Remaco FAS Series Installation Manual

COPYRIGHTS 1998 REMACO TECHNOLOGIES PTE LTD
C
Important Notes:
All screens are thoroughly inspected and fully tested operational in factory. We accept no liability
whatsoever for any losses due to improper operation, or any unauthorized alternation. All trademarks
contained in this installation guide are the property of their respective owners.
Assembly Overview:
8
2
Packing List of Parts:
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
Installation Guide (FAS Series)
9
7
Vertical Frame x2
Front adjustable foot x2
Back adjustable foot x2
Foot horizontal frame x1
Skirting Support Frame x1
Screen Frame x1
Skirting x2
Front projection fabric X1 or rear projection fabric X1 (depend on the model)
Castor bar detachable x2
Flight case x1
2
Website: www.remacotech.com
6
5
10
3
1
4
9
V:3.0
FAS
1
