Seville Classics FRN04745 Assembly Instructions

Resin 3-tier book case

Table of Contents

Download this manual

Step 2: Refer to the diagram below. First, tighten the 9 pre-inserted screws (marked

Resin 3-Tier Book Case

Model No. FRN04745

"A" in the picture). Next, screw in and tighten the 6 short screws into the 6 screw holes

on the unit (these screw holes are marked "B" in the picture). Do NOT over tighten the

screws.

Step 3: Use a Phillips screwdriver to screw in and tighten a Bracket (C) using 2

Bracket Screws (D) at four corners of the unit.

Customer Service

How to Fold the Bookcase (If Needed): First, fully loosen and remove all 4 brackets

Tel 1.800.323.5565

(marked "C" in the picture above) from the unit. Then, fully loosen and remove all 6

Fax 1.310.533.3899

Monday through Friday 8:30AM-4:30PM (PST)

short screws (marked "B" in the picture above) from the unit. Next, fully loosen (about

5 turns), but do NOT remove, the 9 remaining pre-inserted screws (marked "A" in the

picture above). Finally, carefully fold down the unit. Please note that the unit

CANNOT be folded completely flat. Forcing the unit into a folded position without first

removing the 4 brackets, 6 short screws and fully loosening the 9 pre-inserted screws

Seville Classics, Inc.

may result in irreparable damage to the unit.

Torrance, CA 90501 USA

www.sevilleclassics.com

Table of Contents

Need help?

Do you have a question about the FRN04745 and is the answer not in the manual?

Page 1 Step 2: Refer to the diagram below. First, tighten the 9 pre-inserted screws (marked Resin 3-Tier Book Case Model No. FRN04745 ASSEMBLY INSTRUCTIONS “A” in the picture). Next, screw in and tighten the 6 short screws into the 6 screw holes on the unit (these screw holes are marked “B”...
Page 2 READ AND SAVE THESE INSTRUCTIONS Please Note: 1) Do NOT place the unit vertically when unfolding as this may result in the unit CAUTION suddenly unfolding and pinching your fingers. 1) Do NOT overly tighten the screws. Doing so may damage the unit. 2) Find a flat surface or floor to assemble the unit. Using an uneven surface or floor to 2) Do NOT place the unit in high temperature area or near appliances that emit large assemble the unit may result in uneven/unlevel shelves, which can compromise the amount of heat.
