Page 1: Installation Instructions
Installation instructions Important - Save for the local electrical inspector’s use. EKWE / EKWH... -
Page 2: Table Of Contents
Dimensions and distances ....4 An overview of the honeycomb dimensions ..5 Cooking unit EKWH 320.14 / 320.18 / 320.18 Z Control unit EKWE 320.W / S Installing the honeycombs/honeycomb cooking units 6 Instructions for installing the honeycombs... -
Page 3: Safety Instructions
Safety instructions General Installation conditions Installation instructions - EKWE/EKWH - USA • Turn off the power source before installing the honeycomb cooktop. • Do not operate the appliance until it has been properly installed within cabinetry or into an opening in the countertop! •... -
Page 4: Dimensions And Distances
40 mm (1-9/16"). The third side may only be positioned next to an appliance of equal height. We recommend a horizontal distance between the appliance and mounted cabinets of at least 300 mm (12") for ergonomical reasons. Installation instructions - EKWE/EKWH - USA... -
Page 5: An Overview Of The Honeycomb Dimensions
Cooking unit EKWH 320.14 / 320.18 / 320.18 Z Glass ceramic panel Silicon bonding compound Metal support View from bottom Control unit EKWE 320.W / S Glass ceramic panel Silicon bonding compound Metal support View from Metal base panel bottom... -
Page 6: Installing The Honeycombs/Honeycomb Cooking Units
• The plastic coating or veneer must be applied with a heat-resistant adhesive (160 °C / 320 °F). This adhesive prevents the surfaces from warping or working loose. especially on the narrow sides of the fitted cupboards. Installation instructions - EKWE/EKWH - USA... -
Page 7: Measuring And Marking Out The Worktop Cut-Outs
Measuring the cut-out Correct: Allow an extra 1-3 mm for the silicon seal Incorrect: Allow an extra 1-3 mm round each honeycomb Installation instructions - EKWE/EKWH - USA Dimensioned drawings on CD-ROM Dimensioned drawings of lay-out options for the honeycombs are available from Küppersbusch. -
Page 8: Marking Out The Cut-Out
* Only permissible for worktops with a depth of at least 650 mm (25-9/16"). For the EKWE 320 control element, no opening, only a round cut-out for the bottom pan has been provided for. When selecting a solid surface worktop for your Küppersbusch Honeycomb... -
Page 9: Cut-Out In Stone Worktops
Cutting out the installation area and the openings Replacing the piece cut out into the worktop Installation instructions - EKWE/EKWH - USA The cut-out can be made as for worktops made of solid surface. (Trimming the cut-out for the honeycomb cooking zones) See “Cutout in worktops made of solid surface”. - Page 10 On being used the honeycomb units may no longer be clamped since this may result in stress cracking. The clamps are only for adjusting during assembly or for fastening purposes if the whole worktop, with honeycombs installed, is to be transported. Installation instructions - EKWE/EKWH - USA...
-
Page 11: Electrical Connection
Electrical connection Installation instructions - EKWE/EKWH - USA When installing the power module, a minimum distance to the ground of 300 mm (11-13/16") is to be observed in accordance with the drawing on page 6. • Observe all guidelines and regulations from your local electric company. -
Page 12: Connecting The Honeycomb Cooking Units To The
Only the EKWH 320.14, EKWH 320.18 and EKWH 320.18Z honeycomb cooking units may be connected to the EKWE 320 control honeycomb. A dangerous situation may otherwise arise. Apart from the first connection socket the sockets for the control honeycomb are covered with adhesive tape from installation side. -
Page 13: Programming The Control Honeycomb In Accordance With The Cooking Zone Layout
Programming the control honeycomb in accordance with the cooking zone layout Installation instructions - EKWE/EKWH - USA Since the control honeycombs can be used for any kind of honeycomb layout, the control honeycomb has to be informed on which cooking zones have actually been installed and on the final layout. - Page 14 The final step is automatic calibration of the pan-on detection. The LED displays will indicate “ ”. Once this display has switched off the honeycomb can be Installation instructions - EKWE/EKWH - USA...
- Page 15 Installation instructions - EKWE/EKWH - USA...
- Page 16 ÜPPERSBUSCH 4920 West Cypress Street, Tampa, Florida 33607 Telephone: 813-288-8890 Fax: 813-288-8604 Customer Care line: 1 - 800 - 459 - 0844 www.kuppersbuschusa.com TEKA USA, I ÜPPERSBUSCH IS A BRAND OF...
