 Unplug the data/power cable from the instrument to turn the instrument off.
 Plug the data/power cable into the instrument to turn the instrument on.

Output Formats

Default Output Format

MVP•X are set to display pressure, sound velocity, conductivity, and temperature, in that order. If
any of those sensors are not installed, no value is displayed for that sensor. Note that only the
order of the real values is affected by this command. The following table shows the decimal format
for each Xchange™ sensor:
Conductivity•Xchange™
Pressure•Xchange™
Temperature•Xchange™
Example CTD output:
0000.61 33.859 21.950
0000.65 33.860 21.950
0000.69 33.857 21.950
0000.65 33.859 21.950
0000.61 33.857 21.951
0000.59 33.858 21.951
0000.61 33.858 21.951
0000.59 33.859 21.951
0000.61 33.858 21.951
0000.59 33.860 21.951
0000.59 33.858 21.950
Example SVPT output:
0000.61 1431.859 21.950
0000.65 1431.860 21.950
0000.69 1431.857 21.950
0000.65 1431.859 21.950
0000.61 1431.857 21.951
0000.59 1431.858 21.951
0000.61 1431.858 21.951
0000.59 1431.859 21.951
0000.61 1431.858 21.951
0000.59 1431.860 21.951
0000.59 1431.858 21.950
User Manual for AML Oceanographic's MVPX
Sensor
SV•Xchange™
Units Default Format
m/s 1234.567
mS/cm 12.346
dBar 1234.56
C 12.345
8
