- Page 1 LIFT ERGORISE – SIT / STAND WORKSTATION VERSION INSTRUCTION MANUAL MAX Weight 20 lbs (9 KG) CAUTION: DO NOT EXCEED MAXIMUM LISTED WEIGHT CAPACITY. SERIOUS INJURY OR PROPERTY DAMAGE MAY OCCUR! LIFT-MU (Manual) = ES15001-ESI-150910vA Reduce.Reuse.Recycle...
-
Page 2: Parts List
PARTS LIST 1 pcs 1 pcs 1 pcs 2 pcs 1 pcs M6 x 25 mm 2 pcs 1 pcs 1 pcs 1 pcs 1 pcs 1 pcs 1 pcs 1 pcs 1 pcs 2 pcs M6 x 95 mm M4 x 55 mm Extra Replacement (1 pcs) Included... - Page 3 STEP 1 M4 – Allen Wrench M6 x 35 mm 2 pcs STEP 2 M6 x 8 mm 4 pcs...
- Page 4 STEP 3 M4 – Allen Wrench M6 x 10 mm 8 pcs 10mm Screws ONLY Use of Longer Screws will Damage Work Surface STEP 4 M6 x 8 mm 2 pcs...
- Page 5 STEP 4 M4 – Allen Wrench M6 x 18 mm 4 pcs M6 x 35 mm 2 pcs...
- Page 6 STEP 5 M4 – Allen Wrench MAXIMUM Surface Thickness 0.75 in – 3.3 in 20mm – 80mm M6 x 10 mm 3 pcs Tighten Clamp with 5/8” Socket Wrench (Not Included)
- Page 7 STEP 6 Press Lever Down to Raise Center Support Post...
- Page 8 STEP 7 M4 – Allen Wrench M6 x 8 mm 4 pcs M6 x 8 mm 4 pcs 24” Depth 30” Depth...
- Page 9 STEP 8 RIGHT OPTION 1: HANDED LEFT OPTION 2: HANDED...
-
Page 10: Step 9 - Load Adjustment
STEP 9 – LOAD ADJUSTMENT Depress Lever and Adjust to 45 degrees STEP 9 – LOAD ADJUSTMENT M4 – Allen Wrench DO NOT OVERTIGHTEN MAX (+) ADJUSTMENT Load Load... -
Page 11: Adjust Tension
STEP 10 - TENSION LEVER ADJUSTMENT Adjust TENSION LEVER for Lift and Response Rate Adjust Lever Tension Screw Clockwise (Right) Lock the Tension Adjustment Screw in Place with Lock Washer... - Page 12 NEED HELP? PLEASE CONTACT Phone: 1-800-833-3746 Email: customerservice@esiergo.com Web: www.esiergo.com ESI Ergonomic Solutions © 2015...
