CM3311SC-2PK
ASSEMBLY RATING
Tools Required for Assembly:
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
Allen Wrench
(Included)
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
DIFFICULT
EASY
Page 1 of 5
Rev.14-08-26
Advertisement
Table of Contents
Related Manuals for Furniture of America CM3311SC-2PK
Summary of Contents for Furniture of America CM3311SC-2PK
- Page 1 Assembly Instructions CM3311SC-2PK ASSEMBLY RATING Tools Required for Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench (Included) assembling a specific product (with 1 being easy and 5 being difficult). For some products, two persons are recommended.
- Page 2 Page 2 of 5...
- Page 3 Before you begin, please read Page 3 of “Assembly and Care Advice”. And remember, do not tighten until each step is completed or instructed. Parts List Hardware List #1 x 2 pcs x 2 #A x 4 pcs x 2 Front Leg Bolt 5/16”x3-1/4”...
- Page 4 #C x 1 pc #D x 1 pc #E x 1 pc Turn right (clockwise) to tighten Place the backrest with legs (#3) on a protected surface. Align the seat (#2) with the pre-drilled holes of the backrest with legs (#3).
- Page 5 #B x 4 pcs #D x 4 pcs #E x 4 pcs Align the 2 front legs (#1) with the pre-drilled holes on the corners of the seat (#2). II. Prepare 4 bolt assemblies by inserting FIRST the lock washer (#D) onto the bolt (#B) and then the flat washer (#E) onto the SAME bolt (#B), in that order.
