- Page 1 UICK NSTALLATION LPS-H2C-L7A L...
- Page 2 LPS-H2C-L7A The LPS-H2C-L7A is a low-power, HDSL2 plug-in line card that installs in a ™ ® LoopStar Chassis, Soneplex Loop Extender Chassis (LEC), Soneplex Broadband Chassis (BBC), or Soneplex Integrated Broadband Chassis (IBBC). To ensure proper operation, the LPS-H2C-L7A line unit requires the H2TU-R-402-L7A as the corresponding remote unit.
- Page 3 NSTALLATION Align the line card with the enclosure slot guides and slide the card in until it touches the backplane connector. Raise the extraction lever at the bottom of the front panel to press the card into the backplane connector. OWER EQUENCE When the line card powers up, the following occurs:...
- Page 4 Status LED H2TU Remote/Alarm LED Loopback LED Input line configuration code LED D 1 loss of signal LED B8ZS Continuity or SNR error LED CONT LOSW or BER error LED LOSW D 1 transmit/receive onitor jacks Loopback pushbutton (Initiates a dual loopback at the H2C (H2LXC).
- Page 5 OGGING ON TO THE The LPS-H2C-L7A supports system logon through a maintenance terminal (VT100 or a PC running VT100 terminal-emulation software) connected to the craft port on the SCU front panel. Once logged on, you can access the Main Menu screens to view local and remote system settings, initiate loopbacks, and provision the circuit.
- Page 6 © 2004 ADC Telecommunications, Inc. All rights reserved. Information contained in this document is company private to ADC DSL Systems, Inc., and shall not be modified, used, copied, reproduced or disclosed in whole or in part without the written consent of ADC.
