PENCO Stadium Assembly Instructions

Optional
Security
Box and
Shelf
Optional
Footlocker
Locker
Frame
Side Panel
Bottom
Penco Products, Inc. 99 Brower Ave. • PO Box 378 • Oaks, PA 19456-0378
1-800-562-1000 • 610-666-0500 • Fax 610-666-7561
Stadium™
Locker Assembly Instructions
for Knocked Down Version

Assembly of Stadium Locker

All bolts are to be inserted on outside of locker while all
nuts are to be placed on the inside of the locker.
1. Place back panel on a pair of saw horses.
2. Bolt hooks to back panel.
3. Bolt one side panel to back panel.
4. Bolt bottom to side and back panel.
5. Bolt second side panel to bottom and back panel.
6. Loosely bolt shelf and rod holders to side panels and
insert rod into rod holder holes.
7. Bolt top to side panels and back panel.
8. Tighten bolts that anchor shelf and rod holders.
9. Place locker frame over outside edge of side panels, bottom and top and bolt together.
10.Stand locker upright and install on a level surface.
11. Line up number plate with holes at front of shelf and rivet into place.
We recommend that all lockers be anchored to the floor and / or wall.
See next page for instructions on assembling Security Box and Footlocker.
Back
Panel
with Back on Floor or Saw Horses
Shelf
Rod Holder
Rod
Hooks
• www.pencoproducts.com
page 1 of 2
Part No.
View of Locker
Top
Side Panel
