- Page 1 MPPT Solar Charge Controller User Manual Version: V1.01 Subject to change without notice Code: 106998...
-
Page 2: Table Of Contents
Dear users: Contents 1. Product introduction 1.1 Product overview Thank you for choosing our products! 1.2 Product features 1.3 Description on appearance and interface 2. Introduction to maximum power tracking technology 3. Technical parameters 4. Charging 4.1 Charging of lead-acid battery Safety Instructions 4.2 Charging of lithium battery 5. -
Page 3: Product Introduction
Adopt high-quality aluminum radiator and high-temperature derating treatment to ensure reliable and cannot obtain the maximum energy of the solar panel. Instead, the solar controller with MPPT can efficient operation in various operating conditions. -
Page 4: Technical Parameters
The MPPT controller can overcome the problem and adjust the input voltage and current of the 3. Technical parameters solar panel in real time to reach the maximum input power. Moreover, compared with the traditional PWM controller, it can exert the maximum power of the solar battery to provide a larger charging... -
Page 5: Charging
Select such battery types as SLD/FLD/GEL/USE, and select the appropriate system voltage. not connected, the default temperature is 25°C; As shown in Fig. 4-1, the charging stages of lead-acid battery are: MPPT charging, constant voltage charging (equalizing/ boost/floating charging), and current-limiting charging.The constant voltage charging is divided into three stages: 2). -
Page 6: Menu
7. Menu 1) Alternative display between (voltage/power) and (current/power) on the main menu every 10s. 2) Short press the key to browse the menu. If there is no key operation for 5s, it will [SELECT] automatically return to the main menu. 3) Long press [ENTER] for 3s on any interface to enter the parameter setting page. -
Page 7: Parameter Setting List
8.3 Type of battery 8.2 Parameter setting list Please refer to "8.1 and 8.2" for setting. Function Setting range Default Battery Type SLD /GEL/FLD/LI/USE/USE LI ① Equalizing charging voltage 9V~17V Available for USE only ① 9V~17V Boost charging voltage Available for USE and USE LI only ①... -
Page 8: Full-Charging Setting
8.7 Full-charging setting LCD screen Load mode Description 1) [Off]: Set 0 number 2) [On]: Select the appropriate current value between 1-10A When the solar panel voltage is less than the Light control ON voltage with a Full-charging condition: When the constant voltage charging duration of lithium battery reaches the set duration or the duration is more than the light control delay, turn on the load;... -
Page 9: Rs485 Communication Baud Rate
8.15 RS485 communication baud rate 9. TTL communication The RS485 communication baud rate can be modified according to actual needs. 1) Default baud rate: 9,600 kps; check bit: none; data bit: 8 bit; stop bit: 1 bit 2) Communication power supply output specification: (8.5V±1V)/: 100mA Definition VCC: communication power ①... -
Page 10: System Alarms
12. System alarms 13.Common problems and solutions System alarms Meaning Phenomenon Troubleshooting Description No action Check whether the battery and solar panel are properly Normal system LCD screen does not light up connected and whether the LCD connection cable has a poor connection Turn off... -
Page 11: Installation Steps
15. Protection Functions When connecting the system, the output voltage of the components may exceed the human body safety voltage, therefore, use insulated tools and keep your hands dry. The battery terminals on the controller can be connected either to a single battery or a battery pack. Over-temperature protection of device The subsequent instructions are for a single battery, but they are also applicable to systems with a When the internal temperature of the controller exceeds the set value, the charging power will be... -
Page 12: Product Dimensions
17. Product Dimensions 18. System wiring diagram 18.1 System wiring diagram 17.1 Shiner2410 Model: Shiner2410 Product dimension: 155*99*41.7mm Mounting hole spacing: 137*77mm Fixed hole position: φ4.5mm 17.2 Shiner2420 Model: Shiner2420 Product dimension: 181*118*61.7mm Mounting hole spacing: 161*96mm Fixed hole position: φ4.5mm...
