When you have finished viewing (and adjusting if desired) the
■
refrigerator set point, press TEMPERATURE to change the display
to show the freezer set point. When the zone has been changed,
"FREEZER" appears on the display screen.
Press LOCK to raise the set point, or press OPTIONS to lower the
■
set point.
When you have finished viewing (and adjusting if desired) both the
■
refrigerator and freezer set points, press MEASURED FILL to save
the settings.
NOTE: To exit without saving changes, press ICE MODE at any
time while in adjust mode, or allow about 60 seconds of inactivity
and adjust mode will turn off automatically.
When adjusting temperature set points, use the following chart as a
guide.
CONDITION:
REFRIGERATOR too cold
REFRIGERATOR too warm
FREEZER too cold
FREEZER too warm /
Too little ice
The set point range for the refrigerator is 33°F to 42°F (0°C to 6°C).
The set point range for the freezer is -9°F to 5°F (-23°C to -15°C).
Cooling On/Off
Your refrigerator and freezer will not cool when cooling is turned off.
To turn cooling off, press and hold the LOCK and MEASURED
■
FILL buttons at the same time for 3 seconds.
IMPORTANT: To avoid unintentionally locking the dispenser or
changing other settings, be sure to press both buttons at exactly
the same time.
When cooling is off, "REFRIGERATION COOLING IS OFF" will
appear on the display screen.
Press and hold LOCK and MEASURED FILL for 3 seconds again
■
to turn cooling back on.
Additional Features
Max Cool and Max Ice
The Max Cool feature assists with periods of heavy ice usage, full
grocery loads, or temporarily warm room temperatures.
The Max Ice feature assists with temporary periods of heavy ice use
by increasing ice production over a 24-hour period.
To turn on the Max Cool feature, press the OPTIONS button
■
to enter Options mode, then press OPTIONS again to
activate the feature. The Max Cool icon will appear on the
dispenser display.
The Max Cool feature will remain on for 24 hours unless manually
turned off. To manually turn it off, press the OPTIONS button to
enter Options mode (unless you are already in Options mode),
then press OPTIONS again. When the feature has been turned off,
the Max Cool icon will disappear on the dispenser display.
To turn on the Max Ice feature, press the OPTIONS button to
■
enter Options mode, then press the TEMPERATURE button
to activate the feature. The Max Ice icon will appear on the
dispenser display.
The Max Ice feature will remain on for 24 hours unless manually
turned off. To manually turn it off, press the OPTIONS button to
enter Options mode (unless you are already in Options mode),
then press TEMPERATURE. When the feature has been turned off,
the Max Ice icon will disappear on the dispenser display.
TEMPERATURE
ADJUSTMENT:
REFRIGERATOR Setting
1° higher
REFRIGERATOR Setting
1° lower
FREEZER Setting
1° higher
FREEZER Setting
1° lower
When Max Cool and/or Max Ice are active, the temperature display
will not change. After 24 hours, the refrigerator returns to the previous
temperature set points.
NOTE: If increased ice production is desired at all times, change
the freezer control to a lower setting. Setting the freezer to a colder
temperature may make some foods, such as ice cream, harder.
Sabbath Mode
Sabbath Mode is designed for those whose religious observances
require turning off the lights and dispensers.
In Sabbath Mode, the temperature set points remain unchanged, but
the interior and dispenser lights turn off, all sounds and alarms are
disabled, the dispenser display screen backlight turns off, and the
dispenser pads are disabled.
To turn on Sabbath Mode, press and hold LIGHT and OPTIONS at
■
the same time for 3 seconds. When the feature turns on, "Sabbath
Mode" will appear on the dispenser display.
To turn off Sabbath Mode, press and hold LIGHT and OPTIONS at
■
the same time for 3 seconds again.
Power Outage Indicator
The power outage indicator lets you know if the power supply to the
refrigerator has been cut off and the freezer temperature has risen to
18°F (-8°C) or higher.
When power has been restored, "PO" repeatedly flashes
on the display screen and the red Power Outage icon
appears.
When the indicator is on, all other control and dispenser functions are
disabled until you confirm that you are aware of the power outage.
To enable other functions, press MEASURED FILL to reset the
■
display screen to its normal status.
Door Ajar Alarm
The Door Ajar Alarm feature sounds an alarm when the refrigerator or
freezer door is open for 5 minutes and the product cooling is turned
on. The alarm will repeat every 2 minutes. Close both doors to turn it
off. The feature then resets and will reactivate when either door is left
open again for 5 minutes.
NOTE: To mute the audible alarm while keeping the doors open,
such as while cleaning the inside of the refrigerator, press any
button on the control panel. The alarm sound will be temporarily
turned off, but the Door Ajar icon will still be displayed on the
dispenser control panel.
Disabling Sounds
To turn off all control and dispenser sounds, press and hold ICE
■
and MEASURED FILL at the same time for 3 seconds.
To turn all sounds back on, press and hold ICE and MEASURED
■
FILL at the same time for 3 seconds again.
Dual Evaporator (on some models)
Some models come equipped with a dual sequential evaporation
system, which includes two separate evaporators for the refrigerator
and freezer compartments.
Dual evaporation results in higher humidity, which helps keep foods in
the refrigerator from spoiling as quickly and improves food quality and
freshness in the freezer due to decreased freezer burn. In addition,
the dual evaporation system helps keep food smells in the refrigerator
from transferring to ice in the freezer.
NOTE: The dual evaporation system is always activated when your
refrigerator is operating. You do not need to press any buttons to turn
it on.

Convertible Drawer Temperature Control

The control can be adjusted to properly chill meats or vegetables. The
air inside the pan is cooled to avoid "spot" freezing and can be set to
keep meats at the National Livestock and Meat Board recommended
storage temperatures of 28° to 32°F (-2° to 0°C).
To store meat:
Set the control to one of the three MEAT settings to store meat at its
optimal storage temperature.
3
