Reloop MIXON8 PRO Instruction Manual page 10

Serato DJ Pro
FX SECTION:
Arms the microphone on the respective channel (1/4).
Note! In order to activate the microphone channel, you must set the
signal-in switch (12.) of the desired channel to Mic.
25. Mic 1/2 ON
- Channel 1: Mic 1
- Channel 4: Mic 2
26. Mic 1/2 Talkover Enables/disables the talkover function for the selected microphone (1/2).
- Single FX Mode: Controls FX parameter (FX depth)
- SHIFT Single FX Mode: Selects effect for FX unit
27. FX 1-Encoder (FX Unit 1/2)
- Multi FX Mode: Controls FX depth of FX / slot 1
- SHIFT Multi FX Mode: Selects effect for FX unit / slot 1
- Single FX Mode: De-/activates the effect
- Multi FX Mode: De-/activates effect 1
28. FX 1 Arm (FX Unit 1/2)
- SHIFT+FX 1 Arm: Toggles through the effect slot menus for FX Slot 1.
- Single FX Mode: Controls FX parameters
- SHIFT Single FX Mode: N/A
29. FX 2-Encoder (FX Unit 1/2)
- Multi FX Mode: Controls FX depth of FX / slot 2
- SHIFT Multi FX Mode: Selects effect for FX unit / slot 2
- Single FX Mode: Enables/disables various parameters.
- Multi FX Mode: Enables/disables effect 2.
30. FX 2 Arm (FX Unit 1/2)
- SHIFT+FX 2 Arm: Toggles through the effect slot menus for FX Slot 2.
- Single FX Mode: Controls FX parameters
- SHIFT Single FX Mode: N/A
31. FX 3-Encoder (FX Unit 1/2)
- Multi FX Mode: Controls FX depth of FX / slot 3
- SHIFT Multi FX Mode: Selects effect for FX unit / slot 3
- Single FX Mode: Enables/disables various parameters.
- Multi FX Mode: Enables/disables effect 2.
32. FX 3 Arm (FX Unit 1/2)
- SHIFT+FX 3 Arm: Toggles through the effect slot menus for FX Slot 3.
Turn controls the Beats Multiplier value for the software effects.
Pressing resets the Beats Multiplier to the value 1/1.
33. Beat/Param-Encoder
(FX Unit 1/2)
- SHIFT+Turn: Controls beats multiplier value for DJ FX
- SHIFT+Press: Resets the Beats Multiplier to the value 1/1
Manual setting of the FX tempo by pressing for FX unit.
Press and hold to reset the value.
34. Tap (FX Unit 1/2)
- SHIFT+Tab: Toggles between Single or Multi FX modes control or display.
PLAYER SECTION:
Adjusts the tempo of the track.
35. Pitchfader
- SHIFT + pitch fader: You can change the position of the pitch fader while
maintaining the tempo of the track.
Enables/disables slip mode. If the slip mode is active, the track starts at the
exact point, at which it would be if you had not performed any actions.
- SHIFT+Slip: Enables/disables the vinyl mode of the jog wheel.
36. Slip
Note! When Vinyl is activated, the jog wheel stops the playhead.
(or scratches it). Pitch bending is also possible by by moving the
edge of the jog wheel. If vinyl is deactivated, the jog wheel will only
perform only the pitch bend Function.
Toggles between elapsed & remaining time. (elapsed/remaining)
37. Time
- SHIFT+Time: Switches the playing direction of the
respective deck to reverse.
Deactivates/activates Key Lock. If the button is held longer, the tempo will reset.
38. Key Lock
- SHIT+Key Lock: Enables/disables Key Sync*.
Mutes/unmutes the respective deck while the song continues to play in the back-
ground. The deck is reactivated at the selected cue point via the Hot Cue buttons.
39. Silent Cue
- SHIFT+Censor: Changes the pitch range.
(+/-8, +/-16 and +/-50)
Enables/disables the selected auto-loop length.
The loop length can be read via the loop LED bar.
40. Auto Loop
- SHIFT+Auto Loop: De-/activates the selected saved loop.
18
djay Pro AI
Arms the microphone on the respective channel (1/4).
Note! In order to activate the microphone channel, you must set the
signal-in switch (12.) of the desired channel to Mic.
- Channel 1: Mic 1
- Channel 4: Mic 2
Enables/disables the talkover function for the selected microphone (1/2).
- Single FX Mode: N/A
- Multi FX Mode: Controls Dry/Wet value of FX Slot 1
- SHIFT: N/A
Enables/disables effect 1.
- SHIFT+FX 1 Arm: Switches through the effect slot menus for FX Slot 1.
- Single FX Mode: N/A
- Multi FX Mode: Controls Dry/Wet value of FX Slot 2
- SHIFT: N/A
De-/Aktiviert Effekt 2.
- SHIFT+FX 2 Arm: Schaltet durch die Effekt Slot Menüs für FX Slot 2
- Single FX Mode: N/A
- Multi FX Mode: Controls Dry/Wet value of FX Slot 3.
- SHIFT: N/A
Enables/disables effect 3.
- SHIFT+FX 3 Arm: Switches through the effect slot menus for FX Slot 3.
Turn adjusts parameter for FX slots 1-3.
Pressing sets the parameter of FX Slot 1-3 to its original value.
- SHIFT+Turn: N/A
- SHIFT+Press: N/A
Activates FX Slot 1-3 as long as the key is pressed.
When the button is released, FX Slot 1-3 is deactivated.
- SHIFT+Tap: Toggles between FX and Neural Mix™ mode.
Adjusts the tempo of the track.
- SHIFT + pitch fader: You can change the position of the pitch fader while
maintaining the Tempo of the track.
Enables/disables slip mode. If the slip mode is active, the track starts at the
exact point, at which it would be if you had not performed any actions.
- SHIFT+Slip: Enables/disables the vinyl mode of the jog wheel.
Note! When Vinyl is activated, the jog wheel stops the playhead.
(or scratches it). Pitch bending is also possible by by moving the edge
of the jog wheel. If vinyl is deactivated, the jog wheel will only per-
form only the pitch bend Function.
Toggles between elapsed & remaining time. (elapsed/remaining)
- SHIFT+Time: Switches the playing direction of the
respective deck to reverse.
Deactivates/activates Key Lock. If the key is held longer, the tempo is reset.
- SHIT+Key Lock: Enables/disables Key Sync
Mutes/unmutes the respective deck while the song continues to play in the back-
ground. The deck is reactivated at the selected cue point via the Hot Cue buttons.
- SHIFT+Censor: Changes the pitch range.
(+/-8, +/-10, +/-25, +/-50 and +/-75)
Enables/disables the selected auto-loop length.
The loop length can be read via the loop LED bar.
- SHIFT+Auto Loop: De-/activates the selected saved loop.
Serato DJ Pro
Displays the currently selected loop length:
- 1/32 LED 1 flashes
- 1/16 LED 2 flashes
- 1/8 LED 3 flashes
- 1/4 LED 4 flashes
41. Loop-LED-Bar - 1/1 LED 1 lights up constantly
- 2/1 LED 2 lights up constantly
- 4/1 LED 3 lights up constantly
- 8/1 LED 4 lights up constantly
- 16/1 LED 5 lights up constantly
- 32/1 LED 1-5 lights up constantly
42. 1/2x Loop Halves the length of the current loop.
43. 2x Loop Doubles the length of the current loop.
The jog wheel stops the playhead or scratches it
(Vinyl Mode On -> SHIFT+SLIP).
Pitch bending is also possible by moving the edge of the jog wheel.
44. Jogwheel
Note! If the vinyl mode is deactivated, turning the jog wheel, will only
perform the pitch bend function.
- SHIFT+Turn Jog Wheel: Performs a needle search (fast forward) in the track.
The jog wheel display shows information about the track currently loaded in
45. Jogwheel Display the deck. ( USB A/B, Deck 1/3 2/4, Time, BPM, Pitch, Pitchrange, continuous
LED display for the position in the track and rotating track marker).
Controls the parameter functions, depending on the active mode. (Decrease)
46. Param 1 <
- SHIFT+Param 1<: Controls second level of parameter function,
Depending on the active mode. (Decrease)
Controls the parameter function, depending on the active mode. (Increase)
47. Param 1 >
- SHIFT+Param 1>: Controls second level of parameter function,
Depending on the active mode. (Increase)
48. SHIFT Activates second level functions, according to the labelling of the unit.
Toggles between the decks on the respective player.
49. Deck Select (1/3 / 2/4) - Left player: Deck 1/3
- Right player: Deck 2/4
Activates the Sync function.
50. SYNC
- SHIFT+Sync: Deactivates the Sync function.
- During playback: The track returns to the temporary cue point and stops.
- In pause mode: Sets a new temporary cue point at the current position.
If the Cue button is pressed again, the temporary cue is
played as long as Cue is held.
51. CUE
- SHIFT+CUE: The playhead returns to the beginning of the track or loads the
previous track, if the button is pressed for more than one
second during playback.
Activates playback/pause
52. Play/Pause
- SHIFT+CUE: Triggers the temporary cue and the playhead
will continue from that point.
djay Pro AI
Displays the currently selected loop length:
- 1/32 LED 1 flashes
- 1/16 LED 2 flashes
- 1/8 LED 3 flashes
- 1/4 LED 4 flashes
- 1/1 LED 1 lights up constantly
- 2/1 LED 2 lights up constantly
- 4/1 LED 3 lights up constantly
- 8/1 LED 4 lights up constantly
- 16/1 LED 5 lights up constantly
- 32/1 LED 1-5 lights up constantly
Halves the length of the current loop.
Doubles the length of the current loop.
The jog wheel stops the playhead or scratches it
(Vinyl Mode On -> SHIFT+SLIP).
Pitch bending is also possible by moving the edge of the jog wheel.
Note! If the vinyl mode is deactivated, turning the jog wheel, will only
perform the pitch bend function.
- SHIFT+Turn Jog Wheel: Performs a needle search (fast forward) in the track.
The jog wheel display shows information about the track currently loaded in
the deck. ( USB A/B, Deck 1/3 2/4, Time, BPM, Pitch, Pitchrange, continuous
LED display for the position in the track and rotating track marker)
Controls the parameter functions, depending on the active mode. (Decrease)
- SHIFT+Param 1<: Controls second level of parameter function,
Depending on the active mode. (Decrease)
Controls the parameter function, depending on the active mode. (Increase)
- SHIFT+Param 1>: Controls second level of parameter function,
Depending on the active mode. (Increase)
Activates second level functions, according to the labelling of the unit.
Toggles between the decks on the respective player.
- Left player: Deck 1/3
- Right player: Deck 2/4
Activates the Sync function.
- SHIFT+Sync: Deactivates the Sync function.
- During playback: The track returns to the temporary cue point and stops.
- In pause mode: Sets a new temporary cue point at the current position.
If the Cue button is pressed again, the temporary cue is
played as long as Cue is held.
- SHIFT+CUE: The playhead returns to the beginning of the track or loads the
previous Track if the button is pressed for more than one second
during playback.
Activates playback/pause
- SHIFT+CUE: Triggers the temporary cue and the playhead
will continue from that point.
19
