SUPPLIED MATERIAL
•
GPRS Modem
•
Power supply cable
•
Data cable
•
Antenna
ASSEMBLY
1
Disconnect the power from the controller.
2
Insert the phone
jack from the power
supply to the modem.
4
Connect the
antenna to the
modem and place it
up high so that it has
optimum visibility
towards the GSM/
GPRS centre and
granting it the proper
coverage.
Agrónic 7000
GPRS modem installation
Antenna
GPRS Modem
3
Connect the
three-metre telephone
cable (telephone jack)
to the RS232 port of
the A7000 and (SUBD9)
to the modem.
5
If you use the
provided Progrés
SIM card, see the
attached instructions.
If you use your own, deactivate the PIN, remove the
provided card (press until you hear a click), and insert
your own card according to the drawing on the modem.
Using a screwdriver, push the card into the slot until you
hear a click.
Data cable
Power supply cable
