Summary of Contents for Crestron WMKU-4SM
- Page 1 Crestron WMKU-4SM Universal Wall Mount Kit for TPMC-4SM Series Installation Guide...
- Page 2 1-888-CRESTRON Regulatory Compliance As of the date of manufacture, the WMKU-4SM has been tested and found to comply with specifications for CE marking and standards per EMC and Radiocommunications Compliance Labelling. All brand names, product names and trademarks are the property of their respective owners.
-
Page 3: Table Of Contents
Crestron WMKU-4SM Wall Mount Kit for TPMC-4SM Series Contents Universal Wall Mount Kit for TPMC-4SM Series: WMKU-4SM Introduction ..........................1 Setup ............................2 Supplied Hardware ...................... 2 Installation ........................3 Resources........................... 8 Further Inquiries ......................8 Future Updates ......................8 Return and Warranty Policies .................... -
Page 5: Universal Wall Mount Kit For Tpmc-4Sm Series: Wmku-4Sm
Universal Wall Mount Kit for TPMC-4SM Series: WMKU-4SM Introduction ® The WMKU-4SM is a universal wall mount kit for Crestron TPMC-4SM Series touchpanels. It is designed for use with 1-gang and 2-gang U.S. electrical boxes and double gang European electrical boxes. WMKU-4SM Dimensions 4.74 in... -
Page 6: Setup
Wall Mount Kit for TPMC-4SM Series Crestron WMKU-4SM Setup Supplied Hardware The hardware supplied with the WMKU-4SM is listed in the following table. Supplied Hardware for the WMKU-4SM DESCRIPTION PART NUMBER QUANTITY Plastic Enclosure, Black 2028284 Plastic Enclosure, White 2028283 Screw, #04-40 x 3/4”, Flat,... -
Page 7: Installation
Crestron WMKU-4SM Wall Mount Kit for TPMC-4SM Series Installation Complete the following steps to install the WMKU-4SM. Refer to the illustrations that follow this procedure. 1. Insert a small slot head screwdriver into the hole shown in the following illustration and gently separate the back of the touchpanel. - Page 8 Screws (2) #06-32 x 1 1/2” (2007254) Screws (2) #04-40 x 3/4” For standard applications: Phillips (2029111 or 2029110) For secure applications: security type Torx (2029108 or 2029112) 4 • Wall Mount Kit for TPMC-4SM Series: WMKU-4SM Installation Guide – DOC. 6978A...
- Page 9 Screws (2) #06-32 x 1 1/2” (2007254) Screws (2) #04-40 x 3/4” For standard applications: Phillips (2029111 or 2029110) For secure applications: security type Torx (2029108 or 2029112) Wall Mount Kit for TPMC-4SM Series: WMKU-4SM • 5 Installation Guide – DOC. 6978A...
- Page 10 Screws (4) #06-32 x 1 1/2” (2007254) Screws (2) #04-40 x 3/4” For standard applications: Phillips (2029111 or 2029110) For secure applications: security type Torx (2029108 or 2029112) 6 • Wall Mount Kit for TPMC-4SM Series: WMKU-4SM Installation Guide – DOC. 6978A...
- Page 11 Screws (2) #M3.5 x 25 mm (2028659) Screws (2) #04-40 x 3/4” For standard applications: Phillips (2029111 or 2029110) For secure applications: security type Torx (2029108 or 2029112) Wall Mount Kit for TPMC-4SM Series: WMKU-4SM • 7 Installation Guide – DOC. 6978A...
-
Page 12: Resources
Crestron at 1-888-CRESTRON [1-888-273-7876]. You can also log onto the online help section of the Crestron Web site (www.crestron.com/onlinehelp) to ask questions about Crestron products. First-time users will need to establish a user account to fully benefit from all available features. -
Page 13: Return And Warranty Policies
Purchasers should inquire of the dealer regarding the nature and extent of the dealer's warranty, if any. CRESTRON shall not be liable to honor the terms of this warranty if the product has been used in any application other than that for which it was intended or if it has been subjected to misuse, accidental damage, modification or improper installation procedures. - Page 14 Wall Mount Kit for TPMC-4SM Series Crestron WMKU-4SM This page is intentionally left blank. 10 • Wall Mount Kit for TPMC-4SM Series: WMKU-4SM Installation Guide – DOC. 6978A...
- Page 15 Crestron WMKU-4SM Wall Mount Kit for TPMC-4SM Series This page is intentionally left blank. Wall Mount Kit for TPMC-4SM Series: WMKU-4SM • 11 Installation Guide – DOC. 6978A...
- Page 16 Crestron Electronics, Inc. Installation Guide – DOC. 6978A 15 Volvo Drive Rockleigh, NJ 07647 (2027425) Tel: 888.CRESTRON 08.10 Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
