International Drop Ins
N8100B, 8100-EF, N8200, N8200G, N8700-D, N8800
Service, Installation and Care Manual
Please read this manual completely before attempting to install or operate this equipment! Notify
carrier of damage! Inspect all components immediately.
Hot Food Wells, Cold Pans,
Granite Cold Slabs and Frost Tops
Important Information
Read Before Use
CAUTION
Please Save These Instructions!
September 2013

Advertisement

loading
Need help?

Need help?

Do you have a question about the Delfield N8100B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Manitowoc Delfield N8100B

  • Page 1 International Drop Ins N8100B, 8100-EF, N8200, N8200G, N8700-D, N8800 Service, Installation and Care Manual Please read this manual completely before attempting to install or operate this equipment! Notify carrier of damage! Inspect all components immediately. Hot Food Wells, Cold Pans, Granite Cold Slabs and Frost Tops Important Information Read Before Use...
  • Page 2 International N8000 Series Drop-In Installation and Operation Manual Important Warning And Safety Information WARNING Read This Manual Thoroughly Before Operating, Installing, Or Performing Maintenance On The Equipment. WARNING Failure To Follow Instructions In This Manual Can Cause Property Damage, Injury Or Death. WARNING Do Not Store Or Use Gasoline Or Other Flammable Vapors Or Liquids In The Vicinity Of This Or Any Other Appliance.
  • Page 3: Table Of Contents

    International N8000 Series Drop-In Installation and Operation Manual Contents Receiving And Inspecting Unit ..........3 Serial Number Location ............4 Warranty Information .............. 4 Regulatory Certifications ............4 Specifications ..............5-7 Installation ................8-9 Operation ................. 10-12 Maintenance ................. 13 Wiring Diagram ..............
  • Page 4: Serial Number Location

    International N8000 Series Drop-In Installation and Operation Manual Serial Number Location The serial number on self-contained refrigerated units is on the electrical specifications tag located near the condensing unit. The serial number on remote refrigerated units is on the outside bottom of the food well.
  • Page 5 International N8000 Series Drop-In Installation and Operation Manual Export Specifications Export N8100B Series Self-Contained Mechanically Cooled Pans - R404A Counter Cutout Evap BTU/ Ship Refrig. 12”x20” Temp Model Dimensions V/Hz/Ph Amps H.P. TD/TEMP Weight Charge Pans Class 230-240/ 454 g 18”...
  • Page 6 International N8000 Series Drop-In Installation and Operation Manual Export Specifications Export N8200 Series Self-Contained Frost Tops - R404A Counter Cutout Evap BTU/ Refrig. Temp Model Dimensions V/Hz/Ph Amps H.P. TD/TEMP Ship Weight Charge Class 26/42º/-7° 1112 N8231-E 31.75" 26” 15.75” 30.75”...
  • Page 7 International N8000 Series Drop-In Installation and Operation Manual Export Specifications Export N8700D Series Individually Controlled Heated Food Wells Counter Cutout Ship 12”x20” Temp Control Panel Cutout Model Dimensions V/Hz/Ph Watts Weight Pans Class Dimensions N8717-D-E 17.88” 26” 9.5” 16.88” X 25” 7.00”...
  • Page 8 International N8000 Series Drop-In Installation and Operation Manual Installation N8100 & N8200 Series These units are intended for indoor use only. A room Moisture collecting from improper drainage temperature of no more than 86°F (30°C) is recommended. can create a slippery surface on the floor and a hazard to employees.
  • Page 9: Installation

    International N8000 Series Drop-In Installation and Operation Manual Installation N8700 & N8800 Series Plumbing These units are intended for indoor use only. Be sure the location chosen has a counter strong enough to support the total weight N8700-D Plumbing: Unit is equipped with 1/2” (1.3cm) drains, of the unit and contents.
  • Page 10 International N8000 Series Drop-In Installation and Operation Manual Operation N8100B & N8100NB & N8100 Series mechanically cooled cold pans are adjusted Warming of food product can occur very quickly outside of the at the factory to provide proper operation without any unit.
  • Page 11 International N8000 Series Drop-In Installation and Operation Manual Operation N8200 N8200 Series frost tops are designed to maintain an even Since it takes time for the frost to accumulate initially, the unit layer of frost to pleasantly display product. Once turned on, the should be turned on approximately one hour before it is actually compressor will run continuously.
  • Page 12: Operation

    International N8000 Series Drop-In Installation and Operation Manual Operation N8700-D & N8800 Series These units are designed to hold warm food product between Wet Operation 140ºF to 160ºF (60ºC to 71ºC). Fill the food well with a minimum of 2” (5.1cm) of water and cover with lid or empty pan.
  • Page 13: Maintenance

    International N8000 Series Drop-In Installation and Operation Manual Maintenance Drain Maintenance Cleaning the Condenser Coil Each unit has a drain located inside the unit that removes In order to maintain proper refrigeration performance, the the condensation from the evaporator coil and routes it to an condenser fins must be cleaned of dust, dirt and grease external condensate evaporator pan.
  • Page 14 International N8000 Series Drop-In Installation and Operation Manual Wiring Diagram N8100B & N8100NB CONDENSER FAN ON/OFF SWITCH COMPRESSOR COOLING T'STAT 115V Wiring Diagram 8100-EF, 8100-EFN CONDENSER FAN ON/OFF SWITCH COMPRESSOR COOLING T'STAT 120V Wiring Diagram N8200 & N8200G CONDENSER FAN ON/OFF SWITCH COMPRESSOR 115V...
  • Page 15: Wiring Diagram

    International N8000 Series Drop-In Installation and Operation Manual Wiring Diagram N8700-D PILOT LIGHT (FURNISHED) 1450 W - 240 V HEATING ELEMENT HA–1 LINE HA–2 WIRES INFINITE CONTROL HA–3 Amperes In Line Wires WITH “OFF” TO ADDITIONAL POSITION # Of 240V, FOOD WARMERS HA–4 Warmers...
  • Page 16 International N8000 Series Drop-In Installation and Operation Manual Narrow Base Condensing Unit Assembly 1/5 H.P. R404A, Low N8118B, N8130B, N8143B, N8146NB, N8168NB Delfield Part # Description 000-BN5-003I Assembly, 1/5 Condensing Unit 2160029 Fan, Axial, 5.5.", 230V 2160030 Guard, Fan, 6.0" 026-C58-0037 Shroud, Condenser Coil 3526994...
  • Page 17 International N8000 Series Drop-In Installation and Operation Manual Narrow Base Condensing Unit Assembly N8156B, N8169B Delfield Part # Description 2183300 Harness, wire, power cord 3526719 Compressor, 1/4 h.p., 220v/50hz 3516047 Cold control 024-ADB-0041 Stand, compressor 2162689 Fan assembly, condenser, 8” blade, 220V 026-ANM-0033 Baffle, fan 3516067...
  • Page 18 International N8000 Series Drop-In Installation and Operation Manual Food Well Assembly With Infinite Control N8700 For models N8700D Delfield Part # Description 3434703 Insulation, fiberglass, 9” x 48” 2194335 Thermostat, non-adjustable, 480˚F 026-103-0002 Bottom cover 3434663 Insulation, blanket, 24” wide 026-061-0001 Plate, deflector, DFW, with or without drain 2194007...
  • Page 19: Standard Labor Guidelines

    International N8000 Series Drop-In Installation and Operation Manual Standard Labor Guidelines To Repair Or Replace Parts On Delfield Equipment Advice and recommendations given by Delfield Service Technicians do not constitute or guarantee any special coverage. • A maximum of 1-hour is allowed to diagnose a defective component. • A maximum travel distance of 100 miles round trip and 2-hours will be reimbursed.
  • Page 20 Mt. Pleasant, MI Covington, TN Thank you for choosing Delfield! Help is a phone call away. Help our team of professional, courteous customer service reps by having your model number and serial number available at the time of your call (800) 733-8829. Model: ____________________ S/N: ___________________ Installation Date: ____________ For a list of Delfield’s authorized parts depots,...
