PENCO Clipper Assembly Instructions

1A
1B
1C
1A BOX POST (FRONT ONLY)
1B OFFSET ANGLE POST
1C SHELF
1D CLIPPER SHELF CLIP
IMPORTANT NOTE
Shelf clip must be seated properly
on posts by lightly tapping top of
clip into slots. See illustration.
1. Check the number of packages (parts) received against the bill of lading. If any shortages,
secure a "shortage notation" from the carrier and file a claim. Check material for damage.
If any is damaged, secure a "damaged notation" from the carrier and file a claim against
carrier.
2. When unpacking, arrange like parts together as close as possible to the area in which they
are to be assembled.
3. Tools required are slotted screw driver and 7/16" and 1/2" socket wrenches to tighten bolts
and nuts.
4. Use the proper size bolts for each part. Use no more than the number of clips or bolts that
are allowed for each part.
5. Read remainder of these instructions carefully before you proceed further. Familiarize
yourself with all component names.
6. Carefully lay out shelving positions on floor (chalk line suggested).
7. Now follow the detailed instructions step by step.
Clipper
Assembly Instructions
1E
1D
Parts
1E SIDE SWAY BRACE
1F BACK SWAY BRACE
1GSIDE PANEL
1H BACK PANEL
1I BACK PANEL CLIP
1J HI-PERFORMANCE
1K CONVENTIONAL FLANGE SHELF
General Instructions
®
Shelving
1F
1H
1I
® SHELF
Clipper Shelving
Assembly Instructions
Part No. 08185
1G
1J
CAUTION
It is the responsibility of
the persons assembling the
shelving to properly install all
components and hardware as
specified in these instructions
and any accompanying drawings
for specific installations.
• Install all required Side and
Back Sway Braces
• Install Foot Plates and Shims
if required
• Tighten all hardware securely
1K
