EUCHIPS EULP20D-1WMC-0 Quick Start Manual

EULP20D-1WMC-0
(Product No.:102100123101)

Summary

EULP20D-1WMC-0 is a 20W AC/DC constant current mode output LED driver featuring the multiple levels
selectable by DIP switch and complies with DALI standard protocol IEC 62386. EULP20D-1WMC-0 can be
connected to DALI main controller or Touch DIM to achieve a smooth dimming effect.

Product Features

· Single channel output, output current level selectable by DIP S.W.
· Meet DALI protocol IEC 62386
· Support Touch DIM function
· Wide input voltage of 100VAC ~ 240VAC
· High efficiency up to 83%
· Built-in active PFC function
· Dimming effect smooth, no flicker
· Protections: Over load, short circuit
· Suitable for indoor LED lighting application, such as down light, panel light,
tri-proof light, and so on
Technical Paramaters
Model
EULP20D-1WMC-0
Efficiency
Voltage
Frequency Range(Hz)
Input
Power Factor
THD(full load)
AC Current(max)
Standby power
Inrush Current(max)
Current(mA)/Voltage (VDC)
Power(W)
Ripple Current
Output
Channel
Current Tolerance
No load output voltage
Dimming Type
Function
Dimming Range
Short circuit
Protection
Over Load
Surge
Withstand Voltage
Safety& DALI Standard
EMC Safety Standards
EMC Eission
EMC Immunity
Working Temp.
Storage Temp., Humidity
tc
Material
IP Rating
Others
Lifetime
Warranty Condition
Switch Cycle
Packing(weight)
Dimension
User's manual: 2019-8

Application

Downlight Panel Light
>83%@230VAC,Full load
100VAC-240VAC
50/60Hz
≥0.95@230VAC,Full load
<10%@230VAC, Full load
0.12Amax@230VAC
<0.5W
Cold start,35A(twidth=20us measured at 50% Ipeak)@230VAC
350mA/9-45VDC/15.75W 500mA/9-40VDC/20W
700mA/9-29VDC/20.3W
<3%
1
±5%
55Vdc
DALI/Touch DIM
0.1%-100% Dimming to off
Close output，recovers automatically after fault removed
When the output voltage is exceeded, the output current decreases and,
recovers automatically when the load is reduced.
L-N:500V
I/P-O/P: 3000VAC/1min/5mA
IEC 62386-101: 2014, IEC 62386-102: 2014; IEC 62386-207: 2009, DALI 1.0
EN61347, GB19510
EN50515, EN61000-3-2
EN61000-4-2, 3, 4, 5, 6, 8, 11; EN61547
-20℃~50℃
-40℃~85℃, 20-90%RH
70℃
Metal
IP20
30,000h@tc:65℃
3 years
>15,000 times
Net weight: 230g±5%/PCS; 50PCS/Carton; 12kg±5%/Carton; Carton Size:502*338*149mm(L*W*H)
280*30*21mm（L*W*H）
1/2
DALI Constant Current Dimming Driver
Spotlight Ceiling Light Decorative Light

Current Selection Table

350mA 500mA
ON OFF
9-45V 9-40V
Remark: Function default setting is: 350mA (@switch are
all OFF state)
Floor Light Flood Light
700mA
9-29V
