DUO
NOVA
TM
Multi-Use Pressure Cooker
Welcome
Initial Set-up
Getting Started
Venting Methods
Initial Test Run (Water Test)
More Controls and Smart Programmes
Support and Contact Information
Getting Started Guide
Full Manual, How to Videos and Recipes available online at instantpot.co.uk
Register your product today at instantpot.co.uk/support/register-your-product/
Advertisement
Related Manuals for Instant Pot DUO NOVA
Summary of Contents for Instant Pot DUO NOVA
- Page 1 NOVA Multi-Use Pressure Cooker Welcome Initial Set-up Getting Started Venting Methods Initial Test Run (Water Test) More Controls and Smart Programmes Support and Contact Information Getting Started Guide Full Manual, How to Videos and Recipes available online at instantpot.co.uk Register your product today at instantpot.co.uk/support/register-your-product/...
- Page 2 Welcome to the world of Instant cooking. As the new owner of an Instant Pot® Duo™ Nova 7-in-1 Multi Pressure Cooke, we’d like to welcome you to the Instant Community. At Instant Brands™, we are committed to helping homechefs worldwide to cook healthier, and get delicious meals on the table, quicker and easier than ever before.
-
Page 3: Initial Setup
Failure to do so may result in property damage and/or personal injury. • Use ONLY the Instant Pot® Duo Nova lid with the Instant Pot® Duo Nova pressure cooker. Using any other pressure cooker lids may cause injury and/or damage. - Page 4 Inner Pot Cooker Parts Overview Top of Lid Stainless Steel Inner Pot Steam Release Valve Float Valve Quick Release Button Handle Cooker Base Lid Position Marker Cooker Handles Lid Fins Condensation Rim Bottom of Lid Outer Pot Locking Pin Heating Element Float Valve Silicone Cap Anti-Block Shield Control Panel...
- Page 5 Open and Close Lid When cooker is plugged in, it will play a jingle when lid is opened and closed. Open Close Open: Grip handle and turn lid anti-clockwise Close: Grip handle and align the on lid with until on lid is aligned with indicator indicator on rim of cooker base.
- Page 6 Only one sealing ring should be installed when using your cooker. Replace your sealing ring every 12-18 months or when deformation or damage is noticed. Install Always check for cuts or deformations in sealing ring prior to cooking. Only use authorised Instant Pot ® CAUTION sealing rings.
- Page 7 Remove and Install Float Valve The float valve has 2 positions. It pops up to indicate when the cooker is pressurised and lowers into the lid when the cooker is depressurised. Remove: Place one finger on the flat top of the float valve.
- Page 8 Remove and Install Anti-Block Shield Remove: Grip lid and press firmly against side of anti-block shield (pressing towards side of lid and up) until it pops off the prongs underneath. Anti-block shield must be installed before use and cleaned after each use. Install: Place anti-block shield over prongs and press down until it snaps into position.
- Page 9 Remove and Install Steam Release Assembly Remove: Pull steam release valve up and off steam release pipe. Steam release valve must be installed before use and cleaned after each use. Install: Place steam release valve on steam release pipe and press down. Fits loosely when installed properly but will remain in place when the lid is turned over.
- Page 10 Failure to do so may damage the cooker. Place inner pot into cooker base before cooking. Food must be placed only in the inner pot, not cooker base. The inner pot is an integral part of product safety. Always use an authorised Instant Pot inner pot ®...
- Page 11 Install Condensation Collector Install: On back of cooker base, align grooves on condensation collector over tabs and push condensation collector into place. The condensation collector accumulates excess water and should be installed before cooking. Clean after use. Remove: Pull condensation collector away from cooker base. Do not pull down on condensation collector.
-
Page 12: Venting Methods
Do not lean Do not place Do not cover The float valve drops when the cooker has The Duo Nova 9.5 Litre model has a high-pressure over the steam unprotected skin the steam depressurised. Do not attempt to open the lid while valve. - Page 13 11. Discard water and dry inner pot. 6. Use + / – keys to adjust cooking time to “00:05” minutes. 12. Start cooking! Note: The Instant Pot will save any customisation made to cooking time. After 10 seconds, display indicates “On” and cooker begins Pre-heating.
-
Page 14: More Controls
More Controls Cancel Press to stop a Smart Programme at any time. Cooker returns to Standby and displays “OFF”. Delay Start Postpone cooking up to 24 hours. Select a Smart Programme and, if desired, adjust the cooking time, then press Delay Start to turn the setting on. - Page 15 Smart Programmes Smart Setting Suggested Use Note Programme Less Soup without meat Liquid remains clear due to lack of boiling motion. Soup/Broth Normal Soup with meat Always use NR to release pressure when cooking soup with a high starch content. More Rich bone broth Less...
- Page 16 Smart Setting Suggested Use Note Programme Less Oatmeal—coarse or rolled Normal White rice porridge/congee Adjust time as directed in recipe. Porridge Always use NR to release pressure when cooking foods that expand. Rice porridge/congee with a mixture More of various grains Less Vegetables Use steam rack provided to elevate food from cooking liquid.
- Page 20 Enjoy time well spent with the Instant family of small appliances. ® Join the Official Instant Pot Community: Instant Brands (EMEA) Limited, Register your product today at: instantpot.co.uk/support/register- www.facebook.com/groups/ 1 Christchurch Way, your-product/ InstantPotUKCommunity Woking, Surrey, GU21 6JG, UK. Contact Customer Care: +44 (0) 3331 230051 UKSupport@instantbrands.com...
