DB1100X Service Manual
Innovative Concepts in Entertainment
10123 Main Street
Clarence, New York 14031
(716) 759-0360 8:30am to 6:00pm EST
WWW.ICEGAME.COM

Advertisement

loading
Need help?

Need help?

Do you have a question about the DODGEBALL and is the answer not in the manual?

Questions and answers

Summary of Contents for Icegame DODGEBALL

  • Page 1 DB1100X Service Manual Innovative Concepts in Entertainment 10123 Main Street Clarence, New York 14031 (716) 759-0360 8:30am to 6:00pm EST WWW.ICEGAME.COM...
  • Page 2 Table of Contents - REV B - 10/13/2022 1100x Deluxe model DODGEBALL Safety and Warnings Game description and operations Hardware kit breakout 5 - 6 Game Assembly Chapter 1 7 - 15 Chapter 2 16 - 21 Chapter 3 22 - 27...
  • Page 3: Safety And Warnings Before You Begin

    SAFETY AND WARNINGS BEFORE YOU BEGIN WARNING: WHEN INSTALLING THIS GAME, A GROUNDED A.C. RECEPTACLE MUST BE USED. FAILURE TO DO SO COULD RESULT IN INJURY TO YOURSELF OR OTHERS. FAILURE TO USE A GROUNDED RECEPTACLE COULD ALSO CAUSE IMPROPER GAME OPERATION, OR DAMAGE TO THE ELECTRONICS.
  • Page 4 The object of the game is to hit targets to score the most points possible using multipliers to increase your score. The game can be played in either single training mode or competitive mode. Points of the game: ● Arena Jumbotron - Players can compare their scores in competitive mode against others. ●...
  • Page 5: Hardware List

    HARDWARE LIST AA6630 1/4-20 x 4 black Allen E08639 HARNESS AA6369 - 1/4-20 X 3-1/2 BLACK CLAMP AA6516: 1/4-20 X 3/4 DOWEL NUT PC60636 1/4-20 X 3 (BLACK) AA0655 - #8 X 3/4 silver Square pan head screw AA6125 1/4-20 X 2-1/2 black AA6584 1/4-20 X 2 (BLACK) QTY: 3 AA6177 - 8-32 x 1...
  • Page 6 NON-HARDWARE ITEMS INCLUDED WITH PARTS PACK DB3024 - balls X’s 24 (4 boxes with 6 multicolored balls in each box) 18 balls installed in game, and 6 spare balls. AA6105 Latch tool AA6173 AA6811 #2 Phillips BIT T-20 Torx Bit PC60615A AA6215 #2 SQ DRIVE BIT...
  • Page 7 Chapter 1 Assembly for Steps 1-9.
  • Page 8 Parts Needed Pallet 1 Pallet 2, loose, 2k Bundle 1 1P (X’s4) Bundle 2 1S (X’s 2) Pallet 2 Bundle 2 2v & 2W Pallet 1, Loose, 1F HARDWARE NEEDED AA6125 1/4-20 X 2-1/2 black Allen (QTY 26) Pallet 1, loose, 1G AA6212 1/4 X 3/4 black washer (QTY 30) AA6966 1/4-20 black...
  • Page 9 STEP 1: Attach two “1P” leg to the left wall “1G” panel, graphics facing up, using three AA6125 Allen bolts and three AA6212 black flat washers on each “1P”leg. The legs should be on top of the outside of the panel. Graphics should be on facing at you.
  • Page 10 STEP 2: Attach two “1P” legs to the right side wall ”1H”, graphics facing up, using three AA6125 Allen bolts and three AA6212 black flat washers on each leg. The “1P” legs should be on top of the outside of the panel.
  • Page 11 STEP 3: Attach the two 2V and 2W brackets to each side of the rear wall panel (1F) using three AA6584 black Allen bolts and AA6212 black washers. Brackets when installed should be on the inside of the panel. See mounted brackets and pay attention to the Square cut out on the right side. X’s 6 AA6584 1/4-20 X 2 (BLACK) AA6212 1/4 X 3/4 FLAT...
  • Page 12 STEP 4: Slide the back wall assembly into the left wall back slots you created when you installed the back legs. STEP 5: Secure the back wall to the left side wall assembly using two AA6125 and two AA6212 black flat washers. X’s 2 AA6212 1/4 X 3/4 FLAT WASHER BLACK...
  • Page 13 STEP 6: Insert the other side of the back wall assembly into the right wall slots. Secure the back wall to the right wall assemblies using three AA6125 and three AA6212 black flat washers. X’s 2 AA6125 1/4-20 X 2-1/2 (BLACK) AA6212 1/4 X 3/4 black washer...
  • Page 14 STEP 7: Slide two 1S Joists into the two inner channels shown. NO HARDWARE is used to secure them.
  • Page 15 AA6125 1/4-20 X 2-1/2 black Allen (QTY 4) AA6212 1/4 X 3/4 black washer (QTY 8) STEP 8: AA6966 1/4-20 black nylon nut (QTY 4) Slide the upper support onto the brackets at the front of the game. Secure the support using two AA6125 Allen bolts and AA6212 washers from the backside and secure them with AA6966 nylon...
  • Page 16 Chapter 2 Assembly for Steps 9-16.
  • Page 17: Parts Needed

    Parts Needed Pallet 2, loose, 2k Pallet 2, loose, 2E Pallet 1, loose, 1O Pallet 1, loose, 1E HARDWARE NEEDED Pallet 1, loose, 1k QTY 12 : AA6584 1/4-20 X 2 (BLACK) QTY 3 : AA6281 1/4-20 X 1-1/2 BLACK Pallet 1, loose, 1J Pallet 1, loose, 1I QTY 15 : AA6212 1/4 X 3/4 black washer...
  • Page 18 STEP 9: Slide the power sub-floor (1E) into the rear channels. Align the tabs into the slots. WATCH YOUR FINGERS! NOTE: Although all efforts we made to ensure quality in parts, before installing this panel, inspect the panel for damage to wiring or mounting holes not fully cleaned out.
  • Page 19 STEP 11: Locate the components shown below to assembly the ball gate assembly. The two DB3186 ball deflectors are not installed at this time. 2E Ball gate assembly STEP 12: Secure both left (1I) and right (1J) ball deflectors to the (2E) ball gate assembly using three AA6281 black Allen bolts and AA6212 black washers on each deflector.
  • Page 20 STEP 13: Attach the 1K center support with four AA6584 black Allen bolts and four AA6212 black washers from the top and at the back of the support. AA6584 1/4-20 X 2 (BLACK) X’s 4 AA6212 1/4 X 3/4 FLAT WASHER BLACK STEP 14: Slide the 2E ball gate assembly into the front slot of the base cabinet.
  • Page 21 STEP 15: Secure the 1O center floor panel using four AA6584 black Allen bolts and AA6212 black washers. X’s 4 AA6584 1/4-20 X 2 black Allen AA6212 1/4 X 3/4 black washer NOTE: Although all efforts we made to ensure quality in parts, before installing this panel, inspect the panel for damage to wiring or mounting holes not fully cleaned out.
  • Page 22 Chapter 3 Assembly for Steps 17-22.
  • Page 23 Parts Needed Pallet 2, loose, 2B Pallet 2, loose, 2A Pallet 2, loose, 2D Pallet 2, loose, 2C HARDWARE NEEDED Pallet 2, bundle 1 Pallet 2, bundle 1 QTY 7 : AA6584 1/4-20 X 2 (BLACK) QTY 6 : AA6004 - 8-32 X 1/2 QTY 7 : AA6212 1/4 X 3/4 black washer...
  • Page 24 STEP 17: Lay the (2C) left and (2D) right Towers on their backs. At the bottom of the (2C) left tower should be one network cord and two DC connections (one small, one large). Carefully pull them out and ensure no damage has been done to the network cable. At the bottom of the (2D) right tower should be two network cords and two DC connections (one small, one large).
  • Page 25 STEP 18: Position 2C target assembly to the left and 2D target assembly to the right at the back of the cabinet. Align the hole at the bottom of the towers with the holes already at the back. Secure using three AA6584 black Allen bolts and AA6212 black washers.
  • Page 26 STEP 19: Install the 2M and 2N lower panel covers to both score towers using three AA6004 each. USE A SCREW DRIVER or lower Torq setting. These covers must remain removal for future service. AA6004 - 8-32 X 1/2 X’s 3 2M or 2N STEP 20: Lay the 2A left and 2B right inner towers on their backs.
  • Page 27 STEP 21: Position 2A inner tower to the left and 2B inner tower to the right at the back of the cabinet. Align the hole at the bottom of the towers with the holes already at the back. T-Molding goes to the bottom! STEP 22: Secure each of the inner towers using four AA6584 black Allen bolts and AA6212 black washers.
  • Page 28 Chapter 4 Assembly for Steps 23-26.
  • Page 29 Parts Needed Pallet 1, loose, 1D Two 6’ or 8’ ladders. Pallet 2, bundle 1 HARDWARE NEEDED QTY 4 : AA6584 1/4-20 X 2 (BLACK) QTY 6 : AA6004 - 8-32 X 1/2 QTY 4 : AA6212 1/4 X 3/4 black washer Recommend 3 helpers...
  • Page 30 STEP 23: THIS STEP REQUIRES HELPERS! DO NOT ATTEMPT TO LIFT ALONE! RECOMMEND THREE PEOPLE TO INSTALL THIS ASSEMBLY. DO NOT ATTEMPT TO INSTALL FROM THE FRONT! THIRD PERSON POSITION SHOULD BE AT THE FRONT, INSIDE THE CABINET TO MOUNT HARDWARE AND STABILIZE CENTER TARGET/JUMBOTRON ASSEMBLY.
  • Page 31 STEP 25: Secure each inner tower to the jumbotron using three AA6584 black Allen bolts and AA6212 black washers. Use two AA6584 black Allen bolts and AA6212 black washers on each side of the center target assembly. AA6584 1/4-20 X 2 (BLACK) X’s 4 AA6212 1/4 X 3/4 FLAT WASHER BLACK...
  • Page 32 STEP 27: On each inner tower and on both sides attach a DB3034 cover using three AA6004 black Allen bolts and AA6212 black washers. X’s 6 AA6004 - 8-32 Jumbotron Installed...
  • Page 33 Chapter 5 Assembly for Steps 28-46.
  • Page 34 Parts Needed HARDWARE NEEDED Pallet 2, Loose, 2H AA6369 - 1/4-20 X 3-1/2 BLACK QTY 2 PC60636 1/4-20 X 3 (BLACK) QTY 6 AA6125 1/4-20 X 2-1/2 black Allen QTY 6 PC60622 1/4-20 X 1 (BLACK) QTY 16 AA6281 1/4-20 X 1-1/2 black Allen QTY6 AA6212 1/4 X 3/4 FLAT WASHER BLACK QTY 36 Pallet 2, Loose, 2G AA6966 1/4-20 nylock black nut QTY 4...
  • Page 35 STEP 28: Attach a 3J to each cage (2G & 2H) front using three PC60636 black Allen bolts and AA6212 black washers. The notch faces to the outside of the cages. It is necessary to raise the cages off the ground to install. X’s 6 PC60636 1/4-20 X 3 (BLACK) AA6212 1/4 X 3/4 FLAT...
  • Page 36 STEP 29: Position the 2G (left) cage assemble on the left side and against the 2C outer tower. Notch to the outside. STEP 30: DO NOT TIGHTEN HARDWARE Loosely secure the cage to the 2C outer tower using three PC60622 black Allen bolts and AA6212 black washers from the inside of the cabinet.
  • Page 37 STEP 31: DO NOT TIGHTEN HARDWARE Loosely secure the cage bottom to the cabinet using five PC60622 black Allen bolts and AA6212 black washers from the inside of the cabinet. X’s 5 PC60622 1/4-20 X AA6212 1/4 X 3/4 FLAT 1 (BLACK) WASHER BLACK STEP 32:...
  • Page 38 STEP 33: Secure the cage to the front cabinet legs using one AA6369 Black Allen Bolt and AA6212 black washer. X’s 1 AA6369 - 1/4-20 X 3-1/2 BLACK OUTSIDE AA6212 1/4 X 3/4 FLAT WASHER BLACK STEP 34:DO NOT TIGHTEN HARDWARE Secure the cage to 1Q using three AA6281 Black Allen Bolts and AA6212 black washers.
  • Page 39 STEP 35: Secure the cage assembly to the 2C left outer tower with one AA6125 black bolt and AA6212 black washer. AA6125 1/4-20 X 2-1/2 black Allen X’s 1 AA6212 1/4 X 3/4 FLAT WASHER BLACK STEP 36: Align the 2H right cage against the back tower.
  • Page 40 STEP 37: DO NOT TIGHTEN HARDWARE Secure the cage to the outer tower using three PC60622 black Allen bolts and AA6212 black washers from the inside of the cabinet. X’s 3 PC60622 1/4-20 X 1 (BLACK) AA6212 1/4 X 3/4 FLAT WASHER BLACK STEP 38: DO NOT TIGHTEN HARDWARE Secure the cage bottom to the cabinet using five PC60622 black Allen bolts and AA6212 black...
  • Page 41 STEP 39 Slide the 1R filler panel onto the 2H right cage top. STEP 40: Secure the cage to the front cabinet legs using one AA6369 Black Allen Bolt and AA6212 black washer. X’s 1 AA6369 - 1/4-20 X 3-1/2 BLACK OUTSIDE AA6212 1/4 X 3/4 FLAT WASHER BLACK...
  • Page 42 STEP 41: Secure the cage to the DB3158 using three AA6281 Black Allen Bolts and AA6212 black washers. X’s 3 AA6212 1/4 X 3/4 FLAT AA6281 1/4-20 X 1-1/2 BLACK WASHER BLACK STEP 42: Secure the cage assembly to the back tower with one AA6125 black bolt and AA6212 black washer. X’s 1 AA6125 1/4-20 X 2-1/2 black AA6212 1/4 X 3/4 FLAT...
  • Page 43 STEP 45: Slide the back 2K roof arch into the back legs. STEP 46: Loosely secure the 2K arch using two AA6125 Allen bolts and AA6212 washers from the backside and secure them with AA6966 nylon nuts at the front on both sides. X’s 4 DO NOT TIGHTEN AT THIS TIME.
  • Page 44 Chapter 6 Assembly for Steps 47-54.
  • Page 45 Parts Needed HARDWARE NEEDED AA6125 1/4-20 X 2-1/2 black Allen QTY 4 AA6584 1/4-20 X 2 (BLACK) QTY 20 AA6212 1/4 X 3/4 FLAT WASHER BLACK QTY 24 Pallet 1, loose, 1C Pallet 1, loose, 1B Pallet 1, loose, 1A...
  • Page 46 STEP 47: DO NOT TIGHTEN HARDWARE Install the 1C center button wall to the back of the game loosely with six AA6584 black Allen bolts and AA6212 black washers. X’s 6 AA6584 1/4-20 X 2 (BLACK) AA6212 1/4 X 3/4 black washer Front view Back view...
  • Page 47 STEP 48: Install the 1A right button wall to the back of the game using seven AA6584 black Allen bolts and AA6212 black washers. You might have to shift the upper archway bar. X’s 7 AA6584 1/4-20 X 2 (BLACK) AA6212 1/4 X 3/4 FLAT WASHER BLACK Front view...
  • Page 48 STEP 50: Install the 1A button wall to the back of the game using seven AA6584 black Allen bolts and AA6212 black washers. You might have to shift the upper archway. X’s 7 AA6584 1/4-20 X 2 (BLACK) AA6212 1/4 X 3/4 FLAT WASHER BLACK Front view Back view...
  • Page 49 STEP 52: Tower harnesses Insert cables from each tower assembly into the bottom holes.
  • Page 50 STEP 53: NETWORK CABLE FLOW The Network cable run starts from front of game to first coupler at the back. The other side of the coupler goes up the left score tower and back down into another coupler. Each tower has two network cables.
  • Page 52 STEP 54: Remove the upper center panel. From the back of the cabinet, the network cable on the left side comes from the middle tower on the left. The right side comes from the middle tower on the right. Both at the top. From the front of the cabinet you can reach in and route the cables up into the jumbotron assembly.
  • Page 53 Chapter 7 Assembly for Steps 55-58. HARDWARE NEEDED AA0655 - #8 X 3/4 Square pan head QTY6...
  • Page 54 Parts Needed Pallet 2, loose, 2F...
  • Page 55 STEP 55: Undo harnesses at either end and push out side holes. The ball gate harness is accessed from the front. Remove keys attached to top of cabinet and put aside. Uncoil wires and run to the back of the game...
  • Page 56 STEP 56: Slide 2F front podium to the cabinet assembly. Unlock the center door and plug in ball gate harness. Latch the front cabinet to the back cabinet using the provided latch tool. STEP 57: Install the power inlet module with six AA0655 screws. Also apply DECALS from parts box (“CAUTION”, “WARNING”, “SUITABLE”) .
  • Page 57 Step 58: Install wire clips along the right side of the cabinet. Run the AC harness from the front to back using the wire clips to secure it to the cabinet. Underside of Game E08639 HARNESS CLAMP...
  • Page 58 Chapter 8 Assembly for Steps 59- 72.
  • Page 59 HARDWARE NEEDED Parts Needed AA6584 1/4-20 X 2 (BLACK) QTY 4 AA6281 1/4-20 X 1-1/2 black Allen QTY 12 PC60622 1/4-20 X 1 (BLACK) QTY 4 AA6514 - 8 1/2 pan head silver QTY8 QTY 2 AA6177 - 8-32 x 1 pan head silver QTY 4 AA6212 1/4 X 3/4 FLAT WASHER BLACK QTY 16 PC60614 1/4-20 Kept Nut QTY8 Pallet 3, loose, 3I...
  • Page 60 STEP 59: Location the right archway base (3D). Lift the front cabinet up and slide the right archway base into position and connect the 12 volt harness. Then slide the tower against the front podium. Notch must be underneath front cabinet.
  • Page 61 STEP 60: Secure the arch base using three AA6584 black Allen bolts and AA6212 black washers. X’s 2 AA6584 1/4-20 X 2 (BLACK) AA6212 1/4 X 3/4 FLAT STEP 61: Lift the front cabinet again and slide the 3C left arch base into position and plug in the harness. It may be necessary to slightly lift the podium to allow proper alignment with the tower.
  • Page 62 STEP 62: Secure the archway base using three AA6584 black Allen bolts and AA6212 black washers. X’s 2 AA6584 1/4-20 X 2 (BLACK) AA6212 1/4 X 3/4 FLAT WASHER BLACK STEP 63: Attach a 3I arch wire cover to the left and right arch bases. Secure each with two AA6177 screws. X’s 4 AA6177 - 8-32 x 1 pan head silver...
  • Page 63 STEP 64: Look inside at the LED”s in the upper archway. The LED’s have arrows. For the right archway, the arrows go down. The left archway has the LED’s arrow facing up. Lift the upper tower assemblies onto the lower tower assembly aligning the exposed studs. Secure the upper tower to the lower using four PC60614 Kept Nuts.
  • Page 64 STEP 65: Repeat step 64 for the 3B right side archway. STEP 66: The Right harness connectors will not fit the let side. Before lifting up onto the base, make sure the arrows are facing down for right and up for left. LEFT SIDE HARNESS RIGHT SIDE HARNESS...
  • Page 65 STEP 67: Peel covers then install front cover using eight AA6514. X’s 8 AA6514 - 8 1/2 pan head silver STEP 68: Attach 3E, 3F, and 3G together to make the top archway. Use eight AA6281 and AA6212 washers. Connect harnesses. QTY 8 AA6281 1/4-20 X 1-½...
  • Page 66 STEP 69: Partly install two AA6281 Allen bolts and AA6212 washers on each side on the arch assembly. There should be about 1/2 sticking out. X’s 4 AA6281 1/4-20 X 1-1/2 BLACK AA6212 1/4 X 3/4 black washer STEP 70: With a helper, raise the arch onto the brackets.
  • Page 67 STEP 71: Secure the arch assembly with two PC60622 and AA6212 on each side. Then tighten the bolts used to hook the arch assembly to the bracket. X’s 4 PC60622 1/4-20 X 1 (BLACK) AA6212 1/4 X 3/4 black washer STEP 72: Connect the arch wiring on the left and right sides of the towers.
  • Page 68 Chapter 9 Assembly for Steps 73- 81. HARDWARE NEEDED AA6630 1/4-20 x 4 QTY 6 AA6125 1/4-20 X 2-1/2 QTY 31 AA6281 1/4-20 X 1-1/2 QTY 4 PC60622 1/4-20 X 1 QTY 14 AA6062- 8-32 x 1 1/4 pan head silver QTY 4 AA6966 1/4-20 nylock QTY 28 AA6212 1/4 X 3/4 FLAT WASHER QTY 36 AA6185 1/4 x...
  • Page 69 Pallet 2, bundle 1, 2R Pallet 2, bundle 1, 2R Pallet 2, bundle 1, 2R Pallet 2, bundle 1, 2R Pallet 2, bundle 1, 2Q Pallet 2, bundle 1, 2Q Pallet 1, bundle 2, 1T QTY 2 Pallet 1, loose, 1M Pallet 2, bundle 1, 2T Pallet 2, bundle 1, 2U Pallet 2, loose, 2I...
  • Page 70 STEP 73: Slide 2I and 2J together aligning the two arrows to face each other. STEP 74: Attach 2I and 2J assembly using two AA6630 black bolts and AA6212 black washers from the top and AA6212 black washer and AA6966 nylock nut at the bottom on the arches at both ends. Use one AA6125 bolt and AA6212 washer to attach the2I and 2J assembly support to the marquee.
  • Page 71 STEP 75: Attach two1T bars to the left and right ends of the cabinet for the roof supports using AA6630 black Allen bolts and AA6212 washers from the top and AA6212 black washers with AA6966 nylon nuts from the bottom. X’s 4 AA6630 1/4-20 x 4 black Allen AA6212 1/4 X 3/4...
  • Page 72 STEP 76: At the back and front of the cabinet, secure the 2S tarp with 22 AA6125 black Allen bolts and AA6185 large black washers at the top. From the bottom, use AA6212 black washer and AA6966 nylock nuts. SEE RED ARROWS. 11 per back and front. X’s 36 AA6125 1/4-20 X 2-1/2 AA6966 1/4-20...
  • Page 73 STEP 78: Partly install four AA6281 bolts. X’s 4 AA6281 1/4-20 X 1-1/2 BLACK STEP 79: Attach the 2T and 2U flames onto the marquee using four AA6062 8-32 screws. AA6062- 8-32 x 1 1/4 pan head silver QTY 4...
  • Page 74 STEP 80: Lift the marquee sign up onto the marquee assembly aligning the holes and sliding it down onto the bolts. Tighten using small Allen wrench. STEP 81: Attach two 2Q ball deflectors using four AA6125 black Allen bolts and AA6212 black washers at the front, 2R mounting plate at the back.
  • Page 75 FROM FRONT TO BACK, RIGHT SIDE, AC POWER, COMS, AND DATA During setup you uncoiled the main AC wiring, COMS and Data lines. From underneath the cabinet, plug them into the back of the cabinet harnesses. AC plugs into the power module at the back cabinet wall.
  • Page 76 Universal Card link Connection See Wiring Insert for wire colors and which connections are used. Pin 1. +12v- Supply to Card System = Minimum of 2A available for the card systems and a Max of 3A. Pin 2. Coin 1 - input to the game PCB. Pin 3.
  • Page 77 PROGRAM SETTINGS - DIAGNOSTICS - VOLUME - POWER CONTROLS Located at the front is a center access panel. It contains the operator control panel boards, amplifier for volume, Fuse board, one DC power supply, and AC power control. Located in the middle of the playfield is another access hatch.
  • Page 78: Program Settings

    PROGRAM SETTINGS To enter programming mode, open the center access door and press the LEFT Front board’s “prog” button. The right Font board’s “prog” will NOT enter programming. The jumbotron will display the first option and the value for it. Use the “UP” and “DOWN” buttons or the left side arrows to change the value.
  • Page 79 Version 3.0 Option /Description Min/Max/Inc/Default Attract Time - How often attract audio is played in 30 seconds increments 0/30/1/1 COIN 1 - Cost of play per pulse. Set to 1 if using card swipe. 0/9/1/1 DBV - Cost of play for DBV or Coin line 2. NOT A MULTIPLIER! 0/9/1/1 Ticket Multiplier - 0 = Play for fun, 1 = Normal 1 to 1 ticket, 2 = ½...
  • Page 80 Diagnostics and trouble shooting guide Your game comes with extensive diagnostics to aid you in keeping your game running correctly. To access the diagnostics, open the left lower door assembly. Press the “SELECT” and “DOWN” buttons at the same time in attract mode. GAME MUST BE IN ATTRACT MODE TO ENTER DIAGNOSTICS In diagnostics, the Jumbotron will show the layout of the sensor boards.
  • Page 81 When in diagnostics if you press the “Press to enter initials” button it will cycle through the sensor board numbers and light the location of the sensor. Each press of any podium button will flash that button. You can use either side. When you press the “LEFT”...
  • Page 84 Tower Covers Part Numbers...
  • Page 85 DECAL PART NUMBERS...
  • Page 86 DB3216X Leaderboard Assembly and Parts The leaderboard assembly contains the leaderboard displays, two WR2032X five digit displays, Multiple LED strips, WH2236X matrix display board, 2 RB2009EX receiver sensors, 2 FP2009EX Transmitter boards, DB3102X Blocker arm and motor assembly, three DB2033X target boards, two ML2032X display boards, and a DB3068X Dot Matrix Grid.
  • Page 87 DB3216X Leaderboard Assembly and Parts WR2032X WR2032X NB2035DB SX2535DBX BLUE ML2032X - Display ML2032X - Display DB3054 - Display cover DB3054 - Display cover AA6953 - Hardware AA6953 - Hardware AA6753 AA6281 AA6281 DB3111 DB3112 PC60643 AA0644 RB2009EX AA0675 AA0675 FP2009EX DB3111 DB3155...
  • Page 88 Removing the DB3102X Blocker arm & Motor assembly 1) Remove DB3068X leaderboard display first then remove the four AA6177 screws holding the DB3154 Motor guard plate to the cabinet. 2) Remove the four AA6967 shoulder bolts and BL1086 springs. AA6967 BL1086 3) Remove the six AA6831 Phillip screws holding the Motor/gearbox assembly.
  • Page 89 DB3102X Swing Arm Assembly DB3100 DB1054 AA6212 DB3101 AA6915 PC60604 AA6831 DB7032X DB3849X - Button Target DB3847 MZ2005 AA6926 AA6177 PC60643 AA6584 ML2032X DB3845X DB2033X AA6203 AA0644...
  • Page 90 E02907BLX DB2033X BL4009 AA6020 AA0655 DB4001 AA6227 DB1045 DB4045 DB4045 DB1045 AA6072 E01662 AA6512 PC60610 DB1052 3 per game! DB1053 DB1051 WH3005 FB2008DBX Target Assembly DB3500X PC60610 AA6438...
  • Page 91 DB3277X- ball-gate Assembly NS1022-P802 (black) NS1022-P509 (blue) ZS2015X Actuator...
  • Page 92: Main Board

    BALLGATE: How to measure the voltage at connector P15 when testing your actuators. Do not measure between the black/blue and orange/blue on P15, you will never see the12VDC. Use pin 5 or 6 on P11 (where the black wires go to). Your should see the following: ●...
  • Page 93 Trouble Shooting Tips DB2033X - TARGET BOARDS On power up each target board will first display the version number of the firmware. It then will identify their location ID. Any board that is showing “888” has failed and should be replaced.
  • Page 94 Target arms not moving or partially but motor is fine O-RING or Spring washers are pinched in assembly. Two springs where used. Short spring washers have Ø1.225 O.D.; Tall spring washers have Ø1.103 O.D. Short spring washers require two to be installed. How to test your target assembly: Coin in a 2 player game and allow it to run All targets should present in round 2, final score should be 0-0...
  • Page 95 Spare Parts list: Electronic Parts: Misc. Items. DB2033X Target Board DB3024X Case of 6 dodgeballs FB2008DBX Target Motor DB4001 O-Ring .326 ZS2015X Actuator DB1052 Target Wave Spring MZ2005 Large push button E00039 8 Amp Fast BLO fuse GF2008D Gear box for swing arm E08702 7’...
  • Page 96: Warranty Policy

    (including labor) that is performed by such a distributor. Innovative Concepts in Entertainment 10123 Main St. Clarence, NY 14031 Phone #: (716) - 759 – 0360 Fax #: (716) – 759 – 0884 www.icegame.com...
