ATC iLifestyle Quick Start Manual

iLifestyle Quick Start Guide
For a full description of the operation of your iLifestyle WiFi
radiator please refer to the main manual.
Controls
Lock icon
Current Temp/
set point
Mode Key
OK Key
Manual
Mode Key
Easy Mode
Easy mode is designed to allow you to use
the radiator with just temperature control
and Standby/On To access the easy mode,
touch and hold the OK and MODE keys
together until you have the screen shown
on the right.
Touch OK twice to move to "Param.2" and then touch the up
key to change 1P to 2P and touch OK. To exit easy mode, enter
the same menu and change 2P to 1P and touch OK.
When in Easy mode the screen will change
to show the current room temperature.
The temperature required can be set with
the ▼ and ▲ keys and switch the radiator
on or off with the Standby key. None of the
other keys or functions are available.
WiFi Menu
The WiFi menu shows the required information to allow the
radiator to be linked to a users WiFi Network.
There are 4 or 5 available, depending on whether the radiator
has a linked WiFi network or not, The Menus can can be
selected using the ▼ and ▲ keys, and by touching the OK key
when the desired menu is highlighted.
A73023530 - 2021-12
Time/Day
Heating
Indicator
Current
Comfort Mode
Mode Icon
Up Key
Down Key
Eco Mode
Standby Key
Anti-Frost Mode
For all functions in the WiFi menu, please refer to the main
operating manual.
Operating Modes
To choose which way the radiator will run
touch the MODE key to show the MODES
menu. Each of the 4 modes will change the
way the radiator works. Use the ▼ and
▲ keys to select a continuous mode and
touch OK.
Comfort Mode
Comfort mode is used for continuous heat between 12 and 30
°C. It is typically used when you are at home and want to bring
the radiator on without setting a program or using manual
mode. Temperatures can be adjusted directly using the ▼ and
▲ keys.
Eco – Economy Mode
Economy mode temperature can be set between 0.5 and 4.5 °C
less than the comfort temperature. Temperature settings can
be adjusted directly using the ▼ and ▲ keys. Economy is used
in program mode and situations where you don't need full heat
but require a lower level of heat to prevent the temperature
falling excessively.
Anti-Frost Mode
Anti-Frost is factory set at 7 °C and is used in the Program
Mode as an off set point within a program; it is also used for
long periods of absence when you want to avoid freezing in the
heated zone.
Program Mode
The Program mode allows you to set your
own schedule according to your daily or
weekly needs.
The program display is shown as two 12
hour clock faces, 00:00 to 11:59 and 12:00
to 23:59.
Each ½ hour segment of the day can be programmed to
Comfort, Eco or Anti-Frost (see Controls section).
Edit program (when in Program Mode)
To begin editing the program touch the OK key, the radiator
will begin with the current day if it is set, change the day to be
programmed with the ▼ and ▲ and then touch OK.
The program then moves on to setting the heating times of the
day; you can move backward and forward through the times to
pick which temperature setting is required.
Using ▼ and ▲ to reach the time that you want to have the
heating on, touch MODE to change between Comfort, Eco, or
Anti-Frost.
Move forward for each ½ hour and touch MODE to select
setting for each segment of the day. The display will change
from AM to PM when appropriate.
