- Page 1 ROCK PICKER 250 Operation & Maintenance Manual OPERATORS MANUAL & PART LIST...
-
Page 3: Table Of Contents
ROCK PICKER 250 Contents PAGE SECTION 1 INTRODUCTION & MANUAL INFORMATION PRE-DELIVERY INSPECTION / NOTES SPECIFICATIONS SERVICE AND WARRANTY INFORMATION SAFETY SUGGESTIONS 10,11 DECAL LOCATIONS 12,13 MAINTENANCE / GREASE LOCATIONS 14-16 OPERATING NSTRUCTIONS GRADE CHART TORQUE CHART PAGE SECTION 2... - Page 5 SECTION 1...
- Page 7 ROCK PICKER 250 Thank you for making the decision to purchase a RITE WAY We are pleased to welcome you as an owner of a product from RITE WAY MFG. This product is the result of years of agricultural and engineering experience, and is built to give you many years of successful operating service.
- Page 8 ROCK PICKER 250 Manual Details Unit Model Number RR-250-ST-Rock Picker Manual Revision Number Revision 1.1 Manual Revision Date 1/10/2019 Manual Serial Number Range Serial # 18-250-966 - Current Previous Serial Number Range Serial # 15-250-917 - 17-250-965 The area below is provided for the owner / end-user to make notes regarding the equipment.
- Page 9 ROCK PICKER 250 Pre-delivery Inspection Check List General Remove wrapping and wash unit, removing all road debris. (Road salt, mud, snow, etc.) Inspect paint, decals and general appearance of unit. Verify that the owners manual is in the manual storage tube.
-
Page 10: Specifications
ROCK PICKER 250 Specifications Standard Equipment: Multi-position Hydraulic Swing Hitch • 10” Side Wind Parking Jack • Safety chains • Drive Variable Hydraulic Drive Reel 2 Bat Reel Chain Weight 2,931 lbs / 1,330 kg Picking Width 50” / 127 cm Minimum Rock Diameter 2”... - Page 11 ROCK PICKER 250 Notes Notes...
- Page 12 ROCK PICKER 250 Service & Warranty Policy Rite Way Manufacturing Co. Ltd. (hereafter referred to as Rite way) warrants each new machine to be free from defects in materials and workmanship for a period of one (1) year from date of purchase under normal agricultural use and service.
- Page 13 ROCK PICKER 250 Service & Warranty Claim Procedure 1. All claims must be handled through a dealer / distributor. All claims must be submit- ted on a properly completed warranty claim form within 30 days of the date of repair.
- Page 14 ROCK PICKER 250 Safety Warnings (General) 1. Read the manual thoroughly and understand before operating or working on the machine. 2. Study all safety and warning decals on the implement. 3. Most accidents occur because of neglect or carelessness. 4. Do not allow riders on the tractor or implement during operation.
- Page 15 ROCK PICKER 250 Safety Warnings (Equipment Specific) 1. Read manual thoroughly before operating or working on the machine. 2. Study all warning decals on implement. 3. Most accidents occur because of neglect or carelessness. 4. Only the operator should be on the tractor during operation.
-
Page 16: Decal Locations
ROCK PICKER 250 Decals ON THE TOP 13 14 DECALS SHOWN HERE ARE PLACED ON FRAME Decal Locations... - Page 17 ROCK PICKER 250 Decals Item # Part # Description 060-0121 Rite Way Mfg. (Large Decal, White)- On Side Of The 060-0072 RR 250ST (Large Decal, White)- On The Side Of The 060-0009 Amber Reflector - On The Frame 060-0022 Red Reflector - On The Rear Of The Frame 060-0015 Important - Block Wheel Before Unhooking..
- Page 18 Repack the wheel hubs after the first 500 travel miles; then yearly thereafter. • Visually inspect the wheel bolts for tightness each day. Riteway torque recommen- • dation to 110 ft - lbs after the first few hours of operation and frequently there after, (manufactures torque recommendations 90 to 131 ft - lbs).
-
Page 19: Maintenance / Grease Locations
ROCK PICKER 250 Maintenance Grease Locations Maintenance... -
Page 20: Operating Nstructions
ROCK PICKER 250 Operating Instructions Always choose a level spot when manually or hydraulically moving the unit into or out of transport position. Preparation for Picking Rocks 1. Hook rock picker up to tractor. Connect the rotary switch to a 12V power source. Connect the white wire to the positive and the black wire to the negative. - Page 21 ROCK PICKER 250 Operating Instructions (cont) 5. Move the 3 position rotary switch to the Rake position in order to pick stones. See Figure B. ONLY THOSE ROCKS ON THE SURFACE CAN BE PICKED. IF THE ROCKS ARE DUG UP FROM UNDER THE GROUND, IT WILL CAUSE DAMAGE TO THE UNIT.
- Page 22 ROCK PICKER 250 Operating Instructions (cont) PARKER ELECTRIC SELECTOR MANIFOLD 12-VOLT – ½” ORB (1C-3914) FIGURE D—Manifold top view Operating Instructions...
-
Page 23: Grade Chart
ROCK PICKER 250 Grade Chart Min. Proof Min. Tensile Min. Yield Grade Size Range Specification Material Strength Strength Strength Identification (inches) (psi) (psi) (psi) Marking Grade 1 1/4 to 1-1/2 33,000 60,000 36,000 Low or Medium 1/4 to 3/4 55,000... -
Page 24: Torque Chart
ROCK PICKER 250 Torque Chart Grade 2 Grade 5 Grade 8 Nominal Clamping Tightening Clamping Tightening Clamping Tightening Thread Size Torque Load Torque Load Torque Load Coarse Thread 1/4-20 1,300 lbs 65 in-lbs 2,000 lbs 100 in-lbs 2,850 lbs 143 in-lbs... - Page 25 SECTION 2...
-
Page 28: Parts
ROCK PICKER 250 Parts Details Hitch Pole Parts... - Page 29 ROCK PICKER 250 Parts Details Hitch Pole Item # Part # Description 030-5989 3-1/2” X 8” Hydraulic Cylinder, 3/4 ORB 105-1124 Lockup, Hitch Cylinder 110-2517 Hitch Pole Weldment 110-3502 Main Frame Weldment 123-3210 Hitch Pivot Pin 403-0269 Lockup Tension Spring 407-0003 24"...
- Page 30 ROCK PICKER 250 Parts Details Main Frame & Bucket Parts...
- Page 31 ROCK PICKER 250 Parts Details Main Frame & Bucket Item # Part # Description 030-5938 3-1/2" X 14" Hydraulic Cylinder, 3/4 ORB 105-1126 Deflector Screen Weldment 110-2520 Rocker Picker Frame Weldment 110-2521 Bucket Weldment 110-2522 Bucket Bearing 110-2524 Deflector Mount Weldment...
- Page 32 ROCK PICKER 250 Parts Details Rake, Bat, & Reel Parts...
- Page 33 ROCK PICKER 250 Parts Details Rake, Bat, & Reel Item # Part # Description 020-0112 12.5L X 15 Tire 030-5938 3-1/2" X 14" Hydraulic Cylinder, 3/4 ORB 030-5980 3-1/2” X 8” Hydraulic Cylinder, 3/4 ORB, With Stroke Control 110-2520 Rocker Picker Frame Weldment...
- Page 34 ROCK PICKER 250 Parts Details Bearing & Frame Parts...
- Page 35 ROCK PICKER 250 Parts Details Bearing & Frame Item # Part # Description 030-5980 3-1/2” X 8” Hydraulic Cylinder, 3/4 ORB, With Stroke Control 105-1123 Chain Guard Weldment 110-2514 Bat Weldment (14 Tooth) 110-2515 Two Bat Reel Weldment 110-2516 Rake Weldment (15-Tooth)
- Page 36 ROCK PICKER 250 Parts Details Perfect Hitch Item # Part # Description 423-0013 Perfect Hitch Base (PP1-237VR) 423-0006 Perfect Hitch Clevis (PP1-208VR-10) 526-6107 Nut, Stover Lock, 3/4-10 UNC, Gr.5, Yellow Zinc Plated 526-1248 Bolt, 3/4-10 UNC - 5, Gr.5, Yellow Zinc Plated...
- Page 37 ROCK PICKER 250 Parts Details Hub & Spindle Screw in Wheel Stud Type Press in Wheel Stud Type 020-6016, 020-6017 020-6014 Item # Part # Description 203-6025 Spindle 200-6011 812-1 Hub (Takes SE17) 200-6013 812 Hub (Takes SE17) 200-6014 812-2 Hub (Takes SE35)
- Page 38 ROCK PICKER 250 Parts Details MONARCH 3-1/2" x 8" x 1-1/4" MONARCH PART NUMBER 645666 RITE WAY PART NUMBER 030-5980 Item # Part # Description 492403 3-1/2” Clevis Cap 492423 Rod Cap 492528 3-1/2” Piston 492700 1-1/4” Rod 491798 3-1/2” Tube...
- Page 39 ROCK PICKER 250 Parts Details MONARCH 3-1/2" x 8" x 1-1/4" MONARCH PART NUMBER 645665 RITE WAY PART NUMBER 030-5989 Item # Part # Description 492403 3-1/2” Clevis Cap 492423 Rod Cap 492528 3-1/2” Piston 492700 1-1/4” Rod 491798 3-1/2” Tube...
- Page 40 ROCK PICKER 250 Parts Details MONARCH 3-1/2" x 14" x 1-1/4" MONARCH PART NUMBER 645667 RITE WAY PART NUMBER 030-5938 Item # Part # Description 492403 3-1/2” Clevis Cap 492423 Rod Cap 492528 3-1/2” Piston 492873 1-1/4” Rod 491804 3-1/2” Tube...
- Page 41 ROCK PICKER 250 Parts Details Hydraulic Drive System Item # Part # Description 307-1003 Parker Hydraulic Motor c/w Built in Reliefs 308-0001 Pioneer Tip – ½” M Quick Connect, Poppet Type 310-5010 Flow Control Valve (5/8” ORB) 312-1745 ½” Hose (2-Wire) – ½” JIC Sw F x ½” JIC Sw F – 45”...
- Page 42 ROCK PICKER 250 Parts Details Rake, Bucket, & Hitch Hydraulics Item # Part # Description 030-5935 3-1/2” x 8” Hydraulic Cylinder 030-5936 3-1/2” x 8” Hydraulic Cylinder c/w Depth Control 030-5938 3-1/2” x 14” Hydraulic Cylinder 308-0001 ½” NPT F – Male Quick Connect (Pioneer Tip) 310-4038 Parker 12-Volt Electric Selector Manifold (½”...
- Page 43 ROCK PICKER 250 NOTES Notes...
