2. SCREEN DATA

Information is displayed on the screen in the following
way: the first two digits indicate the code in which we are.
The following block of digits gives information about the
motorised valve M1, while the last block of digits makes
reference to the motorised valve M2 or to the electric
conductivity.
Use the "C" key to go from one code to the next one.
If you keep pressing this key, the code will change rapidly.
Use the "+" and "-" keys to modify the values which
are displayed on the screen. These keys will increase or de-
crease the active value which is displayed in that moment.
If you keep pressing the key, it increases or decreases rap-
idly.

3. CHARACTERISTICS OF THE UNIT

Feeding
Outlet
Number 5
Type Relay, Triac. optolinked
Environment
Temperature 0º C a 45º C
Humidity < 85 %
Height 2000 m.
Pollution Grade II
DECLARATION OF CONFORMITY
It follows the 89/336/CEE Guidelines for the Electromagnetic compatibility and the 73/23/CEE
Guidelines of Low Tension for the Fulfilment of the Product Security. The fulfilment of the follow-
ing specifications was demonstrated as indicated in the Official Diary of the European Communi-
ties.
Symbols which can be displayed on the product
Power source
Energy consumption
Input fuse
Inputs
Weight (approximate)
1 Kg.
24 V. ac
Average consume: 8,5 VA
2,5 A, type F, 250 V (fast)
Number 4
Type Optolinked
Memory backup
Parameters, pro-
grammes
Double insulation
It can not be
erased
