Configuring with the WBM
6.3 The menu items of the WBM
Displayed parameters
Distance limiting
Max. number of
transponders
Transponder type
Antenna status
Presence check
Table 6- 18
Displayed parameters
UID
Transponder type
Version
Lock status of the OTP
area
Size of the user memory Memory size of the user memory in bytes
Size of a memory block
Number of memory
blocks
Measured value power
flux density
Passive error counter
Active error counter
Presence counter
58
Description
This parameter has no relevance for RF360R (Fixed value: 0).
Maximum number of transponders to be expected that may be located in
the antenna field at the same time. Due to single tag mode, RF360R may
have a maximum of one transponder in the antenna field.
Set transponder type profile
The following values are possible:
Value
0x00
0x01
0x03
0x04
0x05
0x06
0x08
0x10
0x11
Status of the antenna
Set presence check profile
Displayed parameters of the "Transponder status" area
Description
Unique identifier of the transponder
Transponder type (vendor, identification)
Version of the transponder chip
Disabled blocks of the OTP area on the chip
Size of the memory blocks of the transponder chip
Number of memory blocks of the transponder chip
Radiant power that arrives at the transponder.
The lower the value, the more power the transponder receives.
Number of passive errors which occurred
Number of errors which occurred
Sum of the signature and CRC errors
Time in [ms] that the transponder spent in the antenna field.
Meaning
RF300 (RF3xxT)
ISO 15693 general
MDS D3xx, Infineon
MDS D4xx, Fujitsu - 2 KB
MDS D1xx, NXP
MDS D2xx, TI
MDS D5xx, Fujitsu - 8 KB
RF300 (RF3xxT)
General Mode
