ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
CM7517T
DIFFICULT
Tools Required For Assembly:
Allen Wrench
Phillips Screwdriver
2 PERSONS RECOMMENDED
Page 1 of 5
(Included)
(Not Included)
Rev: 18- 10 - 03
Advertisement
Related Manuals for Furniture of America CM7517T
Summary of Contents for Furniture of America CM7517T
- Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM7517T ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that Allen Wrench shows the degree of effort needed in (Included) assembling a specific product (with 1 being easy and 5 being difficult).
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 5...
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. Parts List Hardware List #A x 6pcs #1 x 1pc Headboard Bolt Ø5/16" x 1-3/8" #B x 6pcs #2 x 2pcs Lock Washer Ø5/16"...
- Page 4 #A x 6pcs #B x 6pcs #C x 6pcs Align HB legs (#2R/L) to the headboard (#1), then secure by using bolts (#A) with washers (#B,C). Align and hook the side rails (#3) to the latch of the headboard (#1) and footboard (#4). Page 4 of 5...
- Page 5 Align slats (#5) to side rails (#3), then secure by using screws (#E). #E x 8pcs ASSEMBLY IS COMPLETED Page 5 of 5...
- Page 6 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM7517F ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that Allen Wrench shows the degree of effort needed in (Included) assembling a specific product (with 1 being easy and 5 being difficult).
- Page 7 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 5...
- Page 8 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. Parts List Hardware List #1 x 1pc #A x 6pcs Headboard Bolt Ø5/16" x 1-3/8" #2 x 2pcs #B x 6pcs Headboard leg(L&R) Lock Washer Ø5/16"...
- Page 9 Align HB legs (#2R/L) to the headboard (#1), then secure by using bolts (#A) with washers (#B,C). #A x 6pcs #B x 6pcs #C x 6pcs Align and hook the side rails (#3) to the latch of the headboard (#1) and footboard (#4). Page 4 of 5...
- Page 10 Attach support legs (#6) to slats (#5), then adjust the leveler on support legs (#6) according to ground level. Align slats (#5) to side rails (#3), then secure by using screws (#E). #E x 8pcs Page 5 of 5...
