18600 Series and CTP-NB
Service and Installation Manual
Please read this manual completely before attempting to install or operate this equipment! Notify carrier of damage! Inspect all
components immediately.
18600PTL
Pizza Tables with LiquiTec® Rail
18600PDL
Dual LiquiTec ® Rail Prep Table
CAUTION
Please Save These Instructions!
18600PTBM
Pizza Tables with Raised Rail
18600BSTM
Work Table with Backsplash
Important Information
Read Before Use
18600BUCM
Work Tables
CTP-NB
Countertop Condiment Rail
February 2013

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Delfield 18600 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Manitowoc Delfield 18600 Series

  • Page 1 18600 Series and CTP-NB Service and Installation Manual Please read this manual completely before attempting to install or operate this equipment! Notify carrier of damage! Inspect all components immediately. 18600PTL 18600PTBM 18600BUCM Pizza Tables with LiquiTec® Rail Pizza Tables with Raised Rail Work Tables 18600BSTM 18600PDL...
  • Page 2 18600 and CTP-NB Series Service and Installation Manual Important Warning And Safety Information WARNING Read This Manual Thoroughly Before Operating, Installing, Or Performing Maintenance On The Equipment. WARNING Failure To Follow Instructions In This Manual Can Cause Property Damage, Injury Or Death. WARNING Do Not Store Or Use Gasoline Or Other Flammable Vapors Or Liquids In The Vicinity Of This Or Any Other Appliance.
  • Page 3: Table Of Contents

    18600 and CTP-NB Series Service and Installation Manual Contents Receiving & Inspecting Equipment ........... 3 Serial Number Information ............4 Warranty Information ..............4 Regulatory Certifications ............4 Specifications ................5 Refrigerant Charges ..............6 Installation ................. 6 Operation 18600PTBM & PTL Series ............7 18600BUCM &...
  • Page 4: Serial Number Information

    18600 and CTP-NB Series Service and Installation Manual Serial Number Information The serial number on 18600 Series units is located on the electrical specifications tag affixed inside the compressor section next to the pressure control. The serial number on CTP-NB Series units is located on the front of the unit.
  • Page 5: Specifications

    18600 and CTP-NB Series Service and Installation Manual Specifications 18600PTBM Pizza tables with raised rail 1/3 Pan Size # Of Shelf Max Shelf Area Volume BTU Load BTU Sys. Cap. Voltz/Hertz/ NEMA Ship Weight FT 2 FT 3 Model Capacity # Of Doors Shelves Load (LBS)
  • Page 6: Refrigerant Charges

    18600 and CTP-NB Series Service and Installation Manual Refrigerant Charges Refrigerant Charges For 18600 Series Units: 18648-PTBM & PTL ..16 oz. (454g) 18660-BUCM & BSTM ..16 oz. (454g) 18660-PTBM.
  • Page 7: 18600Ptbm & Ptl Series

    18600 and CTP-NB Series Service and Installation Manual Operation: 18600PTBM & PTL Series Product should be loaded into the unit with care. All R404A models have a high pressure limiting device. Under Failure to heed these recommendations could result in severe overloading conditions, or in the event of a condenser fan damage to the interior of the cabinet or the blower coil.
  • Page 8: 18600Pdl Series

    18600 and CTP-NB Series Service and Installation Manual Operation: 18600PDL Series Product should be loaded into the unit with care. All R404A models have a high pressure limiting device. Under Failure to heed these recommendations could result in severe overloading conditions, or in the event of a condenser fan damage to the interior of the cabinet or the blower coil.
  • Page 9: Pressure Control Settings

    18600 and CTP-NB Series Service and Installation Manual Pressure Control Settings The factory recommended low-pressure control settings for 18600PTBM’s are: 55psi cut-in and 30psi cut-out to maintain proper temperature for product in the rail. The interior temperature is controlled by the thermostat mounted in the mechanical compartment.
  • Page 10: Care And Cleaning

    18600 and CTP-NB Series Service and Installation Manual Care & Cleaning Door Gasket Maintenance in place automatically. Once all tracks are replaced, insert the drawer box. Rest the drawer box bottom track on the front track roller. Then Door gaskets require regular cleaning to prevent mold and mildew push the drawer back in place SLOWLY.
  • Page 11 18600 and CTP-NB Series Service and Installation Manual Care & Cleaning, continued If conditions are such that the condenser is totally blocked in three Continuous opening and closing of the doors will hamper the unit’s months, the frequency of cleaning should be increased. Clean the ability to maintain optimum refrigeration temperature.
  • Page 12: Wiring Diagram

    18600 and CTP-NB Series Service and Installation Manual Wiring Diagram - 18600PTBM Series Wiring Diagram - 18600PTL Series For customer service, call (800) 733-8829, (800) 773-8821, Fax (989) 773-3210, www.delfield.com...
  • Page 13: 18600Bucm & Bstm Series

    18600 and CTP-NB Series Service and Installation Manual Wiring Diagram - 18600BUCM & BSTM Series Wiring Diagram - 18600PDL Series For customer service, call (800) 733-8829, (800) 773-8821, Fax (989) 773-3210, www.delfield.com...
  • Page 14: Ctp-Nb Series

    18600 and CTP-NB Series Service and Installation Manual Wiring Diagram - CTP-NB Series POWER SWITCH CONDENSING UNIT TEMPERATURE CONTROLS THE CONDENSING UNIT For customer service, call (800) 733-8829, (800) 773-8821, Fax (989) 773-3210, www.delfield.com...
  • Page 15 18600 and CTP-NB Series Service and Installation Manual 18600PTBM Replacement Parts All 18600PTBM Models 3234290 1" Shelf Support 9321132 1.5" Shelf Support Screw 3234160 Caster, 5, Plate ,Swivel 3234161 Caster, 5, Plate, Swivel, Break 3234392 Hinge, Pan Cover, Center 3234282 Hinge, Pan Cover, End, LH 3234266 Hinge, Pan Cover, End, RH...
  • Page 16 18600 and CTP-NB Series Service and Installation Manual 18600BUCM Replacement Parts All 18600BUCM Models 3234290 1" Shelf Support 9321132 1.5" Shelf Support Screw 3234160 Caster, 5, Plate, Swivel 3234161 Caster, 5, Plate, Swivel, Brake *000-298-003P Control Assembly 186114BUCM 18699BUCM 18691BUCM 18672BUCM 18660BUCM 18648BUCM...
  • Page 17 18600 and CTP-NB Series Service and Installation Manual 18600BSTM & 18600PTL Replacement Parts All 18600BSTM Models 3234290 1" Shelf Support 9321132 1.5" Shelf Support Screw 3234160 Caster, 5, Plate, Swivel 3234161 Caster, 5, Plate, Swivel, Brake *000-298-003P Control Assembly 186114BSTM 18699BSTM 18691BSTM 18672BSTM...
  • Page 18 18600 and CTP-NB Series Service and Installation Manual CTP8000-NB & 18600PDL Replacement Parts All CTP8000-NB Models 243-ALS-0032 Divider, Bar, Cold 3234392 Hinge, Pan Cover, Center 3234282 Hinge, Pan Cover, End, LH 3234266 Hinge, Pan Cover, End, RH 9321374 Pin, Hinge, Salad Pan CTP8175-NB CTP8160-NB CTP8146-NB...
  • Page 19: Replacement Parts

    18600 and CTP-NB Series Service and Installation Manual Replacement Parts - Control Assemblies Part Number Description 000-282-006I Thermostat & Dual Pressure Control Assembly 2193942 Dual pressure control 2190154 Rocker switch, 20A/125V 2194824 Control, Danfoss, GDM, 115V Part Number Description 000-282-006C &...
  • Page 20 18600 and CTP-NB Series Service and Installation Manual Replacement Parts - Condensing Unit Assemblies Part Number Description 000-AUX-0038 Condensing Unit Assembly, 1/5HP, CTP 3526694 Compressor 000-BN5-0031 Assembly, 1/5 Condensing Unit 3516082 Condenser Coil 3516457 Fan Blade 3516172 Fan Blade 2160020 Fan Guard 2162691 Fan Motor...
  • Page 21 18600 and CTP-NB Series Service and Installation Manual Replacement Parts - Condensing Unit Assemblies Part Number Description Part Number Description 000-BN5-0036 Assembly, 3/4 HP Condenser, Med 000-BN5-0037 Assembly, 1/3 Condensing Unit 2160019 Guard, Fan, Wire 3516457 Fan Blade 3516442 Capacitor, Start, Run, Assembly 2160020 Fan Guard 3527021...
  • Page 22 18600 and CTP-NB Series Service and Installation Manual Replacement Parts - Condensing Unit Assemblies 000-BN5-003Y Assembly, 1/2-1/5 Stacked 3516433 Blade, Fan, 25Deg, 10", CW 3516457 Blade, Fan, 7.25 DIA. 2194789 Capacitor, Start, 240MFD 2194787 Capacitor, Start, 280MFD 3516455 Coil, Cond., 1/2 HP 3516454 Coil, Cond., 1/5, 1/4 3526997...
  • Page 23 18600 and CTP-NB Series Service and Installation Manual Replacement Parts - Evaporator Coil Assembly Part Number Description 000-248-0037 Coil Assembly, R404A, Ref, Fan Lt Part Number Description 2160024 Guard, fan, 4.7" 000-248-0030 Coil Assembly, R404A, Ref 2160023 Fan, axiel, 120V 2160024 Guard, fan, 4.7"...
  • Page 24 18600 and CTP-NB Series Service and Installation Manual Replacement Parts - Door & Cover Assemblies Part Number Description Part Number Description 000-187-007X Assembly, Dr, Ref, 19X26, RT, 430 000-402-0054 Assembly, Hinged Cover, 6 Pan, PTL 000-402-004Q Assembly, Hinged Cover, 6 Pan, RT 1701183 Gasket, Dr, 19, Mark7 000-402-004V...
  • Page 25: Standard Labor Guidelines

    18600 and CTP-NB Series Service and Installation Manual Standard Labor Guidelines To Repair Or Replace Parts On Delfield Equipment Advice and recommendations given by Delfield Service Technicians do not constitute or guarantee any special coverage. • A maximum of 1-hour is allowed to diagnose a defective component. • A maximum of 1-hour is allowed for retrieval of parts not in stock. • A maximum travel distance of 100 miles round trip and 2-hours will be reimbursed.
  • Page 26: Notes

    18600 and CTP-NB Series Service and Installation Manual Notes For customer service, call (800) 733-8829, (800) 773-8821, Fax (989) 773-3210, www.delfield.com...
  • Page 27 18600 and CTP-NB Series Service and Installation Manual Notes For customer service, call (800) 733-8829, (800) 773-8821, Fax (989) 773-3210, www.delfield.com...
  • Page 28 Mt. Pleasant, MI Covington, TN Thank you for choosing Delfield! Help is a phone call away. Help our team of professional, courteous customer service reps by having your model number and serial number available at the time of your call (800) 733-8829. Model: _______________________ S/N: ______________________ Installation Date: _______________ For a list of Delfield’s authorized parts depots,...
