C
Step-1
Mount the wall plate to the solid concrete.
Step-3
a) Turn over WPS back frame
b) Secure lower frame hook at bottom of WPS
frame.
c) Secure marker tray at bottom of WPS as
shown.
Step-4
Side View of WPS
Installation Guide
Wall Plate
Lower Hook Frame
Lower Wall Support
(WPS Series)
Step-2
Attach hook bracket to WPS screen
Lower Hook Frame
V: 4.0
WPS
Hook Bracket
Front View of WPS
Marker Tray
Lower Wall Support
Lower Hook Frame
WPS
WPS Frame
Advertisement
Table of Contents
Related Manuals for Remaco WPS 1710W
Summary of Contents for Remaco WPS 1710W
- Page 1 V: 4.0 Installation Guide (WPS Series) Hook Bracket Step-1 Step-2 Wall Plate Attach hook bracket to WPS screen Mount the wall plate to the solid concrete. Step-3 a) Turn over WPS back frame Front View of WPS b) Secure lower frame hook at bottom of WPS frame.
- Page 2 46.4 cm Wall Plate Lower Wall Support Overall Size (cm) A (cm) B (cm) C (cm) D (cm) E (cm) WPS 1710W 176 x 111 104.5 WPS 2012W 197 x 125 118.5 WPS 2113W 219 x 138 131.5 WPS 2314W 238 x 150 143.5...
