Neptronic DTS Specification & Installation Instructions

Technical Data

Auxiliary switches
Feedback
Power supply
Power consumption
Control signal
Torque
Running time through 90º
Ingress protection
Approvals
Fail safe - Enerdrive
Electrical connection
Inlet bushing
Angle of rotation
Direction of rotation
Ambient temperature
Storage temperature
Relative Humidity
Weight

Warning: Do not press the clutch when actuator is powered

Dimensions

Caution
We strongly recommend that all neptronic® products be wired to a separate transformer and that transformer shall service only neptronic® products. This precaution will
prevent interference with, and/or possible damage to incompatible equipment.
When multiple actuators are wired on a single transformer, polarity must be observed. Long wiring runs create voltage drop which may affect the actuator performance.
1
Enerdrive System U.S.A. Patent #5,278,454
DTS-210803

Feature:

• Mounts easy on round
& square shaft (with option –8).
• External clutch for manual adjustments.
• Maintenance free.
• Position indicator.
• Fail safe by Enerdrive System
• Auxiliary switches
(on model 80S).
DT060S DT065S DT080S
No No
No Yes
22 to 26 VAC or 28 to 32 VDC
15VA Peak, 6VA
2 wire / 2 position, 4 wire / 3 point floating
50 in.lb. [5,6 Nm] at rated voltage
(Fail-safe 35 in.lb. [3,9 Nm])
90 - 110 sec, (Fail-safe 70-80 sec)
IP22 equivalent to Nema type 2,
IP54 equivalent to Nema type 3R if
water tight inlet bushings (not supplied
NEP617) are installed
0 to 90 degrees, mechanically adjustable (factory set with 90º stroke)
Reversible, Clockwise (CW) or Counterclockwise (CCW) (factory set with CW direction)
Specification & Installation instructions
1
DT160S DT165S
Yes (2) No No
No No Yes
110 to 130 VAC 50/60Hz
3 wire / 2 position, 4 wire / 3 point floating
Yes
18 AWG [0.8 mm
2 inlet bushings: 13/16" [20.6mm]
-22ºF to +122ºF [-30ºC to +50ºC]
-22ºF to +122ºF [-30ºC to +50ºC]
5 to 95 % non condensing.
3 lbs. [1.4 kg]
Dimension
A
B
C
model 0XX
D
model 1XX & 2XX
DTS Actuator
DT180S DT260S
Yes (2) No
No No
220 to 250 VAC 50/60Hz
12VA Peak, 6VA
35 in.lb. [4 Nm] at rated voltage
90 - 110 sec, (Fail-safe25-50 sec)
IP22 equivalent to Nema type 2
Class 2
2
] minimum
Inches
1.50
3.64
6.60
3.02
3.81
DT060S
DT065S
DT080S
DT160S
DT165S
DT180S
DT260S
DT265S
DT280S
DT265S DT280S
No Yes (2)
Yes No
Metric (mm)
38.1
92.5
167.5
76.8
96.8
