RITEWAY ROCK PICKER 900 Operator's Manual & Parts

Hide thumbs

Advertisement

Quick Links

ROCK PICKER 900
Operation &
Maintenance
Manual
OPERATORS MANUAL
& PART LIST

Advertisement

loading
Need help?

Need help?

Do you have a question about the ROCK PICKER 900 and is the answer not in the manual?

Questions and answers

Related Manuals for RITEWAY ROCK PICKER 900

Summary of Contents for RITEWAY ROCK PICKER 900

  • Page 1 ROCK PICKER 900 Operation & Maintenance Manual OPERATORS MANUAL & PART LIST...

  • Page 3: Table Of Contents

    ROCK PICKER 900 Contents PAGE SECTION 1 INTRODUCTION & MANUAL INFORMATION PRE-DELIVERY INSPECTION / NOTES SPECIFICATIONS SERVICE AND WARRANTY INFORMATION SAFETY SUGGESTIONS 10,11 DECAL LOCATIONS 12,13 MAINTENANCE / GREASE LOCATIONS 14-16 OPERATING NSTRUCTIONS GRADE CHART TORQUE CHART PAGE SECTION 2...
  • Page 5 SECTION 1...
  • Page 7 ROCK PICKER 900 Thank you for making the decision to purchase a RITE WAY We are pleased to welcome you as an owner of a product from RITE WAY MFG. This product is the result of years of agricultural and engineering experience, and is built to give you many years of successful operating service.
  • Page 8 ROCK PICKER 900 Manual Details Unit Model Number RR-900-ST-Rock Picker Manual Revision Number Revision 1.4 Manual Revision Date 1/10/2019 Manual Serial Number Range Serial # 18-1600 - Current Previous Serial Number Range Serial # 16-1532 - 18-1599 The area below is provided for the owner / end-user to make notes regarding the equipment.
  • Page 9 ROCK PICKER 900 Pre-delivery Inspection Check List General Remove wrapping and wash unit, removing all road debris. (Road salt, mud, snow, etc.) Inspect paint, decals and general appearance of unit. Verify that the owners manual is in the manual storage tube.

  • Page 10: Specifications

    ROCK PICKER 900 Specifications Standard Equipment: Multi-position Hydraulic Swing Hitch • 10” Side Wind Parking Jack • Safety chains • Drive Variable Hydraulic Drive Reel 3 Bat Reel Chain Weight 4,784 lbs / 2,170 kg Picking Width 60” / 152 cm Minimum Rock Diameter 2”...
  • Page 11 ROCK PICKER 900 Notes Notes...
  • Page 12 ROCK PICKER 900 Service & Warranty Policy Rite Way Manufacturing Co. Ltd. (hereafter referred to as Rite way) warrants each new machine to be free from defects in materials and workmanship for a period of one (1) year from date of purchase under normal agricultural use and service.
  • Page 13 ROCK PICKER 900 Service & Warranty Claim Procedure 1. All claims must be handled through a dealer / distributor. All claims must be submit- ted on a properly completed warranty claim form within 30 days of the date of repair.
  • Page 14 ROCK PICKER 900 Safety Warnings (General) 1. Read the manual thoroughly and understand before operating or working on the machine. 2. Study all safety and warning decals on the implement. 3. Most accidents occur because of neglect or carelessness. 4. Do not allow riders on the tractor or implement during operation.
  • Page 15 ROCK PICKER 900 Safety Warnings (Equipment Specific) 1. Read manual thoroughly before operating or working on the machine. 2. Study all warning decals on implement. 3. Most accidents occur because of neglect or carelessness. 4. Only the operator should be on the tractor during operation.

  • Page 16: Decal Locations

    ROCK PICKER 900 Decals ON THE TOP 13 14 DECALS SHOWN HERE ARE PLACED ON FRAME Decal Locations...
  • Page 17 ROCK PICKER 900 Decals Item # Part # Description Rite Way Mfg. (Large Decal, White)- On Side Of The 060-0121 Bucket RR 900ST (Large Decal, White)- On The Side Of The 060-0086 Bucket 060-0009 Amber Reflector - On The Frame...
  • Page 18 ROCK PICKER 900 Decals 10” 21” 1/2” Gap 10” 21” 1/2” Gap Decal Locations...
  • Page 19 Repack the wheel hubs after the first 500 travel miles; then yearly thereafter. • Visually inspect the wheel bolts for tightness each day. Riteway torque recommen- • dation to 110 ft - lbs after the first few hours of operation and frequently there after, (manufactures torque recommendations 90 to 131 ft - lbs).

  • Page 20: Maintenance / Grease Locations

    ROCK PICKER 900 Maintenance Grease Locations Maintenance...

  • Page 21: Operating Nstructions

    ROCK PICKER 900 Operating Instructions Always choose a level spot when manually or hydraulically moving the unit into or out of transport position. Preparation for Picking Rocks 1. Hook rock picker up to tractor. Connect the rotary switch to a 12V power source. Connect the white wire to the positive and the black wire to the negative.
  • Page 22 ROCK PICKER 900 Operating Instructions (cont) 5. Move the 3 position rotary switch to the Rake position in order to pick stones. See Figure B. ONLY THOSE ROCKS ON THE SURFACE CAN BE PICKED. IF THE ROCKS ARE DUG UP FROM UNDER THE GROUND, IT WILL CAUSE DAMAGE TO THE UNIT.
  • Page 23 ROCK PICKER 900 Operating Instructions (cont) PARKER ELECTRIC SELECTOR MANIFOLD 12-VOLT – ½” ORB (1C-3914) FIGURE D—Manifold top view Operating Instructions...

  • Page 24: Grade Chart

    ROCK PICKER 900 Grade Chart Min. Proof Min. Tensile Min. Yield Grade Size Range Specification Material Strength Strength Strength Identification (inches) (psi) (psi) (psi) Marking Grade 1 1/4 to 1-1/2 33,000 60,000 36,000 Low or Medium 1/4 to 3/4 55,000...

  • Page 25: Torque Chart

    ROCK PICKER 900 Torque Chart Grade 2 Grade 5 Grade 8 Nominal Clamping Tightening Clamping Tightening Clamping Tightening Thread Size Torque Load Torque Load Torque Load Coarse Thread 1/4-20 1,300 lbs 65 in-lbs 2,000 lbs 100 in-lbs 2,850 lbs 143 in-lbs...
  • Page 26 SECTION 2...
  • Page 29 ROCK PICKER 900 Parts Details Hitch Pole Parts...
  • Page 30 ROCK PICKER 900 Parts Details Hitch Pole Item # Part # Description 030-5989 3-1/2” X 8” Hydraulic Cylinder, 3/4 ORB 105-1124 Lockup, Hitch Cylinder 110-2517 Hitch Pole Weldment 110-3502 Main Frame Weldment 123-3210 Hitch Pivot Pin 403-0269 Lockup Tension Spring 407-0003 24"...
  • Page 31 ROCK PICKER 900 Parts Details Main Frame & Bucket Parts...
  • Page 32 ROCK PICKER 900 Parts Details Main Frame & Bucket Item # Part # Description 030-5986 4” X 30” Hydraulic Cylinder, 3/4 ORB 105-1125 Deflector Screen Weldment 110-2524 Deflector Mount Weldment 110-3502 Main Frame Weldment 110-3542 Bucket Weldment 110-3545 Hose Guard Weldment...
  • Page 33 ROCK PICKER 900 Parts Details Rake, Bat, & Reel Parts...
  • Page 34 ROCK PICKER 900 Parts Details Rake, Bat, & Reel Item # Part # Description Reel Weldment 105-1120 Chain Guard Weldment 105-1123 110-3541 Rake Weldment Rake Bearing Weldment 112-1104 Hyd. Motor Mount Casting 112-2507 80B11 Sprocket, 1-1/4 Hole, 5/16 Key 252-1180...
  • Page 35 ROCK PICKER 900 Parts Details Bearing & Frame Parts...
  • Page 36 ROCK PICKER 900 Parts Details Bearing & Frame Item # Part # Description 204-5585 W14C X 16.1" - 8 Hole Wheel, 3/8" Offset 205-1192 16.5 X 16.1 6 Ply Tire 030-5980 3-12” X 8” Hydraulic Cylinder, 3/4 ORB, With Stroke Control 030-5986 4”...
  • Page 37 ROCK PICKER 900 Parts Details Perfect Hitch Item # Part # Description 423-0013 Perfect Hitch Base (PP1-237VR) 423-0006 Perfect Hitch Clevis (PP1-208VR-10) 526-6107 Nut, Stover Lock, 3/4-10 UNC, Gr.5, Yellow Zinc Plated 526-1248 Bolt, 3/4-10 UNC - 5, Gr.5, Yellow Zinc Plated...
  • Page 38 ROCK PICKER 900 Parts Details Hub & Spindle Screw in Wheel Stud Type Press in Wheel Stud Type 020-6016, 020-6017 020-6014 Item # Part # Description 203-6025 Spindle 200-6011 812-1 Hub (Takes SE17) 200-6013 812 Hub (Takes SE17) 200-6014 812-2 Hub (Takes SE35)
  • Page 39 ROCK PICKER 900 Parts Details MONARCH 3-1/2" x 8" x 1-1/4" MONARCH PART NUMBER 645666 RITE WAY PART NUMBER 030-5980 Item # Part # Description 492403 3-1/2” Clevis Cap 492423 Rod Cap 492528 3-1/2” Piston 492700 1-1/4” Rod 491798 3-1/2” Tube...
  • Page 40 ROCK PICKER 900 Parts Details MONARCH 3-1/2" x 8" x 1-1/4" MONARCH PART NUMBER 645665 RITE WAY PART NUMBER 030-5989 Item # Part # Description 492403 3-1/2” Clevis Cap 492423 Rod Cap 492528 3-1/2” Piston 492700 1-1/4” Rod 491798 3-1/2” Tube...
  • Page 41 ROCK PICKER 900 Parts Details MONARCH 4" x 30" x 1-1/2" MONARCH PART NUMBER 671646 RITE WAY PART NUMBER 030-5986 Item # Part # Description 492680 Clevis Cap – 4” - ¾” ORB – 1.00 492686 Rod Cap – 4” x 1-1/2” – ¾” ORB 292527 Piston –...
  • Page 42 ROCK PICKER 900 Parts Details Hydraulic Drive System Item # Part # Description 307-1003 Parker Hydraulic Motor c/w Built in Reliefs 308-0001 Pioneer Tip – ½” M Quick Connect, Poppet Type 310-5010 Flow Control Valve (5/8” ORB) 312-1745 ½” Hose (2-Wire) – ½” JIC Sw F x ½” JIC Sw F – 45”...

  • Page 43: Parts

    ROCK PICKER 900 Parts Details Rake, Bucket, & Hitch Hydraulics Item # Part # Description 030-5935 3-1/2” x 8” Hydraulic Cylinder (3/4” ORB) 030-5936 3-1/2” x 8” Hydraulic Cylinder c/w Depth Control (3/4” ORB) 030-5952 4” x 30” Hydraulic Cylinder (3/4” ORB), Ports @ 90º...
  • Page 44 ROCK PICKER 900 NOTES Notes...
