2. You can dispense water by the ounce, cup, or liter. The default
unit is ounces. To switch to cups or liters, press the LIGHT button.
Default, minimum, and maximum volumes are listed below.
Units Default
Ounces 8
Cups 1
Liters 0.25
3. Press the LOCK and OPTIONS buttons to adjust the volume
as desired. The LOCK button increases the volume, and the
OPTIONS button lowers the volume.
NOTES:
When increasing or decreasing the volume, the control
■
may stop responding if an adjustment button is held for
approximately 10 seconds or longer. Release the button for
approximately 2 seconds, then continue making adjustments.
Most coffee cups (commonly 4 to 6 oz [118 to 177 mL] per
■
cup) are not the same size as a measuring cup (8 oz [237 mL]).
You may need to adjust the volume to avoid unintentionally
overfilling coffee cups.
4. To dispense water, press a sturdy glass against the water
dispenser pad OR place the glass below the water dispenser and
press the MEASURED FILL button. Hold the glass close to the
water dispenser spout to ensure that the water dispenses into the
glass.
A. Water dispenser spout
NOTE: While dispensing water, the digital display will count down
how much water remains to be dispensed, according to the volume
you selected. The flow of water will automatically stop once the
desired volume has been dispensed.
5. To stop dispensing before the selected volume has been
dispensed, remove the glass from the dispenser pad OR press the
MEASURED FILL button a second time.
NOTE: If you stop dispensing before the desired volume has been
dispensed, the digital display will continue to show how much
water remains to be dispensed. The display will turn off after 1
minute of inactivity.
To select a new volume or start dispensing the same volume
again, you must first finish dispensing the selected volume, or turn
off the Measured Fill feature (either by waiting 1 minute so it will
automatically turn off or by pressing ICE MODE to manually turn it
off) and then turn it back on.
The Ice Dispenser
Ice dispenses from the ice maker storage bin in the freezer when the
dispenser pad is pressed. To turn off the ice maker, see "Ice Maker
and Storage Bin."
Your ice maker can produce both
crushed and cubed ice. Before
dispensing ice, select which type of
ice you prefer by pressing the
ICE MODE button.
The display screen indicates which
type of ice is selected.
For crushed ice, cubes are crushed before being dispensed. This may
cause a slight delay when dispensing crushed ice. Noise from the ice
crusher is normal, and pieces of ice may vary in size. When changing
from crushed to cubed, a few ounces of crushed ice will be dispensed
along with the first cubes.
Minimum Maximum
1 128
1/4 16
0.05 4.00
A
CRUSHED CUBED
To Dispense Ice:
1. Make sure the desired type of ice is selected. To switch between
cubed and crushed, press ICE MODE.
Use a sturdy glass when dispensing ice.
Failure to do so can result in cuts.
2. Press a sturdy glass against the ice dispenser pad. Hold the glass
close to the ice guide to ensure that the ice dispenses into the
glass.
IMPORTANT: You do not need to apply a lot of pressure to the
pad in order to activate the ice dispenser. Pressing hard will not
make the ice dispense faster or in greater quantities.
3. Remove the glass to stop dispensing.
NOTE: Ice may continue to dispense for several seconds after
removing the glass from the pad. The dispenser may continue to
make noise for a few seconds after dispensing.
The Dispenser Light
When you use the dispenser, the light will automatically turn on. If you
want the light to be on continuously, you may choose either ON or
DIM. The display screen indicates which mode is selected.
ON
ON: Press LIGHT to turn the dispenser light on.
DIM: Press LIGHT a second time to select DIM mode. The dispenser
light will remain on, but at a lower intensity.
OFF: Press LIGHT a third time to turn the dispenser light off.
If the dispenser lights do not appear to be working as described in
"Water and Ice Dispensers" (in the User Instructions, User Guide, or
Use & Care Guide) or if the interior lights do not illuminate when either
door is opened, call for assistance or service. See either the front
cover or the Warranty for contact information.
The Dispenser Lock
The dispenser can be turned off for easy cleaning or to avoid
unintentional dispensing by small children and pets.
5
WARNING
Cut Hazard
A. Ice guide
DIM OFF
A
