- Page 1 VECTECH 378DA & 378DH Self-Feeder Soldering Station Instruction Manual...
-
Page 2: Table Of Contents
Self-Feeder Soldering Station 1. Safety Instruction Contents Chapter 1 Safety Instruction ........................2 Chapter 2 Product Summary ........................3 2.1 Specification ............................3 2.2 Instruction ............................3 2.3 Feeding & Cutting Device (option) ..................... 4 Chapter 3 Instruction of Working State and Socket ..................6 3.1 Switching &... -
Page 3: Chapter 1 Safety Instruction
Self-Feeder Soldering Station 1. Safety Instruction Chapter 1 Safety Instruction In this instruction manual, “Warning” “Caution” and “Note” are defined as followings: WARNING Misuse may potentially cause death or serious injury to the user. Misuse may potentially cause injury to the user or physical damage to the objects CAUTION involved. -
Page 4: Chapter 2 Product Summary
The feeding is precise and the controlling method is flexible. The feeding speed, returning length, alarming mode etc., all are steady and can be adjusted. By the unit, it can get well soldering effect and improve the solder work efficiency. 2.1 Specification Type 378DA & 378 DH ★100~130V / 200~240V AC Voltage Power 320W Heating √... -
Page 5: Feeding & Cutting Device (Option)
Self-Feeder Soldering Station 2. Product Summary Description LCD display Setting number (+)/(-) Alarm indicator lamp Wire feeder indicator lamp Dial switch Parameter setting button Wire feeder button Wire back button Power switch Soldering station switch Solder wire feeding device switch Function Description Function... - Page 6 Self-Feeder Soldering Station 2. Product Summary Device of Solder wire feeding371L Device of Solder wire feeding and cutting371LI 371H: it can feed the solder wire automatically. The pressure adjusting screw at the right side can adjust the feeding pressure. 371HI: it can cut fine hole at the solder wire and then feed the solder wire automatically. 371L: it can feed the solder wire automatically.
-
Page 7: Instruction Of Working State And Socket
Self-Feeder Soldering Station 3. Instruction of Working State and Socket Chapter 3 Instruction of Working State and Socket 3.1 Switching & Instruction of Working Mode 1. The dial switch is “7777”, press the “FEEDER” and "RETURN" buttons simultaneous until the wire feeder indication light flashing, it can change solder wire feeding cutting device (371 HI, 371 LI). -
Page 8: Instruction Of Socket
Self-Feeder Soldering Station 3. Instruction of Working State and Socket 3.3 Instruction of Socket 3.3.1 Six-pin socket The function of six-pin socket is as following table. Pin’s No. Instruction of pins Application 6P-1 Sensor - 6P-2 Sensor + 6P-3 6P-4 Heater 6P-5 Heater -... -
Page 9: Eight-Pin Socket (Optional)
Self-Feeder Soldering Station 3. Instruction of Working State and Socket 3.3.3 Eight-pin socket (optional) The function of eight-pin socket is as following table. Pin’s No. Instruction of pins Application 8P-1 Motor1 Feeder motor signal 8P-2 Motor2 Feeder motor signal 8P-3 Motor3 Feeder motor signal 8P-4... -
Page 10: Chapter 4 Soldering Parameters Setting
Self-Feeder Soldering Station 4. Soldering Parameters Setting Chapter 4 Soldering Parameters Setting 4.1 Temperature Setting Note: Make sure the temperature of the controller can be adjusted (the default password is 000). Do not switch off the unit when setting the temperature, or else the setting value will not be memorized. ... -
Page 11: Soldering Parameters Setting
Self-Feeder Soldering Station 4. Soldering Parameters Setting press “*” to save calibration valve. 7. When is displayed on the screen, it is indicate that the calibration is successful. NOTE: Recommend using the 191/192 series thermometers to measure the tip temperature. ... -
Page 12: Enter The Password
Self-Feeder Soldering Station 4. Soldering Parameters Setting It must enter correct password(default password:000) before setting the parameters, password setting, work mode, temperature alarming, address, sleeping time, off time ,round-trip delay setting and baud rate setting. 4.3.1 Enter the Password The default password is “000”. The setting temperature is admitted when the password is 000. If need to limit the setting temperature, the password must be changed, then turn off and turn on the unit. -
Page 13: Working Mode Setting
Self-Feeder Soldering Station 4. Soldering Parameters Setting 4.3.3 Working Mode Setting When the window displays , press “▲” and “▼” buttons simultaneously, then the LCD displays This indicates the unit comes into working mode setting menu, press “▲” and “” button to change displaying digit as follow: The 10~15 among the working modes have alarming sound. -
Page 14: Upper And Lower Limits Alarm Temperature Setting
Self-Feeder Soldering Station 4. Soldering Parameters Setting Alarm：OC connection Normal : OC disconnection WARNING: The heater element and soldering tips will be seriously oxidized or damaged when working with a high temperature. So please choose the working mode carefully and try to operate with a lower temperature if possible. -
Page 15: Off Time Setting
Self-Feeder Soldering Station 4. Soldering Parameters Setting or 50℃ (setting temperature＜ 200℃). 1. Press “*” button until the LCD displays “sleep time”. 2. Press “▲” or “” button to select the required digit, press “*” button to move digit cursor and then press “*” button to save. -
Page 16: Baud Rate Setting
Self-Feeder Soldering Station 4. Soldering Parameters Setting 4.3.9 Baud rate setting 1. Press “*”button until the LCD displays “mode address”. 2. Press “▲” “▼”button② to set delay time and press“*”to save parameters. 3. The baud rate is 115200, 38400 and 19200. 4.3.10 Alarm symbol instruction S-E: sensor error H-E: heater error... -
Page 17: Chapter 5 Feeding & Cutting Setting
Self-Feeder Soldering Station 5. Feeding & Cutting Set Chapter 5 Feeding & Cutting Setting 5.1 Feeding Parameters Setting Press “+” button on the dial switch, and the number will increase one. Similarly, press “-” button, and the number will decrease one. 1. -
Page 18: Feeding Operation
Self-Feeder Soldering Station 5. Feeding & Cutting Set 371HI: if wire feeding is six times abnormal, the alarm signal will be output and alarm indicator lamp is flashing. 371LI: block material time 6×100ms, output alarm signal and alarm indicator lamp is flashing. 371HI: if wire feeding is seven times abnormal, the alarm signal will be output and alarm indicator lamp is flashing. - Page 19 Self-Feeder Soldering Station 5. Feeding & Cutting Set the parts. 1. Remove the feeding tube assembly backwards, until it cannot touch the cutting blade (06) and auxiliary driven gear (10). Take down the acryl board (12). Loosen the screw (15), and then remove out the feeding tube assembly. After that, loosen the locking screw fixing the feeding position tube with 1.5mm internal-hexagonal spanner.
- Page 20 Self-Feeder Soldering Station 5. Feeding & Cutting Set drive gear position tube of feeding M3×4 screw feeding tube feeder supporting plate acryl board axis auxiliary driven gear * fixing plate M3×4 locking screw locking cap 90 jaggies 60 jaggies blade * 40 jaggies blade supporting wheel driven gear...
- Page 21 QUICK INTELLIGENT EQUIPMENT CO., LTD. ADD: NO.11, FengXiang Road, Wujin High-Tech Industrial Development Zone, Jiangsu, China TEL: 86-519-86225678 FAX: 86-519-86558599 POSTCODE: 213167 WEBSITE: www.quick-global.com...
