INSTRUCTION MANUAL: 32 Device,4 Zone Addressable Fire Alarm Panel
ADDRESSABLE
FIRE ALARM PANEL

Controls

The Simplicity Micro has the following controls:-
BUTTON LABEL
START/STOP
SILENCE FAULT TONE
RESET
LED TEST
NEXT
PREV
GENERAL TEST
GENERAL
DISABLEMENT
0 TO 9
ENTER
CANCEL
Note that the controls can only be used after the first access code has been
entered.

Enabling the controls.

Press enter.
The panel now prompts enter access code
Enter the code 123
The screen returns to its previous contents, but now access on LED is lit.

Entering Configuration Menu 1 (User menu)

If the system normal screen is showing, just press enter
If a fault or fire is showing, press enter (to display details), then cancel. This
returns the user to the menu.

Entering Configuration Menu 2 (Engineer Menu)

From Configuration Menu 1, press the NEXT button by the LCD Screen.
The panel now prompts enter access code
Enter the code 369
The panel will now display Configuration Menu 2
Approved Document No: GLT.MAN-129
Issue : 1.0 Author: NRPJ
USE
Used to silence the sounders in an alarm, or to manually start the
sounders to evacuate building
Used to silence the panel`s internal buzzer in a fault or alarm
condition.
Used to return the panel to its normal condition after an ALARM
condition. All faults (except power faults) can also be reset, but
they will return if the source of the fault remains. (Faults are non-
latching so will clear by themselves when the fault has been
cleared)
To check that all indicator LEDs are working. Use as part of the
daily / weekly fire alarm inspection.
Used to display the Next message (or next event in log) in LCD
Used to display the Previous message (or Previous event in log)
in LCD
Used to initiate test mode
Used to initiate zone disable mode
Used to enter access code, and device description
Used to confirm actions
Used to cancel actions (and delete in text entry)
Date: 11/04/2008
PAGE 9
