EXTERNAL DIMENSIONS

21.5 (.85)
■ TERMINAL ASSIGNMENTS
INPUT RESISTOR
(model: REM2)
Input shunt resistor attached
for current input.
SEN TRONIC
AG
Produkte, Support und Service
unit: mm (inch)
7.3 (.29) 86.7 (3.41)
116.7 (4.59)
4 1
8 5
12 9
14 13
Rugghölzli 2
CH - 5453 Busslingen
DIN RAIL
35mm wide
2–4.2x5
(.17x.20)
MTG HOLE
6 (.24) deep
8–M3
SCREW
[4 (.16)]
• When mounting, no extra space is needed between units.
Tel. +41 (0)56 222 38 18
Fax +41 (0)56 222 10 12
M2LMS
6 (.23)
4 1
8 5
12 9
14 13
15 (.59)
23 (.91)
