Seville Classics FRN04743 Assembly Instructions

Resin 4-tier tower

Download this manual

Step 2: Refer to the picture below. First, tighten the 8 pre-inserted Long Screws

Resin 4-Tier Tower

(marked "A" in the picture). Next, screw in and tighten the 8 Short Screws (B) into the

Model No. FRN04743

ASSEMBLY INSTRUCTIONS

8 screw holes on the unit (these screw holes are marked "B" in the picture). Do NOT

over tighten the screws.

How to Fold the Tower (If Needed): First, fully loosen and remove all 8 Short Screws

Customer Service

(marked "B" in the picture above) from the unit. Next, fully loosen (about 5 turns), but

do NOT remove, the 8 remaining pre-inserted Long Screws (marked "A" in the picture

Tel 1.800.323.5565

above). Finally, carefully fold down the unit. Please note that the unit CANNOT be

Fax 1.310.533.3899

Monday through Friday 8:30AM-4:30PM (PST)

folded completely flat. Forcing the unit into a folded position without first removing the

8 Short Screws (B) and fully loosening the 8 pre-inserted Long Screws (A) may result

in irreparable damage to the unit.

Seville Classics, Inc.

Torrance, CA 90501 USA

www.sevilleclassics.com

Need help?

Do you have a question about the FRN04743 and is the answer not in the manual?

Page 1 Resin 4-Tier Tower (marked “A” in the picture). Next, screw in and tighten the 8 Short Screws (B) into the Model No. FRN04743 ASSEMBLY INSTRUCTIONS 8 screw holes on the unit (these screw holes are marked “B” in the picture). Do NOT over tighten the screws.
Page 2 READ AND SAVE THESE INSTRUCTIONS Please Note: 1) Do NOT place the unit vertically when unfolding as this may result in the unit CAUTION suddenly unfolding and pinching your fingers. 1) Do NOT over tighten the screws. Doing so may damage the unit. 2) Find a flat surface or floor to assemble the unit. Using an uneven surface or floor to 2) Do NOT place the unit in high temperature area or near appliances that emit large assemble the unit may result in uneven/unlevel shelves, which can compromise the amount of heat.
