Rhopoint Instruments Optimap PSD 3 Manual page 9

• delete last measurement button
• project menu
• settings menu.
These features are described below.
Results are also displayed in numerical format in the results window at the bottom left
of the screen.
At the bottom of the screen below the map image, Project Name, Series or batch
number, and Measurement or count number indicators allow the storage and
management of measurement results. Measurements are saved by the Optimap in a
logical sequence allowing clear identification of the surface being measured.
The naming method used for these will differ according to application, however it is
the Project name that is the key field holding all measurement data for each series.
For example, a typical naming setup for an automotive measurement would be to use
the vehicle name or model number as the Project Name and the surface to be
measured, left door, right door etc as the Series. Measurements can then be made
according to requirement with each being stored as a separate measurement number
over the surface.
In the right of the map window of the main screen, a scale is displayed corresponding
to the image displayed in the map window.
or cancel button
8
