Infrared Sauna Instruction Manual
Models MX-M206-01 (SJ-8223) / MX-M306-01 (SJ-8323)
2 and 3 Person Infrared Saunas
FOR CARBON MODEL SAUNAS
RED CEDAR MODELS
FOR INDOOR USE ONLY
120V/15AMP DEDICATED CIRCUIT REQUIRED FOR MX-M206-01 (SJ-8223)
120V/20AMP DEDICATED CIRCUIT REQUIRED FOR MX-M306-01 (SJ-8323)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Maxxus MX-M206-01
Summary of Contents for Maxxus MX-M206-01
- Page 1 Infrared Sauna Instruction Manual Models MX-M206-01 (SJ-8223) / MX-M306-01 (SJ-8323) 2 and 3 Person Infrared Saunas FOR CARBON MODEL SAUNAS RED CEDAR MODELS FOR INDOOR USE ONLY 120V/15AMP DEDICATED CIRCUIT REQUIRED FOR MX-M206-01 (SJ-8223) 120V/20AMP DEDICATED CIRCUIT REQUIRED FOR MX-M306-01 (SJ-8323)
-
Page 2: Table Of Contents
Thank you for choosing Maxxus Infrared Sauna! Table of Contents ===================================== Page Important Safety Guides…………………………………………………..… Introduction…………………………………………………………...…….… Health & Beauty Benefits………………………………………………….… Highlights…………………………………………………………..….….…… Assembly…………….…………….………………………………………….. Schematic Diagram………………………….…………………………..…. Sauna Operation…...………………………………………………………..… Tips For Using Your Sauna…………………………………………….…..…. Safety Instructions……………………………………………………..………. Safeguards For Your Sauna…..………………………………….………….… 15 Troubleshooting..……………………………………………………….…..…… 16 Maintenance………………………………………………………….………..…... -
Page 3: Important Safety Guides
READ IMPORTANT SAFETY GUIDES BEFORE USING! READ AND FOLLOW ALL INSTRUCTIONS A). Please following all warning labels and markings on the sauna room. B). Do not install any receptacles on the interior or exterior walls of the sauna room. C). No locking devices are installed or shall be installed on the door of the sauna room which could result in entrapment within the sauna room. -
Page 4: Introduction
M). Never sleep inside the sauna. N). Do not use any type of cleaning agents on the interior of the sauna. Only wipe down with a cloth and water. O). Do not stack or store any object on top or inside the sauna. P). -
Page 5: Highlights
Highlights a. High quality craftsmanship b. Automatic thermostat for constant temperature c. Timer and buzzer: buzzer sounds 5 minutes before the end of the sauna session d. Digital sensor and thermometer e. Infrared carbon heat emitter panels Wiring diagram: Assembly Assembly Requirements Please note that your sauna has been completely assembled and tested at the factory prior to packaging. -
Page 6: Schematic Diagram
MX-206-01 (SJ-8223) FIG-1 Schematic Diagram MX-306-01 (SJ-8323) FIG-2 Schematic Diagram... - Page 7 3. 2-person sauna models are packed into two cartons and 3-person sauna models are packed into three cartons. For example: C/NO: A = A OF AB and C/NO: C = C OF ABC. See FIG-3 FIG-3 Cartons 4. Place the Floor Panel on a smooth/flat surface and make sure which side is the front and which side is the back. The front of the floor will have a slant.
- Page 8 6. Align the Left Side Panel with the Back Panel. Be sure to make sure the Left Side Panel fits flush into the Back Panel. See FIG-6 and FIG-7 FIG-6 Assembling Left Side Panel FIG-7 Buckle 7. Latch the Left Side Panel with the Back Panel. The buckle has a guide tab that must be placed in the guide slot for alignment.
- Page 9 9. Latch the Right Side Panel with the Back Panel. The buckle has a guide tab that must be placed in the guide slot for alignment. When the Back Panel and the Side Panel are attached together on the Floor Panel, make sure all the buckles are latched.
- Page 10 12. Place the Front Panel up and onto the Floor Panel and align it with both the Left and Right Side Panels. Next, latch the Front Panel with the Left and Right Side Panels respectively. Note: Be cautious with the glass door to avoid breakage.
- Page 11 15. Connect the control panel connectors. See FIG-15 FIG-15 Connecting control panel connectors 16. Make sure all steps are completed correctly. Plug in the power cord to your wall outlet. Turn on the sauna at the control panel to confirm that the control panel is responding. If the control panel responds accordingly, t hen proceed in putting the Roof Dust Cover onto the Roof Panel.
-
Page 12: Sauna Operation
Sauna Operation 1. Precautions a. Please make sure your wall outlet meets the specifications required. Failure to meet the requirements may cause safety risks. a. Set the temperature and time to a comfortable level. The average used temperature range is between 118ºF –... - Page 13 d. Press the button to turn the light ON. If you want to use the Color Light Therapy System: 1. While the interior light is ON, press and hold down the button for 2 seconds. You will notice “2n” in the LED display. This indicates you are in the “light” mode. If you do not press any buttons for approximately 15 seconds, the “2n”...
-
Page 14: Tips For Using Your Sauna
The MP3 Jack will allow you to connect your musical device using the AUX wire. Plug one end of the AUX wire into your musical device and the other end into the MP3 Jack at the ceiling. Do not leave the AUX wire connected at the ceiling when not using this function as it may cause static interference at the speakers. -
Page 15: Safety Instructions
Safety Instructions Read and follow all instructions carefully before using the sauna. 2. When assembling and using the electrical equipment, safety precautions should always be followed. 3. To reduce the risk of injury, do not allow children to use the sauna unless they are closely supervised at all times by an adult. -
Page 16: Safeguards For Your Sauna
16. Do not use the sauna during an electrical storm to avoid risk of shock or injury. 17. Do not continuously switch the power ON and OFF excessively as it will compromise the life of the electrical components. 18. Your hands must be dry and free of moisture before plugging and unplugging cords and wiring harnesses from the power supply and circuit boards. -
Page 17: Troubleshooting
Troubleshooting: problem possible reason countermeasure indicator light for power The connector is not connected Check the connector or replace a new supply not working properly No power supply input Check your circuit breaker to confirm power at the wall outlet Indicator light is broken replace the circuit panel Indicator light for function... -
Page 18: Maintenance
The speaker wire is loose Disconnect and reconnect the speaker connections The power indicator light for CD is off Turn on the switch to start work Bluetooth Connection Device will not connect to Bluetooth Check your device and pair with BT-AUDIO Device will not connect to Bluetooth You can only connect a single device... -
Page 19: Warranty
Limited Lifetime Warranty *Limited Lifetime Warranty: Golden Designs, Inc. warranties the heating elements and electronics against defects in material and workmanship for the life of the product from the original date of purchase. This sauna is for INDOOR use only. Placing your sauna outdoors will VOID this warranty. - Page 20 consequential costs, expense or damages - which may include the removal of permanent deck or other custom fixtures or the necessity for crane removal - arising directly or indirectly out of the use or inability to use the product. Any impli ed warranty shall have duration equal of the applicable warranty stated above.
-
Page 21: Warranty Card
WARRANTY CARD Congratulations on your purchase of an Infrared Sauna from Golden Designs, Inc. Please take the time to complete the following Warranty Card and mail it back to: Golden Designs, Inc. 3550 Jurupa Street, Unit B Ontario, CA 91761 Please include a copy of your sales receipt showing date of purchase as this will serve as proof of purchase.
