7. CONFIGURATION OF THE INSTALLER

This configuration must be done by the installer of the
unit. To access it, press the "+" and "-" keys at the same
time while being at code C0. Press the "C" key to go to the
following code. Press the "+" and "-" keys to change the
values. Press the "C" key until the C0 code is displayed to go
back to CONSULTATION.
Do not change the parameters related to the motor-
ised valves if a programme is working or the motorised
valves are moving. It may cause a malfunction in the unit.
In the programming by openings, only codes 10 to 13
are significant.
- Code 00: Programming mode. By opening percentage
(set at YES pressing the "+" key) or by conductivity ref-
erence (set at NO pressing the "-" key).
- Code 01, 02, 03 and 04: Timings. Indicate, in seconds,
the time that must go by from the detection of the acti-
vation of an input until the programmer takes it into ac-
count. The value must go from 0 to 99.
- Code 05: Alarm outlet: Set at YES (press the "+" key)
so that outlet S5 activates when there is a breakdown.
Set at NO (press the "-" key) so that outlet S5 does not
activate.
- Code 06: Initial regulation delay. Indicate the time in
seconds that the programmer has to wait before start-
ing the regulation when a programme starts. During this
time, the applied opening percentage will be memo-
rised in the last irrigation. This allows the stabilisation of
the mixing. The value must go from 0 to 250.
- Codes 07: Self-adjustment delay. Indicate, in seconds,
the time that has to go by between an adjustment at-
tempt and the next one. The self-adjustment time is the
time that has to go by since a change has taken place at
the opening of one of the motorised valves until the fol-
lowing change takes place. The minimum time is 4 sec-
onds and the maximum 99.
- Code 08: Permissiveness margin. Indicate how much
the reading of the CE can differ from the given refer-
ence without a regulation taking place. Diminish the
value to obtain more precision. Increase the value to
diminish the movement of the motorised valve/s. The
minimum value is 0 the maximum 0,5.
- Code 09: Higher conductivity water. Press the "+" key
if A1 (water controlled by the motorised valve M1) is
the water with the highest conductivity. Press the "-"
key if A2 (water controlled by the motorised valve M2)
is the one with the highest conductivity.
- Code 10: Available motorised valves. The available mo-
torised valves are changed with the "+" and "-" keys. In-
dicate A1 if there is only one motorised valve and it is
connected to the outlets S1 and S2. Indicate A2 if there
is only one motorised valve and it is connected to the
outlets S3 and S4. Indicate A1 and A2 if there are two
motorised valves.
- Code 11: Opening time of the motorised valves. Indi-
cate the necessary time in seconds to completely open
the motorised valves M1 and/or M2 being completely
closed. The maximum time is 199 seconds.
- Code 12: Minimum movement percentage of the mo-
torised valves. Indicate the minimum opening of the
motorised valve M1 and/or M2. The values go from 0.1
to 5.0.
- Code 13: Minimum opening of motorised valve M1
and/or M2 while the mixing is taking place. If it is not
possible to get the expected number (due to the mini-
mum movement of the motorised valve) we will ap-
proach at it as much as possible, by defect or excess.
The control values go from 0 to 99.
- Code 14: Water to be saved. Indicate which water you
want to spend the least. Press the "+" key to indicate
A2 (water regulated by motorised valve M2) or press
the "-" key to indicate A1 (water regulated by motorised
valve M1).
