Serato DJ Pro
PERFORMANCE SECTION:
Activates the pad mode (1-4) marked on the pads.
Note! Pressing again activates the second level pad modes (5-8).
1: Hot Cue:
Triggers the 8 available cue points per deck. The hot cue colours can
be customised in the software and the pads are and the pads will light up in
the corresponding colours.
Note! Parameter knobs perform flip functions****:
Play, Record, Loop, On/Off
- SHIFT+PAD: Deletes the current cue point.
2. Loop Roll:
Pads 1-4 (de)activate a Loop Roll when the pad is held. Each pad is assigned
to a specific loop length from 1/32 - 4/1. The Loop Roll range can be shifted
via the Parameter 1 buttons. Pads 5-8 control the Beat Jump function.
3. Saved Loops:
Up to 8 loops can be saved. Each pad represents one loop slot. To save a loop,
Set an auto loop and press a pad. Press it again to delete the loop.
- SHIFT+PAD: Triggers the loop.
4. Sampler:
Pads 1-8 trigger the 8 available sample slots. Using the parameter buttons,
you can switch back and forth through banks A, B, C, D. The volume can be
adjusted with the Sampler (6.).
- SHIFT+PAD: Stops the sample.
Pad modes in the second level:
53. Performance Pad Modes
5. Pitch Play*:
(1-4)
In combination with Pitch n Time DJ, you can play back your cues in different
tones. There are 3 keys available. To switch between them, press the left
or right PARAM 1 button. The pad with the basic tone is always white
illuminated; here the cue point is played with the regular pitch. When you are
in Pitch Play mode, pressing the pads will play back your cue point At different
pitches.
- SHIFT+PAD: Selects a different Hot Cue Point for Pitch Play.
6. Saved Flip****:
Up to 8 saved flips can be displayed, pads 1-8 start your previously saved flips.
- SHIFT+PAD: Jumps directly to the respective flip and starts it.
7. Slicer:
If the slicer is activated, a defined section is divided into eight equal parts.
These eight sliced sections are distributed to the corresponding performance
pads. When the playhead reaches the end of the section, it moves beyond the
section and forms a new section.
8. Scratch Bank:
In scratch bank mode, you can assign an audio file from your Serato DJ
Pro Library to each of the 8 performance pads. When a pad is pressed, the
respective file is loaded onto the deck. The pads on the left are loaded on
deck 1 and the pads on the right are loaded on deck 2. To set up your scratch
bank files, click on the on the scratch bank icon in the top bar of Serato DJ
Pro. There you will see the Scratch Bank panel. In this panel, you can load or
eject the audio files you want and define your personal settings. The settings
include the start point, repeat on/off and key lock on/off. By clicking on the
button in the upper left corner of the of the scratch bank panel, you can toggle
between the expanded and simple view.
- SHIFT+PAD: Hold down the SHIFT and click on any Scratch Bank pad to
delete the currently loaded file and and reload the last track
loaded on that deck.
Colour-coded, velocity-sensitive drum pad section, to controll the different
54. Performance Pads (1-8)
performance modes.
FRONT SECTION:
55. Mic 2-In (TRS) Microphone input 2 (6.3 mm jack)
56. Crossfader Curve-Adjust Knob for adjusting the crossfader opening behaviour.
57. Headphone Connections Headphone output (3.5 mm / 6.3 mm jack connection)
(3,5 mm / 6,3 mm)
20
djay Pro AI
Activates the pad mode (1-4) marked on the pads.
Note! Pressing again activates the second level pad modes (5-8).
1: Hot Cue:
Triggers the 8 available cue points per deck. The hot cue colours can be
customised in the software and the pads are and the pads will light up in the
corresponding colours
- SHIFT+PAD: Deletes the current cue point.
2. Loop Roll:
Each pad de-/activates a loop roll when the pad is held each pad is assigned a
specific loop length from 1/32 – 4/1.
3. Saved Loops:
Up to 8 loops can be saved. Each pad represents one loop slot. To save a loop,
Set an auto loop and press a pad. Press it again to delete the loop.
- SHIFT+PAD: Triggers the loop.
4. Sampler:
Pads 1-8 trigger the 16 available sample slots. Sampler mode on the left deck
controls samples 1-8, sampler mode on the right deck controls samples 9-16. If
the sampler mode button is pressed for 2 seconds, PAD VELOCITY and AFTER-
TOUCH are activated. The samples can now be played back at different volumes.
Note! Sampler View is only available in 2-deck view.
- SHIFT+PAD stops the sample.
Pad Modes in the second layer:
5. Pitch Play:
You can play your cues in different keys. There are 3 keys available. To switch
between them, press the left or right PARAM 1 button. The pad with
the root key is always lit in white; here the cue point is played with the regular
pitch. When you are in pitch play mode, pressing the pads will play your cue
point in different Pitches.
- SHIFT+PAD: Select a different Hot Cue Point for Pitch Play.
6. Touch FX Mode:
The drum pads have different instant effects that are activated by pressing the
respective pad.
7. Slicer:
If the slicer is activated, a defined section is divided into eight equal parts.
These eight sliced sections are distributed to the corresponding performance
pads. When the playhead reaches the end of the section, it moves beyond the
section and forms a new section.
8. Neural Mix™:
In Neural Mix™ mode you can control the Algoriddim Neural Mix™ functions
via the drum pads. The drum pads are assigned as follows:
- PAD 1: Drum Solo On/Off = Mute Harmonic & Vocal
- PAD 2: Harmonic Solo On/Off = Mute Drum & Vocal
- PAD 3: Vocal Solo On/Off = Mute Drum & Harmonic
- PAD 4: Drum Swap On/Off (deactivates the drum stem of the selected
channel and activates solo for the drum stem of the other channel)
- PAD 5: Drum Solo Hold = Mute Harmonic & Vocal
- PAD 6: Harmonic Solo Hold = Mute Drum & Vocal
- PAD 7: Vocal Solo Hold = Mute Drum & Harmonic
- PAD 8: Drum Swap Hold (deactivates the drum stem of the selected channel
and activates solo for the drum stem of the other channel)
Colour-coded, velocity-sensitive drum pad section, to controll the different
performance modes.
Microphone input 2 (6.3 mm jack)
Knob for adjusting the crossfader opening behaviour.
Headphone output (3.5 mm / 6.3 mm jack connection)
Serato DJ Pro
REAR SECTION:
58. Mic 1-In (XLR/TRS) Microphone input 1 combi jack (XLR / 6.3 mm jack connector)
Mains cable connection for external power supply.
59. PSU-Power Connection
Power On/Off
60. Power ON/OFF
61. USB-C Port (iOS) USB-C port for iOS
Selection switch for use of the USB-C or USB-B B port.
62. USB-In-Switch
63. USB-B A-Port USB port 1 for PC/Mac
64. USB-B B-Port USB port 2 for PC/Mac
Line input Channel 3 (RCA)
65. Line-In Channel 3 (RCA)
Phono/Line input Channel 1 (RCA)
66. Phono/Line-In Channel
1 (RCA) Note! You can control Serato DJ Pro using Noisemap™
Control tone CDs or Vinyl**.
67. Phono/Line-Switch Signal-In selection switch for Channel 1.
Channel 1
68. Grounding-Screw (GND) Grounding screw
69. Phono/Line-Switch Signal-In selection switch for Channel 2.
Channel 2
Phono/Line input Channel 2 (RCA)
70. Phono/Line-In Channel
Note! You can control Serato DJ Pro using Noisemap™
2 (RCA)
Control tone CDs or Vinyl**.
71. Line-In Channel 4 (RCA) Line input Channel 4 (RCA)
72. Booth-Out (TRS) Booth output (2 x 6.3 mm jack)
73. Master-Out 2 (RCA) Master output 2 (RCA unbalanced)
74. Master-Out 1 (XLR) Master output 1 (XLR balanced)
75. Kensington Lock Theft protection
* Requires the Serato Pitch'n Time Expansion Pack
** Requires the Serato DVS Expansion Pack. Not available for djay.
*** Requires a subscription to the desired streaming service: Tidal,
Soundcloud Go+, Beatport Link and Beatsource Link
**** Requires the Serato Flip Expansion Pack
***** Only available fordjay Pro AI (Mac Edition).
djay Pro AI
Microphone input 1 combi jack (XLR / 6.3 mm jack connector)
Mains cable connection for external power supply.
Power On/Off
USB-C port for iOS
Selection switch for use of the USB-C or USB-B B port.
USB port 1 for PC/Mac
USB port 2 for PC/Mac
Line input Channel 3 (RCA)
Phono/Line input Channel 1 (RCA)
Signal-In selection switch for Channel 1.
Grounding screw
Signal-In selection switch for Channel 2.
Phono/Line input Channel 2 (RCA)
Line input Channel 4 (RCA)
Booth output (2 x 6.3 mm jack)
Master output 2 (RCA unbalanced)
Master output 1 (XLR balanced)
Theft protection
