- Page 1 NETWORK CAMERA User Manual ANO-L6012R/ANO-L6022R ANO-L7012R/ANO-L7022R ANV-L6012R/ANV-L7012R...
- Page 2 Network Camera User Manual Copyright ©2021 Co., Ltd. All rights reserved. Hanwha Techwin Trademark Each of trademarks herein is registered. The name of this product and other trademarks mentioned in this manual are the registered trademark of their respective company. Restriction Copyright of this document is reserved.
- Page 3 overview IMPORTANT SAFETY INSTRUCTIONS 22. Installing or using the product in water can cause serious damage to the product. 23. Although a rapid change in temperature could cause frost inside the dome, there will be no problem with the 1. Read these instructions. video.
- Page 4 The ITE is to be connected only to PoE networks without routing to the outside plant. For below models only. The wired LAN hub providing power over the Ethernet (PoE) in accordance with IEEE ANO-L6012R/ANO-L6022R 802.3af shall be a UL Listed device with the output evaluated as a Limited Power Source ANO-L7012R/ANO-L7022R as defined in UL60950-1 or PS2 as defined in UL62368-1.
-
Page 5: Table Of Contents
CONTENTS OVERVIEW NETWORK CONNECTION AND Important Safety Instructions Connecting the Camera Directly to Local SETUP Recommended PC Specifications Area Networking Recommended Micro SD/SDHC/SDXC Connecting the Camera Directly to a DHCP Card Specifications Based DSL/Cable Modem What’s Included (ANO-L6012R/L6022R/ Using Device Manager L7012R/L7022R) Automatically searching camera What’s Included (ANV-L6012R/L7012R) -
Page 6: Recommended Pc Specifications
overview RECOMMENDED PC SPECIFICATIONS WHAT’S INCLUDED (ANO-L6012R/L6022R/L7012R/L7022R) Please check if your camera and accessories are all included in the product package. • CPU : Intel(R) Core(TM) i7 3.4 GHz or higher (As for each sales country, accessories are not the same.) •... -
Page 7: What's Included (Anv-L6012R/L7012R)
WHAT’S INCLUDED (ANV-L6012R/L7012R) OPTIONAL ACCESSORIES FOR INSTALLATION Please check if your camera and accessories are all included in the product package. For your easier installation, you can purchase appropriate optional accessories available. (As for each sales country, accessories are not the same.) Appearance Item Name Quantity... -
Page 8: At A Glance (Ano-L6012R/L6022R/L7012R/L7022R)
overview AT A GLANCE (ANO-L6012R/L6022R/L7012R/L7022R) AT A GLANCE (ANV-L6012R/L7012R) Appearance Appearance Item Description Dome cover Item Description Case cover used to protect the lens and the main unit. Micro SD card slot (Internal space of the product) This is a slot in which you can insert a Micro SD card. Camera Case Housing part that covers the camera body. - Page 9 Components Item Description Illumination Sensor Detects incoming light to control the IR LED. Lens Lens for the camera. IR LED These infrared LED’s are controlled by the illumination sensor. The button restores all camera settings to the factory default. Press and hold for about 5 seconds to reboot the system. If you reset the camera, the network settings will be adjusted so that DHCP can be Reset button enabled.
-
Page 10: Installation & Connection
installation & connection INSTALLATION (ANO-L6012R/L6022R/L7012R/L7022R) How to connect the RJ45 waterproof cable to a LAN cable 1. Insert it through the arrow direction. This camera is waterproof and in compliance with the IP66 spec, but the jack connected to the external cable is not. You are recommended to install this product below the edge of eaves to prevent the cable from being externally exposed. - Page 11 Outdoor installation Hallway view Camera System When you install it outside of the building, please waterproof it with waterproof butyl rubber tape (can be The camera can be rotated to enlarge the vertical monitoring area to an aspect ratio of 9:16, making it purchased in stores) so that water does not leak from the gap of the cable connected to the outside.
-
Page 12: Installation (Anv-L6012R/L7012R)
installation & connection INSTALLATION (ANV-L6012R/L7012R) 5. Close the dome cover. Tighten the fastening bolts tightly using the Torx L wrench to prevent water leakage. This camera is waterproof and in compliance with the IP66 spec, but the jack connected to the external cable is not. You are recommended to install this product below the edge of eaves to prevent the cable from being externally exposed. -
Page 13: Inserting/Removing A Micro Sd Card
INSERTING/REMOVING A MICRO SD CARD Adjusting the monitoring direction for the camera (ANV-L6012R/L7012R) Before installing the camera, the Micro SD card should be inserted while the power source and the body are separated. Do not forcefully insert it in the reverse direction. It might damage your Micro SD card and your product. When it rains or the humidity is high, insertion or ejection of a Micro SD card is not recommended. - Page 14 installation & connection Inserting a Micro SD Memory Card (ANV-L6012R/L7012R) Removing a Micro SD Memory Card Gently press down on the exposed end of the memory card as shown in the diagram to eject the memory 1. Separate the Dome cover of the camera. card from the slot.
- Page 15 POWERING AND NETWORKING Network Cable Specification Item Contents Remark Connect your PoE device to the camera. Connector RJ45 Ethernet 10/100BASE-T 10/100 Mbps Cable Category 5e Max Distance 100 m DC Resistance ≤ 0.125 Ω/m PoE Support IEEE 802.3af If you use a cable other than Category 5e standards, 100m of transmission distance is not guaranteed. <ANO-L6012R/L6022R/L7012R/L7022R>...
-
Page 16: Connecting The Camera Directly To Local
network connection and setup network connection and setup CONNECTING THE CAMERA DIRECTLY TO A DHCP BASED DSL/CABLE You can set up the network settings according to your network configurations. MODEM CONNECTING THE CAMERA DIRECTLY TO LOCAL AREA NETWORKING Connecting to the camera from a local PC in the LAN INTERNET DSL/Cable Modem 1. -
Page 17: Using Device Manager
USING DEVICE MANAGER If using a Broadband Router • IP Address : Enter an address falling in the IP range provided by the Broadband Router. Device manager program can be downloaded from <Technical Support>-<Online Tool> menu at Hanwha Techwin website ex) 192.168.1.2~254, 192.168.0.2~254, (http://www.hanwha-security.com). -
Page 18: Manually Registering Camera
network connection and setup AUTOMATICALLY CONFIGURING IP Configuring Dynamic IP Receive IP address from DHCP 1. Click the camera from the list that you want to automatically • Example of the Dynamic IP environment configure the IP. ANV-L6012R - If a Broadband Router, with cameras connected, is assigned an IP address by the DHCP server 2. -
Page 19: Port Range Forward (Port Mapping) Setup
Port forwarding can be done without additional router setup if the router supports the UPnP (Universal Plug and Play) function. For more information, refer to the user manual of the applicable router. After connecting the network camera, select the checkbox from the menu <Quick connect> in <Wisenet DDNS> in “Settings -> Network -> DDNS”. -
Page 20: Connecting To The Camera From A Shared Local Pc
2. From the remote PC, launch the Internet browser and type the DDNS URL address of the camera, or the IP address of the Broadband Router in the address bar. ex) http://ddns.hanwha-security.com/ID To use Wisenet DDNS, sign up at the Wisenet DDNS homepage (http://ddns.hanwha-security.com) and register the product at [My DDNS]>[Register Product]. 20_ network connection and setup... -
Page 21: Connecting To The Camera
To register your device to the <DDNS> server, visit http://ddns.hanwha-security.com and register your device 1. Launch the Internet browser. first, and then set the Web Viewer’s <Network> - <DDNS> to <Wisenet DDNS>, as well as providing <Product ID> that had been used for DDNS registration. -
Page 22: Password Setting
web viewer PASSWORD SETTING CAMERA WEB VIEWER SETUP When you access the product for the first time, you must register the 1. Click the [Setup ( )] icon. login password. 2. The Settings window appears. 3. You can configure settings for the camera’s basic information, video, network, event, analysis, and system over the network. -
Page 23: Troubleshooting
appendix TROUBLESHOOTING PROBLEM SOLUTION PROBLEM SOLUTION y On the authentication popup window prompted when initially accessing https, click "View y Verify the settings in the following sequence: File is not transferred to the email Authentication Certificate" and select the "Always trust when connecting to the designated even if a motion detection event is A. - Page 24 appendix Any changes or modifications in construction of this device which are not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
