Remaco BKT-M595 Installation Manual

C COPYRIGHTS 1998 REMACO TECHNOLOGIES PTE LTD
Important Notes:
All Plasma / LCD TV brackets are thoroughly inspected and fully tested operational in factory.
We accept no liability whatsoever for any losses due to improper operation, or any unauthorized alternation.
All trademarks contained in this installation guide are the property of their respective owners
BKT-M595 Motorized TV Lifter
(Top Cover-Type1)
H1
D1
Front Side
TV at Up Position
BKT-M595C/S 1037
BKT-M595C/M 1556
BKT-M595C/L 1770
Installation Guide (For BKT-M595)
Radio Frequency Remote Control
Up button
Stop button
Down button
AVA-315-RF 1Ch
Front View
Remark:
Dry Contacts for A/V Control System (e.g. AMX / Creston) Available
Variable
(10-20mm)
TV Height
Variable (10-20mm)
Contact Closure
Common (Yellow)
Stop (Green)
Down (Black)
Up (Red)
W1
W1 D1 H1
325 851
325 851
325 1063
.
Setting
button
AVA-315-RF 1Ch
Back View
H1
+
+
(Width x Depth x Height)
W2 D2
1087 360 W980 x D41 x H616
1606 360 W1470 x D41 x H755
1820 360 W1672 x D41 x H963
Website: www.remacotech.com
BKT-M595 Motorized TV Lifter
(Flip Cover-Type2)
W2
Front Side TV at
Down Position
Max.TV Size
(Diagonal)
V:5.0
BKT-M595
D2
42"
55"
75"
