ARMAND VANITY
Assembly Instructions
TOOLS REQUIRED BUT NOT INCLUDED:
Phillips Head Screw Driver
Do not throw away packing materials and carton until after assembly.
Assemble all parts on a clean smooth surface
The assembly of this item requires x 2 people.
CARE INSTRUCTIONS:
Avoid direct exposure to sunlight. Do not place over heat or Air conditioning vents.
Adjust levelers so that the furniture sits flat on uneven floors.
Blot spills do not rub, with a clean white cloth.
Do not use harsh chemicals.
Before cleaning any part test a small spot in a hidden area.
You may need to re-tighten all bolts after initial use.
PARTS INCLUDED
(A) Table side frame
Quantity: 2pcs
(E) Chair side frame
Quantity: 2pcs
HARDWARE LIST
(1) Bolt
M8 x 35mm
Quantity: 6pcs
(6) Wood dowel
M8 x 40mm
Quantity: 24pcs
EXCLUSIVE AND CONFIDENTIAL PROPERTY OF URBAN OUTFITTERS, INC.
© 2017 UO, Inc. All rights reserved, including all applicable copyright, design and patent rights.
Any unauthorized reproduction, adaptation, distribution or other infringement will be prosecuted.
(B) Table top frame
Quantity: 1pc
(F) Chair rail
Quantity: 4pcs
(2) Bolt
M8 x 80mm
Quantity: 12pcs
(7) Allen key
Quantity: 1pc
(C) Table middle rail
Quantity: 1pc
(G) Seat cushion
Quantity: 1pc
(3) Flat Washers
M8
Quantity: 6pcs
(8) Wrench
Quantity: 1pc
(D) Table back rail
Quantity: 2pcs
(H) Mirror
Quantity: 1pc
(4) Round Washer
M8
Quantity: 12pcs
(9) Screw
M4 x 30mm
Quantity: 4pcs
(5) Hex nut
M8 x 12mm
Quantity: 12pcs
