Summary of Contents for Küppersbusch EKIF9960.1

  • Page 1 BEDIENUNGSANWEISUNG mit Montageanweisungen Instructions for use and installation Instructions d’utilisation et d’installation EKIF9960.1 EKI9960.1F...
  • Page 2 Küppersbusch-Kundendienst Garantiebedingungen Zentrale Kundendienst- / Ersatzteilanforderung Zusätzlich zu seinen Gewährleistungsansprüchen aus seinem Kaufvertrag mit dem Händler leisten wir dem Endabnehmer direkt Garantie für Küppersbusch-Hausgeräte. Der Umfang unserer Deutschland: Garantie wird nachstehend geregelt: 1. Mängel am Gerät, die nachweislich auf einem Material- und/oder Küppersbusch Hausgeräte GmbH Herstellungsfehler beruhen, werden nach Maßgabe der folgenden Küppersbuschstraße 16...
  • Page 3: Table Of Contents

    Dear customer, Thank you for having chosen a KÜPPERSBUSCH induction hob. In order to install properly your appliance and to make the best use of it, please read this entire instruction manual carefully. SUMMARY SAFETY............................21 ...................... 21 RECAUTIONS BEFORE USING ........................
  • Page 4: Safety

    SAFETY Precautions before using • Unpack all the materials. • The installation and connecting of the appliance have to be done by approved specialists. The manufacturer cannot be responsible for damage caused by building-in or connecting errors. • To be used, the appliance must be well-equipped and installed in a kitchen unit and an adapted and approved work surface.
  • Page 5: Precautions Not To Damage The Appliance

    Precautions not to damage the appliance • Raw pan bottoms or damaged saucepans (not enamelled cast iron pots,) may damage the ceramic glass. • Sand or other abrasive materials may damage ceramic glass. • Avoid dropping objects, even little ones, on the vitroceramic. •...
  • Page 6: Description Of The Appliance

    Booster Type Total Power diameter heating zone Power* Power* detection EKIF9960.1 6 Cooking zones 11100 W 2100 W 2600/3700 W 100 mm EKI9960.1F 220x180 mm * Average measured power. According to the form, size and quality of the pan, the maximum measured power can exceed these figures.
  • Page 7: Ventilation

    Ventilation The cooling system is fully automatic. The cooling fan starts with a low speed when the heat created by the electronic system reaches a certain level. The ventilation starts its high speed when the hob is intensively used. The cooling fan reduces its speed and stops automatically when the electronic circuit is cooled enough.
  • Page 8: "Slider" Zone: To Set Power And Timer Values

    “SLIDER” zone: to set power and timer values The slider works like a touch key. Once your finger is placed onto the slider, you can slide to the right hand or to the left hand side, in order to adjust the displayed value. As soon as the expected value has been reached, you can remove your finger from the slider.
  • Page 9: Residual Heat Indication

    Residual heat indication After the switching off of a heating zone or the complete stop of the hob, the heating zones are still hot. This is indicated by displaying [ H ] symbol. The symbol [ H ] disappears when the heating zones may be touched safely. As long as the residual heat indicators are on, don’t touch the heating zones and don’t put any heat sensitive object on them.
  • Page 10: Timer

    Timer The timer is able to be used simultaneous with all heating zones and this with different time settings (from 1 to 999 minutes) for each heating zone. • Setting and modification of the cooking time : Action Control panel Display Select the power level slide on the “SLIDER“...
  • Page 11: Automatic Cooking

    Automatic cooking All the cooking zones are equipped with an automatic cooking device. The cooking zone starts at full power for a certain time, and then reduces automatically its power to the pre-selected level. • Start-up : Action Control panel Display Power level selection slide on the “SLIDER“...
  • Page 12: Keep Warm » Function

    « Keep warm » Function This function allows the hob to reach and maintain automatically a temperature of approximately 42°C, 70°C or 94°C. This will avoid liquids overflowing and burning on the bottom of the pan. • To engage, to start the function « Keep warm » : Action Control panel Display...
  • Page 13: Control Panel Locking

    Control panel locking To avoid accidentally activating or interfering with the settings of the cooking zones, for instance when cleaning, the control panel can be locked (with exception of the On/Off key [ Action Control panel Display Locking the hob Press on [ ] 6s locking light blinkt...
  • Page 14: Cooking Advices

    COOKING ADVICES Pan quality Suitable materials: steel, enamelled steel, cast iron, ferromagnetic stainless-steel, aluminium with ferromagnetic bottom Not suitable materials: aluminium and stainless-steel without ferromagnetic bottom, cupper, brass, glass, ceramic, porcelain The cookware manufacturers usually specify whether their products are suitable to induction. To check if pans are compatible: •...
  • Page 15: Examples Of Cooking Power Setting

    Examples of cooking power setting (the values below are indicative) 1 to 2 Melting Sauces, butter, chocolate, gelatine Reheating Dishes prepared beforehand 2 to 3 Simmering Rice, pudding, sugar syrup Defrosting Dried vegetables, fish, frozen products 3 to 4 Steam Vegetables, fish, meat 4 to 5 Water...
  • Page 16: What To Do In Case Of A Problem

    WHAT TO DO IN CASE OF A PROBLEM The hob or the cooking zone doesn’t start-up: • The hob is badly connected on the electrical network. • The protection fuse cut-off. • The looking function is activated. • The sensitive keys are covered of grease or water. •...
  • Page 17: Installation Instructions

    Stick the gasket (2) two millimeters from the external edge of the glass, after removing the protection tape (3). Aeration Fitting - installing: • Cut out sizes of the worktop: EKIF9960.1 898 mm 518 mm 750 mm 490 mm 48 mm EKI9960.1F...
  • Page 18: Electrical Connection

    • The piece of furniture or the support in which the hob is to be fitted, as well as the edges of furniture, the laminate coatings and the glue used to fix them, must be able to resist temperatures of up to 75 °C. •...
  • Page 19 Caution! This appliance must only be connected to a network 230 V~ 50/60 Hz. Always connect the earth wire. Respect the connection diagram. The connection box is located underneath at the back of the hob casing. To open the cover use a medium screwdriver.
  • Page 21 17487/0...
