Page 2
Küppersbusch-Kundendienst Garantiebedingungen Zentrale Kundendienst- / Ersatzteilanforderung Zusätzlich zu seinen Gewährleistungsansprüchen aus seinem Kaufvertrag mit dem Händler leisten wir dem Endabnehmer direkt Garantie für Küppersbusch-Hausgeräte. Der Umfang unserer Deutschland: Garantie wird nachstehend geregelt: 1. Mängel am Gerät, die nachweislich auf einem Material- und/oder Küppersbusch Hausgeräte GmbH Herstellungsfehler beruhen, werden nach Maßgabe der folgenden Küppersbuschstraße 16...
Sehr geehrte Kundin, sehr geehrter Kunde, vielen Dank für Ihre Entscheidung zum Kauf eines lnduktionskochfeldes von KÜPPERSBUSCH. Bitte lesen Sie die Informationen in diesem Heft sorgfältig durch bevor Sie Ihr Kochfeld in Betrieb nehmen. Sie finden hier wichtige Hinweise für Ihre Sicherheit, den Gebrauch, die Pflege und die Wartung des Gerätes, damit Sie lange Freude an Ihrem Gerät haben.
SICHERHEIT Sicherheitshinweise vor der Inbetriebnahme • Alle Teile der Verpackung entfernen. • Das Gerät darf nur von einem Elektrofachmann eingebaut und angeschlossen werden. Der Hersteller kann nicht verantwortlich gemacht werden für Schäden, die durch Fehler beim Einbauen oder Anschließen verursacht werden. Benutzen Sie das Gerät nur im eingebauten Zustand.
• Überhitzte Fette und Öle entzünden sich schnell. Wenn Sie Speisen in Fett oder Öl (z.B. Pommes Frites) zubereiten, sollten Sie den Kochvorgang beobachten. • Wenn Sie kochen und braten, werden die Kochzonen heiß. Hüten Sie sich deshalb vor Verbrennungen während und nach Benutzung des Gerätes.
• Glaskeramik ist gegen Temperaturschocks unempfindlich und sehr widerstandsfähig, jedoch nicht unzerbrechlich. Besonders spitze und harte Gegenstände, die auf die Kochfläche fallen, können sie beschädigen. • Töpfe und Ränder nicht an der Scheibe anstoßen. • Die Kochzonen nicht mit leerem Kochgeschirr benutzen. •...
• Reparaturen am Gerät dürfen nur von Fachleuten durchgeführt werden. • WARNUNG: Wenn die Glasoberfläche gesprungen ist, ist das Gerät auszuschalten, um die Gefahr eines elektrischen Schlages zu vermeiden. Schutz vor weiteren Gefahren • Achten Sie darauf, dass das Kochgeschirr immer zentriert auf der Kochzone plaziert ist.
BEDIENUNG DES KOCHFELDES Anzeige Anzeige Anzeige Benennung Beschreibung Null Die Kochzone ist aktiviert 1…9 Leistungsstufe Einstellung der Leistung Topferkennung Kein Topf nicht aufgesetzt oder nicht geeignet Ankochautomatik Höchste Leistung + Ankochen Fehleranzeige Fehler der Elektronik Restwärme Kochzone ist heiss Booster (Powerstufe) Die Booster Leistung ist aktiviert.
Wenn das Kochgeschirr für die Induktion nicht geeignet ist, erscheint die Anzeige [ U ]. Funktion der Sensorschaltfelder Das Kochfeld wird über Sensortasten gesteuert. Diese reagieren auf leichte Berührungen des Glases mit dem Finger. Wenn Sie die Tasten etwa eine Sekunde lang berühren, werden die Steuerbefehle ausgeführt.
Topferkennung Die Topferkennung gewährleistet eine sehr hohe Sicherheit: • Die Induktion funktioniert nicht, wenn sich kein Kochgeschirr auf der Kochzone befindet oder wenn ein nicht für die Induktion geeigneter Topf benutzt wird. In diesem Falle kann die Leistungsstufe nicht erhöht werden und das Symbol [ U ] erscheint in der Anzeige. Das [ U ] verschwindet, wenn ein Topf auf die Kochzone gestellt wird.
• Automatische Steuerung der “ Booster Funktion “ (Powermanagement): Je zwei Kochzonen sind -technisch bedingt- zu einem Modul zusammengefasst und verfügen über eine maximale Leistung. Wird dieser Leistungsbereich beim Einschalten einer hohen Kochstufe oder der Powerfunktion überschritten, reduziert das Powermanagement die Kochstufe der zugehörigen Modul-Kochzone.
• Automatisches Ausschalten: Nach Ablauf der programmierten Kochdauer wird [ 000 ] blinkend angezeigt und ein akustisches Signal wird erfolgen. Um den Signalton und das Blinken abzuschalten, brauchen Sie nur Taste [ - ] oder [ + ] zu betätigen. Ankochautomatik Alle Kochzonen sind mit einer Ankochautomatik bestückt.
Memoryfunktion Nach dem Ausschalten des Kochfeldes bleiben die letzten Einstellungen gespeichert. Durch die Memory-Funktion können Sie diese Werte wieder aktivieren. Folgende Einstellungen können durch die Memory-Funktion wieder aktiviert werden: • Leistungsstufen der Kochzonen. • Timer- Einstellungen der Kochzonen. • Einstellungen der Ankochautomatik Memory-Funktion aufrufen: •...
Automatische Brücke und Brücken-Funktion Diese Funktion erlaubt zwei Kochzonen für einen Kochvorgang zusammen zu schalten. Vorgang Bedienfeld Anzeige Einschalten der Kochmulde Auf [ ] drücken [ 0 ] Brücke einschalten Auf die beiden [ ] drücken [ 0 ] und [ oder eine große Pfanne auf beiden Zonen legen die man Brücken möchte...
KOCHEMPFEHLUNGEN Kochgeschirr Geeignete Materialien: Stahl, emaillierter Stahl, Gusseisen, Edelstahl mit magnetischem Boden, Aluminium mit magnetischem Boden Nicht geeignete Materialien: Aluminium und Edelstahl ohne magnetischen Boden, Kupfer, Messing, Glas, Steingut, Porzellan Die Topfhersteller geben meist an, ob ihre Produkte induktionsgeeignet sind. So überprüfen Sie die Induktionskompatibilität der Töpfe: •...
• Den Kundendienst anrufen. Eine Kochzone oder das gesamte Kochfeld schaltet ab: • Die Sicherheits-Abschaltung hat ausgelöst. • Es ist vergessen worden, eine Kochstelle abzuschalten. • Es sind mehrere Sensortasten bedeckt. • Der Topf ist leer und überhitzt. • Durch eine Überhitzung hat die Elektronik automatisch die Leistung reduziert oder bzw. automatisch abgeschaltet Das Kühlgebläse läuft nach dem Ausschalten weiter: •...
Der Benutzer muss darauf achten dass die in seinem Wohnsitz geltenden Normen eingehalten werden. Dichtung Einbau: Die Dichtung (2) nach Abnehmen der Schutzfolie (3) mit 2 mm Abstand von der Außenkannte des Glases aufkleben. Einbau : • Einbaudimensionen: KI9800.0SF 910 mm 410 mm 890 mm 390 mm 48 mm KI9800.0SR...
• Der Abstand vom Ausschnitt bis zu einer Wand und/oder einem Möbelstück muss mindestens 40 mm betragen. • Dieses Gerät entspricht bezüglich des Schutzes gegen Feuergefahr dem Typ Y. Nur Geräte dieses Typs dürfen einseitig an nebenstehende Hochschränke oder Wände eingebaut werden.
Page 21
• Das Gerät muss durch Trenneinrichtungen allpolig vom Netz abgeschaltet werden können. Im abgeschalteten Zustand muss ein Kontaktabstand von 3 mm vorhanden sein. Als geeignete Trennvorrichtungen gelten LS-Schalter, Sicherungen und Schütze. • Die Installation muss durch Sicherungen geschützt sein. Elektrische Kabel müssen durch Einbauten abgedeckt sein.
Page 22
Dear customer, Thank you for having chosen a KÜPPERSBUSCH induction hob. In order to install properly your appliance and to make the best use of it, please read this entire instruction manual carefully. SUMMARY SAFETY ............................23 ...................... 23 RECAUTIONS BEFORE USING ........................
SAFETY Precautions before using • Unpack all the materials. • The installation and connecting of the appliance have to be done by approved specialists. The manufacturer cannot be responsible for damage caused by building-in or connecting errors. • To be used, the appliance must be well-equipped and installed in a kitchen unit and an adapted and approved work surface.
• In general do not place any metallic object except heating containers on the glass surface. In case of untimely engaging or residual heat, this one may heat, melt or even burn. • Never cover the appliance with a cloth or a protection sheet. This is supposed to become very hot and catch fire.
Precautions in case of appliance failure • If a defect is noticed, switch off the appliance and turn off the electrical supplying. • If the ceramic glass is cracked or fissured, you must unplug the appliance and contact the after sales service. •...
DESCRIPTION OF THE APPLIANCE Technical characteristics Type KI9800.0SF KI9800.0SR Total power 7400 W Energy consumption for the hob EC 181.9 Wh/kg Heating zones 250x182 mm Minimum detection Ø 100 mm Nominal power* 2100 W Booster power* 2600/3700 W Standardised cookware category** Energy consumption EC 188.1 Wh/kg...
USE OF THE APPLIANCE Display Display Designation Description Zero The heating zone is activated. 1…9 Power level Selection of the cooking level. No pan detection No pan or inadequate pan. Heat accelerator Automatic cooking. Error message Electronic failure. Residual heat The heating zone is hot.
“SLIDER” zone: to set power and timer values The slider works like a touch key. Once your finger is placed onto the slider, you can slide to the right hand or to the left hand side, in order to adjust the displayed value. As soon as the expected value has been reached, you can remove your finger from the slider.
Residual heat indication After the switching off of a heating zone or the complete stop of the hob, the heating zones are still hot. This is indicated by displaying [ H ] symbol. The symbol [ H ] disappears when the heating zones may be touched safely. As long as the residual heat indicators are on, don’t touch the heating zones and don’t put any heat sensitive object on them.
• Setting and modification of the cooking time : Action Control panel Display Select the power level slide on the “SLIDER“ [ 1 ] to [ P ] Select theTimer Press simultaneously key [ - ] and [ + ] Timer display on from the timer until the desired display is on Decrease the time...
Action Control panel Display Power level selection slide on the “SLIDER“ [ 0 ] to [ 9 ] Automatic cooking Selected power time (Min:S) 00:40 01:12 02:00 02:56 04:16 07:12 02:00 03:12 - : - Stop&Go function This function brakes all the hob’s cooking activity temporarily and allows restarting with the same settings.
« Keep warm » Function This function allows the hob to reach and maintain automatically a temperature of approximately 42°C, 70°C or 94°C. This will avoid liquids overflowing and burning on the bottom of the pan. • To engage, to start the function « Keep warm » : Action Control panel Display...
Grill Function This function allows the optimal use of the grill plate “zub.-Nr. 1303” with combining two areas and using appropriate powers. Action Control panel Display Activate the hob Press display [ [ 0 ] put the grill plate on the 2 zones to use ] blink Activate the Grill...
COOKING ADVICES Pan quality Suitable materials: steel, enamelled steel, cast iron, ferromagnetic stainless-steel, aluminium with ferromagnetic bottom Not suitable materials: aluminium and stainless-steel without ferromagnetic bottom, cupper, brass, glass, ceramic, porcelain The cookware manufacturers usually specify whether their products are suitable to induction. To check if pans are compatible: •...
One or all cooking zone cut-off: • The safety system functioned. • You forgot to cut-off the cooking zone for a long time. • One or more sensitive keys are covered. • The pan is empty and its bottom overheated. •...
Stick the gasket (2) two millimeters from the external edge of the glass, after removing the protection tape (3). Aeration Fitting - installing: • Cut out sizes of the worktop: KI9800.0SF 910 mm 410 mm 890 mm 390 mm 48 mm...
• Ensure that there is a distance of 40 mm between the hob and the wall or sides. • The hobs are classified as “Y” class for heat protection. Ideally the hob should be installed with plenty of space on either side. There may be a wall at the rear and tall units or a wall at one side.
Page 39
• The electrical circuit must be separated from the network by adapted devices, for example: circuit breakers, fuses or contactors. • If the appliance is not fitted with an accessible plug, disconnecting means must be incorporated in the fixed installation, in accordance with the installation regulations. •...
Page 40
Chère cliente, cher client, Nous vous remercions de la confiance que vous nous avez accordée en choisissant une table de cuisson à induction de la marque KÜPPERSBUSCH. Afin de bien connaître cet appareil, nous vous recommandons de lire attentivement cette notice d’utilisation et de la conserver pour toute consultation ultérieure.
SECURITE Précautions avant utilisation en cuisson • Retirez toutes les parties de l’emballage. • L’installation et le branchement électrique de l’appareil sont à confier à des spécialistes agrées. Le fabricant ne saurait être tenu responsable des dommages résultant d’une erreur d’encastrement ou de raccordement.
• Assurez-vous qu’aucun câble électrique d’appareil fixe ou mobile ne vienne en contact avec la vitre ou la casserole chaude. • Les objets magnétisables (cartes de crédits, disquettes informatiques, calculatrices) ne doivent pas se trouver à proximité immédiate de l’appareil en fonction. •...
• Eviter que le sucre, les matières synthétiques ou une feuille d’aluminium ne touchent les zones chaudes. Ces substances peuvent au refroidissement provoquer des cassures ou d’autres modifications de la surface vitrocéramique: Eteindre l’appareil et enlevez-les immédiatement de la zone de cuisson encore chaude (attention : risque de brûlures).
Autres protections • Assurez-vous que le récipient de cuisson soit toujours centré sur la zone de cuisson. Le fond de la casserole doit autant que possible couvrir la zone de cuisson. • Pour les utilisateurs portant un régulateur de rythme cardiaque, le champ magnétique pourrait influencer son fonctionnement.
DESCRIPTION DE L’APPAREIL Caractéristiques techniques Type KI9800.0SF KI9800.0SR Puissance Totale 7400 W Consommation d’énergie de la table de cuisson EC 181.9 Wh/kg Foyer de puissance 250x182 mm Détection minimum Ø 100 mm Puissance nominale* 2100 W Puissance du booster* 2600/3700 W Catégorie de la casserole standard**...
UTILISATION DE L’APPAREIL Affichage Affichage Désignation Description Zéro La zone de chauffe est activée. 1…9 Niveau de puissance Choix du niveau de cuisson. Non détection de casserole Récipient manquant ou inapproprié. Accélérateur de chauffe Cuisson automatique. Message d’erreur Défaut de circuit électronique. Chaleur résiduelle La zone de cuisson est chaude.
Touches sensitives Votre appareil est équipé de touches sensitives permettant de commander les différentes fonctions. Un effleurage pendant 1 seconde de la touche active leur fonctionnement. Cette activation est validée par un voyant, un affichage et/ou par un signal sonore. Dans le cas d’une utilisation générale n’appuyez que sur une seule touche à...
Détection de récipient La détection de récipient assure une sécurité parfaite. L’induction ne fonctionne pas : • Lorsqu’il n’y a pas de récipient sur la zone de cuisson ou lorsque ce récipient est inadapté à l’induction. Dans ce cas il est impossible d’augmenter la puissance et dans l’afficheur le symbole [ U ] apparaît.
Fonction minuterie La minuterie peut être affectée simultanément à tous les foyers de cuisson et ceci avec des réglages de temps de minuterie différents (de 1 à 999 minutes) pour chacune des zones. • Réglage ou modification de la durée de cuisson : Action Bandeau de commande Afficheur...
Programmation d’automatisme de cuisson Toutes les zones de cuisson sont équipées d’un dispositif de cuisson automatique. La zone de cuisson se met en marche à pleine puissance pendant un certain temps, puis réduit automatiquement sa puissance sur le niveau présélectionné. •...
Fonction « Memory » Après avoir éteint la table [ ], il est possible de rappeler les derniers réglages sélectionnés : • Etat de cuisson de toutes les zones de cuisson (puissance). • Minutes et secondes des zones de cuisson programmées par les minuteries. •...
Fonction Grill Cette fonction permet d’utiliser de façon optimal le grill « Zub.-Nr. 1303 » en combinant 2 zones et en utilisant des puissances appropriées. Action Bandeau de commande Afficheur Mise en route appuyer sur [ [ 0 ] poser le grill sur les 2 zones à...
CONSEILS DE CUISSON Qualité des casseroles Matériaux adaptés : acier, acier émaillé, fonte, inox à fond ferromagnétique, aluminium à fond ferromagnétique. Matériaux non adaptés : aluminium et inox à fond non ferromagnétique, cuivre, laiton, verre, céramique, porcelaine. Les fabricants spécifient si leurs produits sont compatibles induction. Pour vérifier si des casseroles sont compatibles : •...
Exemples de réglage des puissances de cuisson (Les valeurs ci-dessous sont indicatives) Faire fondre Sauces, beurre, chocolat, gélatine 1 à 2 Réchauffer Plats pré-cuisinés Gonfler Riz, pudding et plats cuisinés 2 à 3 Décongélation Légumes, poisson, produits congelés 3 à 4 Vapeur Légumes, poissons, viande Pommes de terre à...
L’une des zones ou l’ensemble du plan de cuisson se déclenche : • Le déclenchement de sécurité a fonctionné. • Celui-ci s’actionne dans le cas où vous avez oublié de couper une des zones de chauffe. • Il s’enclenche également lorsqu’une ou plusieurs touches sensitives sont couvertes. •...
Coller le joint (2) sur le rebord de la table à 2mm du bord externe, après avoir ôté la feuille de protection (3). Aération Encastrement : • Dimension de découpe : KI9800.0SF 910 mm 410 mm 890 mm 390 mm 48 mm...
• La distance entre la table de cuisson et le mur doit être au minimum de 40mm. • La table de cuisson est un appareil qui appartient à la classe de protection « Y ». Lors de son encastrement, une paroi d’armoire haute ou un mur peut se trouver sur l’un des côtés et sur la face arrière.
Page 58
• Cet appareil doit être séparé du secteur par un dispositif de sectionnement omnipôles. Lorsque celui-ci est ouvert (déclenché), un écartement de 3mm doit être assuré. • Le circuit électrique doit être séparé du réseau par des dispositifs appropriés, par exemple les disjoncteurs, les fusibles, les disjoncteurs différentiels et les contacteurs.
