RITEWAY F Series Operator's Manual & Parts List

Forward fold land roller
Hide thumbs

Advertisement

Quick Links

Download this manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the F Series and is the answer not in the manual?

Questions and answers

Related Manuals for RITEWAY F Series

Summary of Contents for RITEWAY F Series

  • Page 3 PAGE SECTION 1 INTRODUCTION & MANUAL INFORMATION PRE-DELIVERY INSPECTION / NOTES SPECIFICATIONS SERVICE AND WARRANTY INFORMATION SAFETY SUGGESTIONS 9,10 DECAL LOCATIONS 11,12 MAINTENANCE / GREASE LOCATIONS 13-18 OPERATING NSTRUCTIONS 19-28 ASSEMBLY INSTRUCTIONS GRADE CHART TORQUE CHART PAGE SECTION 2 1-30 PARTS 31-40 HYDRAULIC SCHEMATICS...
  • Page 6 Thank you for making the decision to purchase a RITE WAY product! We are pleased to welcome you as an owner of a product from RITE WAY MFG. This machinery is the culmination of years of agricultural and engineering experience and has been designed to deliver you with many years of successful operation service.
  • Page 7 Unit Model Number Forward Fold Land Roller Manual Revision Number Manual Revision Date October 2020 Manual Serial Number Range 18-3178 to Current The area below is provided for the owner / end-user to make notes regarding the equipment. Owner / Equipment Information Serial Number of Unit Date of Purchase Dealer Name...
  • Page 8 Remove wrapping and wash unit, removing all road debris. (Road salt, mud, snow, etc.) Inspect paint, decals and general appearance of unit. Verify that the owners manual is in the manual storage tube. Verify ‘SLOW MOVING VEHICLE’ sign (SMV) is on unit Verify that jacks are with the unit and function properly.
  • Page 9 • Patented FORWARD™ unfolding system • Auto-fold hydraulic wing lock • Adjustable hitch height c/w perfect hitch clevis • Dual wing transport tires • Over-center wing lockups • Triple Lip Seal Bearings • Large diameter drum with premium heavy wall: •...
  • Page 10 F3 - 3 Section Land Roller WORKING TRANSPORT TRANSPORT WEIGHT 1/2” WEIGHT 5/8” MODEL WING CONFIGURATION WIDTH LENGTH WIDTH DRUM DRUM 32’ 10’-12’-10’ 38’ 14’ 17,640 lbs 19,560 lbs F3-32 (9.8 m) (3.1 m-3.6 m-3.1 m) (11.6 m) (4.3 m) (8,001 kg) (8,872 kg) 36’...
  • Page 11 Rite Way Manufacturing Co. Ltd. (hereafter referred to as Rite Way) warrants each new ma- chine to be free from defects in materials and workmanship for a period of one (1) year from date of purchase under normal agricultural use and service. In addition, Rite Way will supply at no charge, (F.O.B Rite Way Factory) any part that has failed within the 2nd year.
  • Page 12 1. All claims must be handled through a dealer / distributor. All claims must be submitted on a proper- ly completed claim form within 30 days of the date of repair. 2. A warranty registration claim form must be on file at Rite Way Mfg. to validate a warranty claim. 3.
  • Page 13 1. Read manual thoroughly before operating machine. 2. Study all warning decals on implement. 3. Most accidents occur because of neglect or carelessness. 4. Do not allow riders on the tractor or implement during operation. 5. Do not allow children on or near the machine. 6.
  • Page 14 2, 3, 5, 7, 9, 10 1,6,8,12 1,8,12 4,8,12 4,8,12...
  • Page 15 Grease Every 8 Hours 060-0061 Important - Hydraulic Hose Application (Three Color) 060-0067 Warning - Check And Tighten Hub... Riteway Mfg. (Large Decal, 31 x 5 - White) 060-0121 060-0108 www.ritewaymfg.com - (1” x 20”) 060-0032 R (Load Jobs Only) as required...
  • Page 16 • Repack the wheel hubs after the first 500 kilometres of travel ; then yearly thereafter. • Visually inspect the wheel bolts for tightness each day. Torque to 110 ft lbs. (149 Nm) after the first few hours of operation and frequently thereafter. •...
  • Page 17 Grease should be applied to both sides of the machine. EVERY 8 HRS EVERY 8 HRS EVERY 8 HRS EVERY 8 HRS...
  • Page 18 NOTE: Always choose a level area when folding unit either into or from transport position. NOTE: Lubricate all pins, axles and bearings regularly to prevent premature failure of compo- nents. (See Page 14 Section 1 for lubrication diagram). NOTE: Maximum field operating SPEED OF the LAND ROLLER is 8 mph (13 km/h). Above this speed damage can occur and will not be covered by warranty.
  • Page 19 1. When entering the field from transport, find a location that is as level as possible and stop the trac- tor / roller. 2. Remove all wing axle safety lock pins and tee lock pins. 3. While moving forward in low gear, feather wing axle wheels by activating the hydraulic steering cyl- inders to maximum angle (approximately 45 degrees) - the slow moving sign will indicate the posi- tion.
  • Page 20 1. Bring unit to a complete stop in a level area of the field. 2. Use hydraulic system to raise drums / lower wing axle & walking axle. • NOTE: Ensure that all wing cam locks are fully engaged. • NOTE: Ensure that draft arm locks are fully retracted / released.
  • Page 21 1. Cycle hydraulic system to ensure all air has been purged. 2. With unit in transport position, inspect wing cam lock—look for space between hook and cam roller. 3. If hook is not in contact with cam roller—adjust the cylinder clevis. A) Remove cylinder clevis pin.
  • Page 22 1. Cycle hydraulic system to ensure all air has been purged. 2. With unit in transport position, inspect wing cam lock—look for space between hook and cam roller. 3. If hook is not in contact with cam roller—adjust the cylinder clevis. A) Remove cylinder clevis pin.
  • Page 23 NOTE: Steering Axle adjustment is necessary if roller does not properly follow the tow vehicle when in transport position. Adjustment must be made to left and right axles. 1. With unit in transport position, inspect the wing axle steering. With hydraulic steering cylinder set to transport position (fully retracted), the tires must be aligned with a very slight toe—out (approximately 1/2 to 1 degree).
  • Page 24 *All page numbers refer to Section 2, unless otherwise noted. 1. Reference to “left” or “right” and “forward” or “rear” are always determined from the rear of the ma- chine facing the direction of forward travel. 2. Refer to page 2, 7 and 42 for detailed wing, centre frame drawings and wing list. 3.
  • Page 25 1. Refer to page 5 for detailed drawing. 2. Place left and right hitch on stands approximately 30” off ground (item 1). (Ensure decals are right side up). 3. Leave all bolts loose until directed to tighten. 4. Bolt hitch tie retainers, top and bottom pieces to hitch using capscrews, washers and stover lock nuts (items 1, 4, 6, 16 &...
  • Page 26 1. Refer to page 9 for detailed drawing. 2. Begin by threading one 1/2” hex nut halfway down the threaded rod (items 3 & 12). Next, place the tension pipe on the threaded rod, followed by the second hex nut and the 1/2” jam nut (items 6, 12 &...
  • Page 27 1. Refer to page 11 for detailed drawing. Refer to Page 27 & 28 Section 1 for installation dimensions. 2. Attach draft arm pin to telescopic swing arm using pin 3/4” x 1-3/4” capscrew, spring lock washer and flat washer (items 34, 18, 21 & 26). 3.
  • Page 28 10. Attach stroke of 2-1/2” x 6” cylinder pin to walking arm hook weldment (items 1 & 4) using 1” x 4- 1/4” useable cylinder pin weldment (items 10, 34 & 37). 11. Attach two wheel and tire assemblies to centre axle weldment (items 14 & 15). Attach knuckle pin weldment to walking arm weldment (items 40) using two 1/2”...
  • Page 29 1. Refer to page 17 for detailed drawing. 2. Attach 3-1/2” x 24” cylinder base to outer wing lugs using 1” x 4-3/16” useable pin weldment 1” ma- chine washer and cotter pin (items 2, 20 & 22). 3. Attach outer wing to wing axle assembly using 1” x 8-1/2” capscrews, 1” machine bushings, and 1” stover lock nuts (items 1, 5, 6, 13, 16 &...
  • Page 30 1. Refer to page 21 for detailed drawing. 2. Attach the wing tie bar mount weldment to the outer wings using 3/4” x 6-1/16” x 5-3/4” U-Bolts and 3/4” stover lock nuts (items 3, 12 & 16). Repeat for opposite wing. 3.
  • Page 31 1. Loosely mount the ½” Brackets using the U-bolts, only using nuts on the top of the bracket. 2. Position the lower U-bolts to coincide with the farthest hole to the ends of the blades but also clear any lugs or mounts on the wing frame then loosely install the nuts and washers on the lower U-bolt. 3.
  • Page 32 A. Identify the size of your LAND ROLLER B. Confirm the draft arm length. This length is measured from center to center of the ball joint holes. C. Measure from the end of the wing (end closest to center frame) and make a mark on the wing at the indicated measurement.
  • Page 33 F3-32 F3-34NT 153-7/8 F3-36 153-7/8 F3-40NT 161-1/2 F3-42 161-1/2 F3-44NT 161-1/2 148-1/2 F3-46 161-1/2 148-1/2 F3-48 161-1/2 F3-50NT 171-1/8 F3-52 171-1/8 F5-46 171-1/8 F5-50 171-1/8 F5-54 171-1/8 19-1/2 F5-58 237-3/8 90-1/2 F5-62 237-3/8 70-1/8 F5-68 237-3/8 F5-74 237-3/8 HD F5-78 237-3/8 HD F5-84 237-3/8 HD...
  • Page 34 Min. Proof Min. Tensile Min. Yield Grade Size Range Specification Material Strength Strength Strength Identification (inches) (psi) (psi) (psi) Marking Low or Medium 1/4 to 3/4 55,000 74,000 57,000 Grade 2 Carbon Steel 7/8 to 1-1/2 33,000 60,000 36,000 Medium Carbon 1/4 to 1 85,000 120,000...
  • Page 35 Grade 2 Grade 5 Grade 8 Nominal Tightening Clamping Tightening Clamping Tightening Clamping Thread Size Load Torque Load Torque Load Torque Coarse Thread 1/4-20 1,300 lbs 65 in-lbs 2,000 lbs 100 in-lbs 2,850 lbs 143 in-lbs 5/16-18 2,150 lbs 134 in-lbs 3,350 lbs 210 in-lbs 4,700 lbs...
  • Page 39 Varies Refer to Section 2 page 44 112-0529 Offset Drum Cross c/w Coupling Nuts 200-9002 Weld On Bushing 261-6001 Ø3-11/16” x 1-5/16” Split Tapered Bearing 292-4018 Ø2-7/16” Eccentric Lock Collar, Pltd. 292-4022 Ø2-7/16” ID 4-Bolt Flange Bearing 525-0510 5/16” x 1-1/4” Capscrew, NC, Gr.5, Pltd. 526-0815 1/2”...
  • Page 41 105-0053 Wing Attachment Weldment, Universal 105-0054 Finish Drum Mount Weldment 105-0067 Finish Drum Weldment, Ø28” x 20” wide 105-0490 Inner Bolt On Boss Weldment, Ø1-1/2” ID x 4-7/8” overall 105-0510 Spring Tension Weldment 261-5108 Connex Steel Bushing, 1” ID x 3-5/16” long 292-4021 1-3/4”...
  • Page 43 105-0001 Short Hitch, Side Weldment 105-0002 Long Hitch, Side Weldment (65’ and Larger) 105-0122 Narrow Hitch, Side Weldment (Narrow Transport) 105-0003 Tongue Attachment Weldment 105-0004 Centre Frame Wld., Dual Bearing Hanger (12’ wide) 105-0097 Narrow Centre Frame Wld., Dual Bearing Hanger (10’ wide) Hitch, Jack Tube &...
  • Page 45 030-5993 Cylinder, Tie-Rod, 2-1/2" X 6" 060-0034 Riteway Serial Number Plate 105-0004 Centre Frame Weldment, (12’ Wide) 105-0097 Narrow Centre Frame Weldment, (10’ Wide) 105-0012 Auto Fold Hook Weldment 105-0083 Auto Fold Pin, Ø1-1/4” x 6-1/4” useable, Pltd. 105-0087 Cylinder Pin Weldment, Ø1” x 4-1/4” useable, Pltd.
  • Page 47 105-0010 Auto Fold Arm Inner Weldment 105-0011 Auto Fold Arm Outer Weldment 105-0084 Auto Fold Swing Arm Spring Linkage 403-0276 Swing Arm Spring, 5/16” Wire x 2” OD x 27-1/2 Long 419-0100 3/8” NF Grease Zerk Straight, Pltd. 525-6108 1/2” Hex Jam Nut, NC, Gr.5, Pltd. 526-0624 3/8”...
  • Page 49 105-0004 Centre Frame Weldment, 12’ Wide 105-0097 Centre Frame Weldment, 10 Wide (Narrow) 105-0010 Swing Arm Inner Arm Weldment 105-0011 Swing Arm Outer Arm Weldment 105-0069 Centre Frame Hook Roller Weldment 105-0078 Walking Arm Pin Weldment, Ø1-1/2” x 8-1/4” useable 105-0083 Wing Attachment Draft Arm Pin, Ø1-1/4”...
  • Page 50 ATTATCH TO CENTRE FRAME WALKING ARM LUG ATTATCH TO CENTRE FRAME LUG ATTATCH TO CENTRE FRAME AXLE LUG FRONT...
  • Page 51 030-5993 Cylinder, Tie-Rod, 2-1/2" X 6" 030-5967 40THC12-175, 3/4” ORB Ports @ 90° 105-0013 Left Walking Arm Weldment, shown 105-0014 Right Walking Arm Weldment 105-0015 Walking Arm Hook Weldment 105-0016 Centre Axle Weldment c/with Bolt In Spindles 105-0035 Centre Axle Lower Link Weldment (x2) 105-0036 Centre Axle Upper Link Weldment (x2) 105-0074...
  • Page 53 Varies Refer to Section 2 page 44 Varies Refer to Section 2 page 44 030-5935 Cylinder, Tie - Rod, 3-1/2" X 8" 105-0017 Knuckle Weldment for Ø1-1/2” Pin 105-0047 Transport Lock Weldment (Truss Claw) 105-0082 Transport Lock Pin Weldment, Ø1-1/4” x 7-9/16” Useable 105-0086 Cylinder Claw Pin Weldment, Ø1”...
  • Page 55 030-5982 Cylinder, Tie - Rod, 3-1/2" X 24" 105-0087 Cylinder Pin Weldment, Ø1"Ø x 4-3/16" Useable 105-0089 Cylinder Stroke Pin Weldment, Ø1"Ø x 5-11/16" Useable 105-0091 Wing Lock Up Weldment, Painted, 3/4’ x 13-13/16 long Varies Refer to Section 2 page 44 160-0012 Wing Axle Assembly 316-0302...
  • Page 57 020-6014 CTD 812 Hub Assembly c/w Drive in Studs & Wheel Nuts 030-5993 Cylinder, Tie-Rod, 2-1/2" X 6" (Monarch PN 662386) 105-0056 Wing Axle Weldment 105-0058 Wing Pivot Axle, Bolt In Spindle Weldment 105-0068 Wing Axle Slow Moving Sign Bracket, Painted 123-2229 Tee Lock Pin Wld., Ø1”...
  • Page 58 Transport position...
  • Page 59 105-0272 Wing Tie Bar Outer Tube Weldment 105-0273 Wing Tie Bar Inner Tube Weldment 105-0274 Wing Tie Bar Mount Weldment 105-0275 Mount Pin Weldment, Ø1-1/4” x 4-1/4” long 105-0278 Removable Pin Weldment, Ø1” x 4-1/4” long Wing Tie Bar Parking Mount Weldment 105-0484 (10’...
  • Page 60 526-7312 3/4 Stover Lock Nut, Nc, Gr.8, Pltd. 530-1250 Bolt, 3/4-10 Unc - 2, Gr.8, Yellow Zinc Plated 530-1263 Bolt, 3/4-10 Unc - 5.5, Gr.8, Yellow Zinc Plated 550-5621 Washer, Flat, 3/4 Sae, Gr.8, Yellow Zinc Plated 839-0684 Mud Scraper, Bracket, Straight 839-0688 Mud Scraper, 5 Foot Blade 839-0689...
  • Page 61 526-7312 3/4 Stover Lock Nut, UNC, Pltd. 546-5181 3/4" UNC, 6" W X 5.75" Lg, U-Bolt 550-5621 Washer, Flat, 3/4 SAE, Yellow Zinc Plated 839-0684 Mud Scraper, Bracket, Straight 839-0688 Mud Scraper, 5 Foot Blade 839-0689 Mud Scraper, 6 Foot Blade 839-0687 Mud Scraper, 8 Foot Blade...
  • Page 62 020-0130 Tire and Wheel Assembly, 11L-15 D 205-1181 Tire, 11L-15 204-5593 Wheel, 11L-15 020-0108 Tire and Wheel Assembly, 12.5L-15 D 205-1193 Tire, 12.5L-15 204-5586 Wheel, 12.5L-15 020-0136 Tire and Wheel Assembly, 380/55R16.5 205-1209 Tire, 380/55R16.5 204-5597 Wheel, 380/55R16.5 Tire and Wheel Assembly, 020-0154 ST235/75R17.5 020-0149...
  • Page 63 423-0005 Base Hitch (PP1-301VH) 423-0006 Clevis (PP1-208VR-10) 423-0019 Neoprene Cushion (PP1-205H) 423-0017 Top Plate Perfect Hitch (PP1-302V) 423-0018 V-Block (PP1-203VR) 526-1224 3/4” x 3” Capscrew, NC, Gr.5, Pltd. 526-6107 3/4” Stover Lock Nut, NC, Gr.B, Pltd. 526-1241 3/4” x 5-1/2” Capscrew, NC, Gr.5, Pltd. The sliding V-block has a polyurethane cushion which is made to flex.
  • Page 64 203-6044 812 Spindle, Ø2-1/2” X 11-3/4” Long 200-6011 812 Hub (complete) 201-6016 Outer Cup LM2720 201-6017 Inner Cup 3720 202-6013 DC 17 Dust Cap 290-6013 Outer Bearing, 2790 290-6014 Inner Bearing, 3780 295-6016 SE 17 Seal 534-7816 1” Castle Nut, NF, Gr.5, Black 554-5303 1”...
  • Page 65 Acre Meter Housing (Ø4") Measure before ordering replacement 112-0258 meter Arce Meter Varies To Order an Acre Meter Please Call Forster Toll Free # 1-800-661-2994 518-0608 1/2" x 1/2" Set Screw, NC, Black 526-0832 1/2" x 4" Capscrew, NC, Gr.5, Pltd. 526-7508 1/2"...
  • Page 66 7 PIN PLUG 2 X AMBER LENSE 1 X RED LENSE...
  • Page 67 417-0061 28’-0” Main Frame Harness Section 417-0159 Main Wing Harness 417-0122 Amber Light Assembly 417-0123 Red Light Assembly 417-0150 10’ 2-Wire Extension 417-0152 15’ 2-Wire Extension 417-0151 20’ 2-Wire Extension 417-0170 6’ Hitch Harness Extension...
  • Page 68 MONARCH PART NUMBER 662386 RITE WAY PART NUMBER 030-5993 293014 Clevis Cap, 2-1/2” - 3/4” ORB 293017 Rod Cap, 2-1/2” - 3/4” ORB, 1-1/8” ID 293011 Piston, 2-1/2 - TX 194893 Seal Hallite 605 Rod 1-1/8 498512 Cylinder Tube, 2-1/2” x 6” - TX 494182 Tie Rod, 3/8”...
  • Page 69 MONARCH PART NUMBER 645665 RITE WAY PART NUMBER 030-5935 492676 Clevis Cap, 3-1/2” - 3/4” ORB 492677 Rod Cap, 3-1/2” - 3/4” ORB, 1-1/4” ID 292518 Piston, 3-1/2 - TL / TC 199130 Seal Wiper Rod, 1-1/4”, Metal 491798 Cylinder Tube, 3-1/2” x 8” - TL / TC 492338 Tie Rod, 5/8”...
  • Page 70 MONARCH PART NUMBER 648381 RITE WAY PART NUMBER 030-5967 492680 Clevis Cap, 4” - 3/4” ORB @ 90º, 1” Cyl. Pin 492695 Rod Cap, 4” - 1-3/4” ID, 3/4” ORB 294033 Piston, 4”- 1-1/8” TH / TP - Cast 194897 Seal Hallite 605 Rod, Ø1-3/4”...
  • Page 71 MONARCH PART NUMBER 671642 RITE WAY PART NUMBER 030-5982 492676 Clevis Cap, 3-1/2” - 3/4” ORB 492290 Rod Cap, 3-1/2” - 3/4” ORB, 1-3/4” ID 258827 Piston, 3-1/2 - 1 - TSS-ISO-WR 437243 Rod Cyl. 1-3/4 x 24 - 1 x 1-1/2 491814 Cylinder Tube, 3-1/2”...
  • Page 72 TO RIGHT WING TO LEFT WING F7-81 AND UP F7-81 AND UP ONLY ONLY CENTER FRAME HITCH FRONT...
  • Page 73 030-5993 Cylinder, Tie-Rod, 2-1/2" X 6" 030-5967 Cylinder, Tie - Rod, 4" X 12" 313-7937 Hose, Hydraulic, 3/8" Hose, 3/8" FJIC X 3/8" FJIC - 37" 313-7950 Hose, Hydraulic, 3/8" Hose, 3/8" FJIC X 3/8" FJIC - 50" 313-7852 Hose, Hydraulic, 3/8" Hose, 3/8" MJIC X 3/8" FJIC - 52" 313-7863 Hose, Hydraulic, 3/8"...
  • Page 74 Right wing pictured, left wing similar. 030-5993 Cylinder, Tie-Rod, 2-1/2" X 6" 030-5982 Cylinder, Tie - Rod, 3-1/2" X 24" 311-2066 Pipe, Hydraulic, 66 Inch, 3/8" FJIC Swivel End Fittings 311-2083 Pipe, Hydraulic, 83 Inch, 3/8" FJIC Swivel End Fittings 311-2104 Pipe, Hydraulic, 104 Inch, 3/8"...
  • Page 75 Right wing pictured, left wing similar. 030-5993 Cylinder, Tie-Rod, 2-1/2" X 6" 030-5982 Cylinder, Tie - Rod, 3-1/2" X 24" 030-5935 Cylinder, Tie - Rod, 3-1/2" X 8" 311-2038 Pipe, Hydraulic, 38 Inch, 3/8" FJIC Swivel End Fittings 311-2058 Pipe, Hydraulic, 58 Inch, 3/8" FJIC Swivel End Fittings 311-2066 Pipe, Hydraulic, 66 Inch, 3/8"...
  • Page 76 Right wing pictured, left wing similar. 030-5993 Cylinder, Tie-Rod, 2-1/2" X 6" 030-5982 Cylinder, Tie - Rod, 3-1/2" X 24" 030-5935 Cylinder, Tie - Rod, 3-1/2" X 8" 5,6,7 311-2038 Pipe, Hydraulic, 38 Inch, 3/8" FJIC Swivel End Fittings 311-2058 Pipe, Hydraulic, 58 Inch, 3/8"...
  • Page 77 Right wing pictured, left wing similar. 030-5993 Cylinder, Tie-Rod, 2-1/2" X 6” 030-5982 Cylinder, Tie - Rod, 3-1/2" X 24" 030-5935 Cylinder, Tie - Rod, 3-1/2" X 8" 5,6,7 311-2038 Pipe, Hydraulic, 38 Inch, 3/8" FJIC Swivel End Fittings 311-2058 Pipe, Hydraulic, 58 Inch, 3/8"...
  • Page 78 (160-0012) WING AXLE (VARIES) WING ASSEMBLY (160-0004) WALKING ARM, LEFT (160-0005) WALKING ARM, RIGHT (VARIES) DRAFT ARM (VARIES) WING ASSEMBLY (VARIES) HITCH (VARIES) (VARIES) DRAFT ARM CENTER FRAME (160-0012) WING AXLE...

  • Page 79: Center Frame

    (160-0012) WING AXLE (160-0319) FINISHING ROLLER, LEFT (VARIES) WING ASSEMBLY (VARIES) WING ASSEMBLY (160-0004) WALKING ARM, LEFT (VARIES) DRAFT ARM (160-0005) WALKING ARM, RIGHT (VARIES) HITCH (VARIES) WING ASSEMBLY (160-0320) FINISHING ROLLER, RIGHT (160-0274) CENTER FRAME (VARIES) DRAFT ARM (VARIES) WING ASSEMBLY (160-0012) WING AXLE...
  • Page 80 (160-0319) FINISHING ROLLER, (160-0012) LEFT WING AXLE (160-0319) FINISHING ROLLER, (VARIES) LEFT WING ASSEMBLY (VARIES) WING ASSEMBLY (160-0004) WALKING ARM, LEFT (VARIES) WING ASSEMBLY (160-0005) WALKING ARM, RIGHT (VARIES) (VARIES) DRAFT ARM WING ASSEMBLY (160-0320) FINISHING ROLLER, (160-0002) RIGHT LONG HITCH (VARIES) WING ASSEMBLY (160-0320)
  • Page 81 Part # Description 105-0790 Inner Wing, Five & Seven Plex, 8 Foot, Weldment 105-0791 Inner Wing, Five & Seven Plex, 10 Foot, Weldment 105-0792 Inner Wing, Five & Seven Plex, 12 Foot, Weldment 105-0793 Inner Wing, Five & Seven Plex, 15 Foot, Weldment 105-0492 Mid Wing, Five &...
  • Page 82 Part # Description 160-0045 Drum Assembly, Ø42” x .500w Std Pipe - 20’ 160-0046 Drum Assembly, Ø42” x .500w Std Pipe - 18’ 160-0044 Drum Assembly, Ø42” x .500w Std Pipe - 17’ 160-0043 Drum Assembly, Ø42” x .500w Std Pipe - 15’-2” 160-0042 Drum Assembly, Ø42”...
