C COPYRIGHTS 1998
REMACO TECHNOLOGIES PTE LTD
Installation Guide
Universal Bracket can be used for any type of installation as shown below.
Wall Mount
Ceiling
Recessed
Corner Mount
M6 Anchors
M6
Countersunk
Screws
Ceiling Mount
For Suspension from Ceiling
Insert these accessories in
between the indicated arrow.
(optional)
M6 Long Nuts
M5 Stopper
Screws
(For SAS-1515 to SAS-2424)
Pelmet Mount
Lanyard
* For details dimension , please refer to technical specifications at
www.remacotech.com
Website: www.remacotech.com
Ceiling
Suspension
AVA-Wall Ext/L - 25.0cm
AVA-Wall Ext/S - 12.5cm
Extension Mount (Wall)
Universal
Bracket
V: 4.0
SAS
Advertisement
Table of Contents
Related Manuals for Remaco SAS-1515
Summary of Contents for Remaco SAS-1515
- Page 1 C COPYRIGHTS 1998 REMACO TECHNOLOGIES PTE LTD Website: www.remacotech.com V: 4.0 Installation Guide (For SAS-1515 to SAS-2424) Universal Bracket can be used for any type of installation as shown below. Wall Mount Ceiling Ceiling Mount Suspension AVA-Wall Ext/L - 25.0cm AVA-Wall Ext/S - 12.5cm...
- Page 2 COPYRIGHTS 1998 REMACO TECHNOLOGIES PTE LTD Website: www.remacotech.com Important Notes: All screens are thoroughly inspected and fully tested operational in factory. We accept no liability whatsoever for any losses due to improper wiring, installation, operation, or any unauthorized alternation at the point of installation.
- Page 3 Recommended Operation of Semi-Auto Screen (SAS) Common issue when SAS Screen is left in down position overnight It is recommended to keep the screen (roll it up) if not in use. If it cannot retract by itself, please use your hand If SAS Screen is left in down position overnight, to gently push the screen up.
