Cattani ASPI-JET 6 y Operator's Handbook Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

WE LOVE WHAT WE DO.
ASPI-JET
6-7-8-9
Operator's handbook
0 42 5
english

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ASPI-JET 6 y and is the answer not in the manual?

Questions and answers

Related Manuals for Cattani ASPI-JET 6 y

Summary of Contents for Cattani ASPI-JET 6 y

  • Page 1 WE LOVE WHAT WE DO. ASPI-JET 6-7-8-9 Operator’s handbook 0 42 5 english...
  • Page 3 INDEX General running data Legend of components Certification of medical equipment according to directive 93/42/CEE Introduction Signals Recommendations General features General installation and starting tips Installation Operation and use Notice Maintenance and cleaning Main cleaning and maintenance operations Notice Maintenance operations meant for engineers Important notice Transport and storage Transport of second-hand appliances...
  • Page 4 GENERAL RUNNING DATA DENTAL ASPIRATOR Model Aspi-Jet 6-7-8-9 γ Rated voltage 230 V Rated frequency 50 Hz Rated current 3,1 A Insulation class Class I Type of appliance continuous service Protection against liquids COMMON IP20 Level of protection against direct or indirect contact type B Room conditions (temperature) from + 5 °C to + 40 °C...
  • Page 5 Alternating current IEC 417-5032 Earthing IEC 417-5019 Type B appliance IEC 878-02-02 IEC 417-5008 IEC 417-5007 Cup-filler ISO 7000-1854 Bowl flush ISO 7000-1855 Manufactured by CATTANI S.p.A. - PARMA - ITALIA cod: ed. 10-2021...
  • Page 6 LEGEND OF COMPONENTS Aspi-Jet 6 γ Aspi-Jet 7-8-9 γ On/Off switch Exhausted air silencer Fluids conveying pipe Aspirated air conveying pipe to motor Exhausted air conveying pipe to silencer Aspirated liquids manifold Canister Draining valve Maximum level probes - Canister full level alarm Draining pump Filter on canister cover Filter on canister cover...
  • Page 7 ASPI-JET 6 γ ASPI-JET 7-8-9 γ cod: ed. 10-2021...
  • Page 8 180810 While submitting an order for the above components appliance, committing to install the components to to the sales department of CATTANI S.p.A, they shall that appliance and not to others. also indicate SERIAL NUMBER of the concerned cod: ed. 10-2021...
  • Page 9 INTRODUCTION SIGNALS RECOMMENDATIONS INTRODUCTION The following presentation aims at illustrating the shown on the package. The carton is recyclable, equipment and systems dealt with herein to users it is recommended to dispose of it in compliance and engineers; it also aims at explaining operation with the regulations in force.
  • Page 10 • You can find all our updated manuals at our • Dispose of the package in compliance with website: www.cattani.it. We recommend that you regulations. consult them, especially for updates on the subject • Verify that the appliance has not been damaged of safety.

  • Page 11: Installation

    INSTALLATION INSTALLATION The aspirator must be installed in compliance with CEI 62-5 regulation for electro-medical appliances (Aspi-Jet 6-7-8-9 γ have been designed accordingly). Prior to plugging in the unit, check the specifications on the label and make sure that the mains are compatible with the appliance and protected against overcurrent according to CEI 64/8 regulations.

  • Page 12: Operation And Use

    OPERATION AND USE OPERATION AND USE Aspirated liquids and air are conveyed to the the windings is back to normal. Should this happen, manifold (4) through the tip and lifted hose and into identify and eliminate the cause. the canister through tube 3A (page 7); inside the canister liquids are separated from air.

  • Page 13: Maintenance And Cleaning

    NOTICE MAINTENANCE AND CLEANING NOTICE Prior to starting any servicing operation on appliances that have been used, clean with Puli-Jet plus new or Puli-Jet 2.0 a few times as explained in the maintenance section. Use disposable GLOVES (fig. B3), GOGGLES, MASK and OVERALL.
  • Page 14 For Aspi-Jet 7-8-9 γ the canister must be removed fortnight, cleaned and disinfected. Canisters, covers and probes of all models once a week must be accurately cleaned with a sponge and Puli-Jet plus new or Puli-Jet plus 2.0 diluted in hot water.
  • Page 15 MAIN CLEANING AND MAINTENANCE OPERATIONS NOTICE MAINTENANCE OPERATIONS MEANT FOR ENGINEERS MAIN CLEANING AND MAINTENANCE OPERATIONS • After every patient, replace or disinfect the • After each working day: clean filters, clean plant external hose (preferably with Eco-Jet 1). with disinfecting Puli-Jet plus new or Puli-Jet plus •...
  • Page 16 Before servicing the equipment wear disposable gloves, goggles, mask. Aspirated debris is infected and contaminated, moreover the appliances to be serviced could be under pressure and the risk of contaminating splashes is clearly higher. Short-circuit probes and check: • switching off of aspiration unit, and •...

  • Page 17: Important Notice

    • Distributors, agents authorized retailers and equipment) regulations. technicians are supplied with split-up drawings, • On the web site www.cattani.it, you can find our electrical diagrams, handbooks and updating, as for updated manuals. We recommend to consult them, servicing and maintenance.

  • Page 18: Waste Disposal

    WASTE DISPOSAL INFORMATION FOR PROFESSIONAL USERS • Pursuant to art. 13 Legislative Decree no.151 25 of negative effects on the environment and on July, "Implementation of directive 2011/65 EU ROHS human health and promotes reuse and/or recycling and 2003/108/CE, concerning reduction of the use of the materials with which the appliance is made.
  • Page 19 ELECTROMAGNETIC COMPATIBILITY CONFORMITY LEVELS PER EN 60601-1-2:2015 STANDARD ELECTROMAGNETIC COMPATIBILITY CONFORMITY LEVELS PER EN 60601-1-2:2015 STANDARD Warnings: Although compliant with standard EN 60601-1-2, the medical device can interfere with other nearby equi- pment. The device must never be used in the proximity or be stacked on top of other equipment. Install the device away from other equipment emitting high frequency (short waves, microwaves, electro surgery unit, cellular telephones).
  • Page 20 ELECTROMAGNETIC COMPATIBILITY CONFORMITY LEVELS PER EN 60601-1-2:2015 STANDARD cod: ed. 10-2021...
  • Page 21 cod: ed. 10-2021...
  • Page 22 cod: ed. 10-2021...
  • Page 23 cod: ed. 10-2021...
  • Page 24 We reduce costs: less maintenance and lower energy costs mean that we are always the most economical on a cost-benefit analysis. We reduce environmental impact: we save 50% on raw materials, and allow you to save between 30% and 50% on electrical consumption. Via Natta 6/A 43122 Parma – Italy T +39 0521 607 604 info@cattani.it WWW.CATTANI.IT...

This manual is also suitable for:

Aspi-jet 7 yAspi-jet 8 yAspi-jet 9 y
