SC&T HE04M User Manual

HDMI (HDBaseT) Matrix Switcher Series
ITEM NO.: HE04M
With the latest and more affordable HDBaseT technology extend HDMI sources up to 100M at
1080p or 1920x1200. HE04M HDMI 4 by 4 Matrix Switcher allows for effortless control of up
to 4 devices through IR remote control, RS-232 and the front panel.
HE04M 4 x 4 HDMI (HDBaseT) Matrix Switcher

Feature:

4 x HDMI inputs , 4 x HDMI Outputs Matrix switcher

Dual Output: local HDMI port or remote RJ45 termination

Work with HE02ER, HE02R receiver at each monitor up to 100 meters over CAT5e/6.

Work with HE02EIR receiver at each monitor up to 70 meters over CAT6a cable.

Three control option: Front panel button, IR remote control, RS232 through remote PC.

Support local/remote IR control to select input/output.

Built in RS232 console port to select input/output.

Uncompressed high definition video 1080p@60Hz 12 bit and 3D capable

HDMI 1.4 video features supported.

Built in IR extender (work with Receiver: HE02EIR)

Built in RS232 extender ( work with Receiver: HE02R)

Input/Output status could be displayed at panel LED.

Optional CAT5E/CAT6 Receiver Model:

HE02ER 100m HDMI Receiver
HE02R 100m HDMI, IR and RS232 Receiver
HE02EIR 70m HDMI with IR Receiver

Panel View:

LED Indication:
Power ON/OFF
OUTPUT / INPUT: 4x4 led matrix
LEDS Flash
LED ON
:Select INPUT Channel
:Input Selected
