8.3 VALVE UPGRADE KIT (XF500-KIT) DRAWING AND PART LIST

©Copyright Task Force Tips LLC 1999-2018
See
Section
5.6
18
XF500-KIT
VALVE UPGRADE KIT
INDEX DESCRIPTION
SAFETY VALVE HANDLE LABEL
1
VALVE HANDLE
2
1/4 x 1 3/8 SPIROL PIN
3
TORSION SPRING
4
BUTTERFLY
5
5/32 x 1 1/8 SPIROL PIN
6
O-RING-118
7
BUSHING
8
O-RING-113
10
VALVE SHAFT
11
PADDLE
35
1/4-20 x 7/8 FLAT HEAD
36
WEAR PLATE
37
PADDLE PIVOT
38
PADDLE PIVOT SPRING
40
3/32 x 1/2 SPIROL PIN
41
TRIP PIN
42
TRIP PIN SPRING
43
QTY ITEM #
1 XL070
1 X540
1 VP250X1.375H
1 X560
1 X550
3 V1920
2 VO-118
2 X565
2 VO-113
1 X570
1 X530
1 VT25E20FH875
1 X585
2 X590
2 X575
1 VP094X500H
1 X580
1 X582
LIX-040 May 30, 2018 Rev10
