HDMI Matrix Switcher
User Manual
Model :
HE04M
4 x 4 HDMI (HDBaseT)CAT5e Matrix Switcher
Smart Cabling & Transmission Corp.
V1.0_1803150

Advertisement

loading
Need help?

Need help?

Do you have a question about the HE04M and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SC&T HE04M

Summary of Contents for SC&T HE04M

  • Page 1 HDMI Matrix Switcher User Manual Model : HE04M 4 x 4 HDMI (HDBaseT)CAT5e Matrix Switcher Smart Cabling & Transmission Corp. V1.0_1803150...
  • Page 2 Introduction HE04M is a 4 x 4 HDMI matrix switcher which supports the resolution up to 1080p@60Hz 12bit. The matrix can not only route 4 sources to 4 displays but also extend 4 HDMI and IR signal for 100M over HDBaseT™...
  • Page 3 User Manual HE04M 2.0 HE04M Connection View * Under dual Output connection: local HDMI port or remote RJ45 termination Once you link both HDMI & HDBaseT connection, the output will be effected HDMI port only. For HDBaseT active output, you must disconnection HDMI output link.

  • Page 4: Keypad And Leds

    User Manual HE04M 3.0 Keypad and Leds 3.1 Back Panel Switch POWER Light on Power on Light off Power off 3.2 Front LED Indication BLUE Power on Standby LED off Power Off INPUT 1, 2, 3, 4 BLUE Presence signal indication...

  • Page 5: Operation

    User Manual HE04M Channel Setting on Main Screen The Matrix will jump to channel setting screen after 10 seconds, press the MENU key to enter the main. OUT 1 2 3 4 1 2 3 4 Main MENU Option *1. SWITCH *2.
  • Page 6 User Manual HE04M 4.0 LCM Main MENU Function Operation 4.1 Switch (Default: 1 2 3 4) OUTPUT 1 2 3 4 INPUT 1 2 3 4 This function is used to switch the input/output port. Enter the SWITCH menu. Press the ENTER key, then the LCM second line INPUT will flash.

  • Page 7: Matrix Mode

    User Manual HE04M 4.2 RS-232 (Default: FIX MODE) HDBaseT RS-232 extender function works in two mode. Enter RS-232 MENU, press ENTER. The * will flash, then press UP or DOWN button to select FIX MODE or MATRIX MODE. Press ENTER key to confirm setting.
  • Page 8 User Manual HE04M RS-232 SETTING : MATRIX MODE 4.3 IR TX (From matrix to remote locations) (Default IR TX: O O O O) This function setup the IR signal whether from MATRIX, by IR Rx input jack, is sent to HDBaseT ports. Setting O the transmission is enabled, setting X transmission is off.
  • Page 9 User Manual HE04M 4.4 IR RX (Default IR RX: O O O O) This function setup the IR signal whether from HDBaseT location is sent to MATRIX to control local device through the IR Tx output jack. Setting O the transmission is enabled, setting X transmission is off.
  • Page 10 User Manual HE04M These settings on IR01 remote control have to be done the first time you use the IR01 or when you change the batteries. IR01 HE04M ＋ ＋ HDBaseT - 1 HDBaseT - 2 ＋ HDBaseT - 3 HDBaseT - 4 ＋...
  • Page 11 User Manual HE04M IR01 HE04M ＋ 4.7 Ethernet * IP Address Subnet Mask Gateway DHCP Client Media Type MAC Filter IP Address: (Default: 192.168.0.200) IP Address 192.168. 0.200 This function can be setup MATRIX host intranet ”IP Address”, press the ENTER, the left-most number of second row will flash, then press the UP or DOWN button to change the numbers, , press LEFT or RIGHT to move to another location, the move to a position number will flash, press ENTER to complete the setting.
  • Page 12 User Manual HE04M Gateway: (Default 192.168.0.1) Gateway 192.168. 0. 1 This function can be setup MATRIX host intranet “Gateway”, press the ENTER, the left-most number of second row will flash, then press the UP or DOWN button to change the numbers Press the ENTER, , press LEFT or RIGHT to move to another location, the move to a position number will flash, press ENTER to complete the setting.

  • Page 13: Copy Mode

    User Manual HE04M 4.8.1 Build-in Mode This mode supports video resolution 480p, 720p, 1080i / p at 24/50/60Hz, support LPCM two-channel audio and 5.1 channel . After enter BUILD-IN MODE menu, press UP or DOWN key to select LPCM-2CH or LPCM-5.1CH, then press ENTER to confirm setting.

  • Page 14: Hdmi Input

    HDMI INPUT. 4.8.4 PC EDID Mode In this mode you could upload EDID file from RS232 or RJ45 port of PC to MATRIX, please refer user manual of EDID Loader 4.9 Version Display HE04M Matrix firmware version...
  • Page 15 User Manual HE04M 4.10 Key lock Panel button/IR remote lock function is to avoid any wrong button press. Under key lock mode press “POWER + MENU” to unlock 4.11 Scene SCENE function provides 10 sets of channel setting to fast reload for different application.
  • Page 16 User Manual HE04M -Power+2 enable to work on Output 3 -Power+3 enable to work on Output 4 Warning These settings have to be done the first time you use the IR01 or when you change the batteries. IR ID setup Press and hold POWER button, then press Number key.

  • Page 17: Remote Control Function

    Press 1 to 4 to select the source input, press 0 to turn off the output. * Under using quick key operation, LCM screen will jump to the output / input setting page, it won’t allow to use the front panel button to operate the HE04M Matrix. 6.0 Remote Control Function HE04M support RS232 and TCP/IP control by same command as below: 6.1 RS232 Console...
  • Page 18 User Manual HE04M EDID_COPY△[n] Copy EDID from TX n SAVE△[n] Save setting to #n LOAD△[n] Load setting from #n KEY△[y] Panel button& IR remote control Lock/Unlock DHCP△[y] DHCP client on/off IP_ADDRESS△[x.x.x.x] Set Matrix IP address SUBNET_MASK△[x.x.x.x] Set Matrix subnet mask GATEWAY△[x.x.x.x]...
  • Page 19 User Manual HE04M 7.0 RS-232 Extender Function (Default: FIX MODE) *Cable connection please refers to the connection view page. *Transmission baud rate up to 115200 bps. 8.0 Remote Side IR Extender Function Tx Function Receiving IR signal via the 4 sets HDBaseT ports, it sends out the IR signal by Tx jack (connect with 3.5 mm IR Emitter) to control source device.

  • Page 20: Ethernet Menu

    DATA3 - Caution First time to use HE04M remote control or change new batteries must set up IR ID. The wiring must away from any equipment with electromagnetic wave, i.e.: microwave, mobile phone, radio equipment, high voltage, Fluorescent light fixtures, power lines, etc.
  • Page 21 User Manual HE04M 10. Ethernet Control Function Initial IP Configuration Setup MATRIX IP Address same as your PC with same domains. (Default 192.168.0.200) MATRIX IP Address method, please refer to “ETHERNET” Chapter. 3. Input IP Address on a web page, you could link to the Web UI of the MATRIX host.
  • Page 22 User Manual HE04M Advanced  IP address: Change IP address  Subnet mask: Change Subnet mask  Gateway IP: Change Gateway IP  Media Type: Change 10 / 100 / Auto detect  DHCP Client: When setup at Enable, the MATRIX host will automatic get IP Address、Subnet Mask、...
  • Page 23 User Manual HE04M Aliases  Aliases page can change input/output name, enter Apply to finish the setting after change The new name will update and correspond to SWITCH SETTING page Output / Input.  Press Back jump back to advanced page.
  • Page 24 User Manual HE04M Scene  Save: Save 10 set of channel settings.  Load: Reload 1 of the channel settings.  Update: Refresh the status of Load.  Back: Back to Advanced page. 11. Android APP Function APP name: Matrix Controller System Requirement Android 4.0 and up...
  • Page 25 User Manual HE04M Google Play Download Link https://play.google.com/store/apps/details?id=sct.com.matrixcontroller Google Play Download QR code System Setting Connect mobile phone to Wi-Fi and set the IP/ subnet mask same with matrix network segment Default IP address of 10 by 10 matrix is 192.168.0.10 Default IP address of 4 by 4 matrix is 192.168.0.200...
  • Page 26 User Manual HE04M Scan Device Touch「+」button at main screen to enter「Scan Device」page Touch bottom left「Scan Device」to start scan Touch bottom right pen icon to input the IP address manually Add Matrix After scanning it will show all matrixes in the list Touch the IP in list to enter「Add Device」page...
  • Page 27 User Manual HE04M It will show「+」icon in front of the IP address when finished Return to main screen you will see the matrix which just add Modify Device Press the matrix name to show pop-up dialog...
  • Page 28 User Manual HE04M Touch「Modification」to enter modification page. Yellow block shows matrix name and icon Green block shows name and icon of output devices Brown block shows name and icon of input devices Touch yellow block to modify matrix name and icon...
  • Page 29 User Manual HE04M Return to Modification page you will see the matrix have been changed Touch green block to modify output name and icon Input the name and select the icon you prefer then touch「Save」to finish Return to Modification page you will see the output have been changed...
  • Page 30 User Manual HE04M Touch brown block to modify input name and icon Input the name and select the icon you prefer then touch「Save」to finish Return to Modification page you will see the input have been changed...
  • Page 31 User Manual HE04M Channel Switching mode (load scene, input selection, output selection) Click device name in list to enter load scene page Slide right from load scene page to enter input selection mode (as before) Slide left from load scene page to enter output selection mode (support...
  • Page 32 User Manual HE04M Load scene Modify scene name Press scene column to show pop-up dialog to modify scene name After modification touch 「Save」to save scene name It will return to Load Scene page automatically. Notice：Name should be unique, not allow duplicate or empty.
  • Page 33 User Manual HE04M It will show pop-up message 「Reading…」 After reading it will refresh scene status Touch the column name to show pop-up dialog Touch 「Yes」to apply scene...
  • Page 34 User Manual HE04M Input Selection Mode Top right「Refresh」to renew the status of matrix Below「Refresh」button to power on/off the matrix The block under device are Output 1~ Output 10 (4 by 4 matrix only shows Output 1~Output 4) Left side shows output device name Right sideshows current input device name Bottom left「Save Scene」to save the scenes...
  • Page 35 User Manual HE04M Output Selection Mode Top right 「Refresh」to renew the status of matrix Below「Refresh」button to power on/off the matrix The blocks under device are Input 1~ Input 10 (4 by 4 matrix only shows Input 1~Input 4) Left side shows input device name Right side shows current output numbers of devices Bottom left「Save Scene」to save the scenes...
  • Page 36 User Manual HE04M Save Scene In Input or Output Selection page touch bottom left 「 Save Scene」 to enter Save Scene page Touch the Scene column to show pop-up dialog Touch 「Save」to save current channels setting for all output It will return to Save Scene page automatically.
  • Page 37 User Manual HE04M Delete Matrix Press the block of matrix in Controller page to show pop-up dialog then touch「Delete」 Touch「Delete」to delete the matrix...
  • Page 38 User Manual HE04M 12. iOS APP Function APP name: Matrix Controller System Requirement iOS 7.1 and up Size: 2.3M Language: English, Traditional Chinese, Simplified Chinese iTunes Download Link https://itunes.apple.com/us/app/matrix-control/id904487754?l=zh&ls=1&mt=8 iTunes Download QR code System Setting Connect mobile phone to Wi-Fi and set the IP/ subnet mask same with matrix network segment Default IP address of 10 by 10 matrix is 192.168.0.10...
  • Page 39 User Manual HE04M Main Page When first time enter the APP will see the main page Bottom left「+」to add matrix Bottom right「Info」to show information Scan Device Touch「+」button at main screen to enter「Scan Device」page Touch bottom left「Scan Device」to start scan Touch bottom right pen icon to input the IP address manually...
  • Page 40 User Manual HE04M Add Matrix After scanning it will show all matrixes in the list Touch the IP in list to enter「Add Device」page Enter the name of matrix then touch「Add Device」to finish setting Notice：Name should be unique, not allow duplicate...
  • Page 41 User Manual HE04M Return to main screen you will see the matrix which just add Modify Device Touch the gear icon to enter Modification page Yellow block shows matrix name and icon Green block shows name and icon of output devices...
  • Page 42 User Manual HE04M Touch yellow block to modify matrix name and icon Input the name and select the icon you prefer then touch「Save」to finish Return to Modification page you will see the matrix have been changed Touch green block to modify output name and icon...
  • Page 43 User Manual HE04M Return to Modification page you will see the output have been changed Touch brown block to modify input name and icon Input the name and select the icon you prefer then touch「Save」to finish Return to Modification page you will see the input have been changed...
  • Page 44 User Manual HE04M Channel Switching mode (load scene, input selection, output selection) Click device name in list to enter load scene page Slide right from load scene page to enter input selection mode (as before) Slide left from load scene page to enter output selection mode (support...
  • Page 45 User Manual HE04M Load scene Modify scene name Touch the gear icon to enter modify scene name After modification touch 「Save」to save scene name It will return to Load Scene page automatically. Notice：Name should be unique, not allow duplicate or empty.
  • Page 46 User Manual HE04M It will show pop-up message 「Reading…」 After reading it will refresh scene status Touch the column name to show pop-up dialog Touch 「Yes」to apply scene...
  • Page 47 User Manual HE04M Input Selection Mode Top right「Refresh」to renew the status of matrix Below「Refresh」button to power on/off the matrix The block under device are Output 1~ Output 10 (4 by 4 matrix only shows Output 1~Output 4) Left side shows output device name Right sideshows current input device name Bottom left「Save Scene」to save the scenes...
  • Page 48 User Manual HE04M Output Selection Mode Top right 「Refresh」to renew the status of matrix Below「Refresh」button to power on/off the matrix The blocks under device are Input 1~ Input 10 (4 by 4 matrix only shows Input 1~Input 4) Left side shows input device name Right side shows current output numbers of devices Bottom left「Save Scene」to save the scenes...
  • Page 49 User Manual HE04M Save Scene In Input or Output Selection page touch bottom left「Save Scene」to enter Save Scene page Touch the Scene column to show pop-up dialog Touch 「Save」to save current channels setting for all output It will return to Save Scene page automatically.
  • Page 50 User Manual HE04M Delete Matrix Touch top right「Edit」button to enter delete mode Touch 「-」button in the left of matrix Touch「Delete」to delete the matrix Touch top right 「Done」to exit...
  • Page 51 User Manual HE04M 13. HE04M Standard Package Include HE04M Matrix x 1 pcs IR01 IR Remote Control x 1 pcs IR Emitter Cable x 1 pcs IR Receiver Cable x 1 pcs Power Adapter x 1 pcs CD Software x 1 pcs 14.

  • Page 52: Specification

    User Manual HE04M 17. Specification ITEM NO. HE04M Support Compliance HDMI 1.4, HDCP, 3D Max. Video Resolution 1080p@60Hz 12bit Max. Transmission 100M over CAT5e or greater cable Distance Audio Format LPCM 7.1, Dolby TrueHD, DTS-HD Master Audio RS232 Baud Rate...
  • Page 53 User Manual HE04M ITEM NO. HE02NR HE02ER HE02EIR Support Max. Video Resolution 4K@30Hz 4:4:4 8bit Max. Transmission Distance 100M 100M Ethernet Bandwidth 10/ 100Mbps IR Support 30-60KHz, ±55°, 5M 30-60KHz, ±55°, 5M RS-232 Baud Rate 115200bps/ Full Duplex Interfaces & Ports...
