HE-XL103
Digital DC Inputs,
12 Digital Outputs,
2 Analog Inputs
(Medium Resolution)
User' s Guide
Shop online at
e-mail: info@omega.com
For latest product manuals:
HE-XL104
24 Digital DC Inputs,
16 Digital Outputs,
2 Analog Inputs
(Medium Resolution)
omega.com
omegamanual.info
Advertisement
Related Manuals for Omega HE-XL103
Summary of Contents for Omega HE-XL103
- Page 1 User’ s Guide MADE IN Shop online at omega.com e-mail: info@omega.com For latest product manuals: omegamanual.info HE-XL103 HE-XL104 Digital DC Inputs, 24 Digital DC Inputs, 12 Digital Outputs, 16 Digital Outputs, 2 Analog Inputs 2 Analog Inputs (Medium Resolution) (Medium Resolution)
- Page 2 Approach Directives. OMEGA will add the CE mark to every appropriate device upon certification. The information contained in this document is believed to be correct, but OMEGA accepts no liability for any errors it contains, and reserves the right to alter specifications without notice.
- Page 3 Specifications Specifications Digital DC Inputs XL103 XL104 Digital DC Outputs XL103 XL104 12 including 4 24 including 4 12 including 2 configurable 16 including 2 configurable Inputs per Module configurable HSC configurable HSC Outputs per Module PWM outputs PWM outputs inputs inputs rcing / 10 K Pull-Down...
- Page 4 CsCAN cables to the ports using the provided connectors. Begin configuration procedures. R .125” [3 mm] TYP. 5.156" RADIUS CORNERS [131mm] WHEN REQUIRING DUST OR WATER TIGHT SEAL PER NEMA 4, 4X OR 12 6.875" [175mm] 001OCS003-R1 001XLQX007 HE-XL103 and HE-XL104 __________________________________________________________________________________________________________________________________________________________________ Page 2 of 6...
- Page 5 Ports and Connectors To Remove I/O Cover: Unscrew 4 screws located on the cover. Removable Remove cover. Media Mini B USB 5 pin Memory Slot CAUTION: Do not over tighten programming port screws when replacing the back cover. I/O Cover I/O Jumpers: User Interface I/O Jumpers (JP) are located internally.
- Page 6 Serial Communications: MJ2 Pinouts in Half and Full Duplex Modes MJ1: (RS-232 / RS-485) Use for Cscape programming MJ2 Pins and Application-Defined Communications. Signal Direction MJ2: (RS-232 / RS-485) Use for Application-Defined Communications. Ground +5 60mA MJ1 Pins MJ2 Pins Signal Direction Signal...
- Page 7 Wiring and Jumpers Wiring Examples • Wire according to the type of inputs / outputs used and select the appropriate jumper option. XL103 / 104 J1 Orange • Wiring Specifications Positive Logic Digital In • For I/O wiring (discrete), use Location of I/O jumpers (JP) the following wire type or and wiring connectors...
- Page 8 Filter Safety Filter Constant sets the level of digital filtering according to the following chart. When found on the product, the following symbols specify: Filter Warning: Electrical Warning: Consult Constant Shock Hazard. user documentation. This equipment is suitable for use in Class I, Division 2, Groups A, B, C and D or Non-hazardous locations only WARNING –...
- Page 9 Department will issue an Authorized Return (AR) number immediately upon phone or written request. Upon examination by OMEGA, if the unit is found to be defective, it will be repaired or replaced at no charge. OMEGA’s WARRANTY does not apply to defects resulting from any action of the purchaser, including but not limited to mishandling, improper interfacing, operation outside of design limits, improper repair, or unauthorized modification.
- Page 10 Where Do I Find Everything I Need for Process Measurement and Control? OMEGA…Of Course! Shop online at omega.com TEMPERATURE Thermocouple, RTD & Thermistor Probes, Connectors, Panels & Assemblies Wire: Thermocouple, RTD & Thermistor Calibrators & Ice Point References Recorders, Controllers & Process Monitors...
