Pulsar PSB251215 Quick Start Manual

•
DC 13,8V/1,5A uninterruptible power supply
•
wide AC input voltage range 176÷264V
•
high efficiency 70%
•
controlling of battery charging and maintaining
•
protecting of battery against excessive
discharging (UVP)
•
battery charging current 0,5A

1. Technical description.

1.1 General description.

Buffer-type power supply units are intended for continuous power supply to devices that require stabilised voltage
of 12 V DC (+/-15%). The power supply provides a voltage of U=13,8 V DC with an output current of I=1A+ 0,5A battery
charging. In case of power voltage decay, prompt switching to battery supply occurs. The power supply has the
following protections: short-circuit (SCP), overload (OLP) and overvoltage (OVP).
Under normal operation, the total current drawn by the equipment may not exceed I = 1 A; Maximum
battery charging current: 0.5 A. Total device current + battery: 1,5 A max.

1.2. Technical parameters.

Supply voltage
Current consumption
Supply power
Efficiency
Output voltage
Output current
Output current t
AMB
Output current t
AMB
Voltage adjustment range
Ripple voltage
Battery charging current
Short-circuit protection SCP
Overload protection (battery) OLP
Overvoltage protection OVP
Excessive discharge protection UVP
Optical signalisation
Output of optical signalization
Operation conditions
Dimensions (LxWxH)
Net/gross weight
Protection class PN-EN 60950-1:2007
Connectors
Features of the power supply:
<30° C
=40° C
PSB251215
PSB 13,8V/1,5A enclosed switch
mode buffer power supply
Edition: 1 from 08.03.2012
Supercedes edition:
•
battery output is full protected against short-
circuit and reverse connection
•
LED optical signalisation
•
protections:
•
•
•
•
176÷264V AC 50Hz
0,35A@230VAC max.
25W max.
70%
13,8V DC – buffer operation
9,5V÷13,8V DC – battery operation
1A + 0,5A battery charging
1A + 0,5A battery charging - refer to graph 1 .
0,7 A + 0,5A battery charging - refer to grap h 1.
12÷14V DC
120mV p-p max.
0,5A max
electronic
polymer fuse (PTC)
U>115% ÷ 150% of the output voltage, isolation of the
output voltage, atomatic recovery
U<9,5 V (± 5%) – disconnection of battery
green LED- presence of AC voltage
LED AC- presence of AC voltage
LED DC- presence of DC voltage on power supply output
2-nd enviromental class, temperature: -10
relative humidity 20%...90%, without condensation
110 x 78 x 36 [mm]
0,28kg / 0,31kg
I (first) - requires a protective conductor (PE)
power-supply: Φ0,63÷2,5 I/O PCB : Φ0,41÷1,63
battery output BAT: 6,3F-2,5/40cm,
output of optical signalization: plug 3-pin 5 mm
1
SCP short-circuit protection
OVP overvoltage protection
overvoltage protection (output AC)
overload (OLP)
o
C÷40
EN
o
C
