- Page 1 Sun Ray Neptune Low Level Thermal Electric Radiator Installation and Operation Guide Models Type Wattage No. of Fins Size (HxWxD) (mm) Net Weight (kg) LR950 950w 340x865x96 12.8 LR1425 1425w 340x1265x96 19.2...
- Page 2 Installation General Information This appliance must be connected to a 230V 50Hz power supply. This appliance must be connected to a switched fused spur. The main installation must be protected by a 2 pole switch where the distance between contacts must be a minimum of 3mm. Power Cord Wires = Neutral (Grey or Blue) Live (Brown)
- Page 3 provided that it has been placed or installed in its intended normal operating position and they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children aged from 3 years and less than 8 years shall not plug in, regulate and clean the appliance or perform user maintenance.
- Page 4 Directions for the Installer Installation should only be completed by a qualified electrician. Electric Power The electrical circuits within your house should be of the correct type and size for the appliance wattage, consult your electrician for advice. It is recommended that the fused spur outlet is placed 10cm to the right of the appliance and 15cm from the floor.
- Page 5 Mark the appropriate location and fix the brackets in place with the supplied plugs and screws, ensuring the brackets are installed in the correct position (figure 2). Figure 2 Once the brackets have been installed the radiator can be hung from the supports (figure 3). To lock the radiators in place press on the ratchet and turn until a click is heard (figure 4).
- Page 6 Operation The room temperature is controlled by the electronic thermostat in the control end located on the side of the appliance. The thermostat has a precision of ±0.3ºC. Main modes: Time ‘button’ standby time Frost protection ECO ‘button’ Comfort Pilot wire Heating indicator ON / stand by ‘button’...
- Page 7 Mode Change Press the Mode button to change between the mode screens shown below: Pilot wire Comfort Economy Frost Protection Programme 2hr Boost ECO mode Pilot Wire When in the pilot wire mode and if connected to a separate pilot wire controller the appliance can receive four type of control signal: 1.
- Page 8 Programme Mode The programme mode has three programs which can be amended by the user (P1, P2, P3). To select a programme, press the mode until the Programme mode is selected. Then press the time button to select either P1, P2 or P3. To edit a programme: 1.
- Page 9 Programming – Quick Guide Setting Time Chose Time using -/+ Day starts blinking. in Stand by mode , press buttons and select with and hold Time button Mode button. Chose week day (1-7) -/+ Select Hour -/+ Select Minutes -/+ , confirm pressing Mode cofirm pressing Mode cofirm pressing Mode...
- Page 10 Functions Menu Once power has been supplied to the radiator it will initially be in the standby mode. stand by Function Setting Functions 1. In the Stand-by mode press and hold the time button for more than 3 seconds. 2. Press the + or - button to select Time or Function, press mode to chose Function.
- Page 12 The Remote Control (Optional) General Description The remote control communicates with the radiator using infra-red signal from a maximum distance of 10m from the appliance and requires 2x AAA batteries. Temperature transmision Time Button Mode Button Operating Mode ‘-’ Button ‘+’...
- Page 13 IR Transmission Any alterations made using the remote control will be sent to the radiator via an IR signal after 1 second of inactivity. This can be seen by the IR transmission symbol flashing in the top right hand corner. Keypad lock This function allows the user to lock the keypad on the remote to avoid inadvertent changes.
- Page 14 Installation Notes:...
- Page 15 With adaptive start control. • With working time limitation. ATC Electrical and Mechanical Head Office & Showrooms ATC House, Broomhill Drive, Tallaght, D24 EF99, Ireland. IRL Tel: +353 (0)1 4625111 UK Tel: +44 (0)203 5649164 Fax: +353 (1) 452 0887 Email: sales@atc.ie...
- Page 16 SunRay Radiators clean may result in dust becoming burnt and depositing on the wall above the heater in the form of dark streaks or patches. This type of marking is expressly due to failure to keep the heater and surrounding area clean. ATC take no responsibility for any such damage caused...
